Etac molift Raiser Pro Reconditioning

Advertisement

Quick Links

Raiser Pro
Reconditioning
EN
1
Manuell / disinfectant washing
Use a solvent-free detergent
with a pH level between 5
and 9.
Can be washed at 70° C for
10 minutes.
Place the Raiser Pro on the
floor in an angeled position
after washing, so the water
runs out.
2
3
3
1
2
3
4
5
2
Leg support
7
If leg suppport is damaged or worn out:
Unscrew both knobs.
Separate hande an pipes from main plate.
Pull release wire and slide leg support off the
5
pipes.
Pull release wire on new leg support. Insert the
legsupport. Release wire and make sure leg sup-
port lock are engaged.
Mount handle with pipes into main plate, insert
knobs and tighten.
1
2
3
If castor are damaged, turn or rolls porly:
Unscrew castor (2), using tool (3) (art:28465)
Replace bolt and castor (1) (2)
Screw inn new castor, using tool (3) (art:28465).
Tighten aprox 14Nm.
7
"Click"
6
"Click"
3
2
Castors

Advertisement

loading
Need help?

Need help?

Do you have a question about the molift Raiser Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Etac molift Raiser Pro

  • Page 1 Raiser Pro Reconditioning Leg support ”Click” ”Click” If leg suppport is damaged or worn out: • Unscrew both knobs. • Separate hande an pipes from main plate. • Pull release wire and slide leg support off the pipes. • Pull release wire on new leg support. Insert the legsupport.
  • Page 2 Wipe clean old grease and dirt. • Apply grease (art:28473) on aluminum plate(6) • Reasembly wheel with the molift logo horizontally Original spare parts from Etac should always be used. on the top of the wheel, tighten bolt (1) aprox 13Nm...
