MANUAL OF INSTALLATION - USE - MAINTENANCE

BURNERS - BRUCIATORI - BRULERS - BRENNER - QUEMADORES - ГОРЕЛКИ

7.5 11/2023

M039159CH

Table of Contents

Need help?

Do you have a question about the P60 VS and is the answer not in the manual?

Questions and answers

Summary of Contents for CIB UNIGAS P60 VS

Page 1 P60 VS P72 VS P73 VS Multihead gas burners MANUAL OF INSTALLATION - USE - MAINTENANCE BURNERS - BRUCIATORI - BRULERS - BRENNER - QUEMADORES - ГОРЕЛКИ 7.5 11/2023 M039159CH...
Page 2: Risk Analysis
DANGERS, WARNINGS AND NOTES OF CAUTION - Faults in the fuel supply system; - Use of the burner even after an error and/or fault has occurred; - Repairs and/or overhauls incorrectly carried out; This manual is supplied as an integral and essential part of - Modification of the combustion chamber with inserts that prevent the the product and must be delivered to the user.
Page 3 those parts likely to constitute sources of danger shall be made harm- For safety reasons the unit must be efficiently earthed and installed as  less. required by current safety regulations. In case the equipment is to be sold or transferred to another user, or in It is vital that all saftey requirements are met.
Page 4: Symbols Used
DIRECTIVES AND STANDARDS close the gas valves; contact qualified personnel. Gas burners Do not obstruct the ventilation openings of the room where gas  European directives appliances are installed, to avoid dangerous conditions such as the 2016/426/UE (appliances burning gaseous fuels) development of toxic or explosive mixtures.
Page 5 PART I: SPECIFICATIONS PART I: SPECIFICATIONS These burners are designed to be installed into boilers provided with very big combustion chamber but the tube nest very close to the burner stokhole. The flame produced by this burner series is very short, but has the energy necessary to take up all the combustion chamber and then exchange this energy to the water, as to get very high efficiency.
Page 6: Gas Connection
PART I: SPECIFICATIONS Note: the figure is indicative only Control panel with startup switch Gas valve group Cover Flange Blast tube-Combustion head group Head adjusting ring nut Air tank Gas operation: the gas coming from the supply line passes through filter, gas valves and pressure regulator. This one forces the pres- sure in the utilisation limits.
Page 7 PART I: SPECIFICATIONS Specifications BURNER TYPE P60..VS P72..VS P73..VS 332 - 1100 300 - 1650 300 - 2150 Output min. - max. kW Natural gas Fuel see next paragraph ”Gas category” Category 35 - 116 32 - 174.6 32 - 227,6 Gas rate min - max (Stm min.- max.
Page 8 Overall dimensions (mm) Boiler plate drilling P60 VS - 1.40 1185 M12 450 450 P60 VS - 1.50 1185 1013 M12 450 450 P60 VS - 1.65 1185 1058 M12 450 450 P72 VS - 1.50 1338 373 1057 381...
Page 9: Performance Curves
PART I: SPECIFICATIONS Performance curves P60.. VS P72..VS 200 300 400 500 600 700 800 900 1000 1100 1200 1000 1250 1500 1750 P73..VS 1000 1250 1500 1750 2000 2250 To get the input in kcal/h, multiply value in kW by 860. Data are referred to standard conditions: atmospheric pressure at 1013mbar, ambient temperature at 15°C.
Page 10 PART I: SPECIFICATIONS P73 - VS 87,5 Rp 2" (50) 62,5 37,5 DN65 DN80 12,5 75 100 125 150 175 200 225 250 275 Caution: the gas rate value is quoted on the x-axis, the related network pressure is quoted on the y-axis (pres- sure value in the combustion chamber is not included).
Page 11 Packing The burners are despatched wooden cages whose dimensions: P60 VS: 1390 х 870 х 960 mm (L x P x H) P72 VS - P73 VS: 1480 х 950 х 1110 mm (L x P x H) Packing cases of this kind are affected by humidity and are not sui- table for stacking.
Page 12: Electrical Wiring
PART II: INSTALLATION Electrical wiring Respect the basic safety rules. make sure of the connection to the earthing system. do not reverse the phase and neutral connections. fit a differential thermal magnet switch adequate for connection to the mains. ATTENTION: before executing the electrical connections, pay attention to turn the plant’s switch to OFF and be sure that the burner’s main switch is in 0 position (OFF) too.
Page 13 PART II: INSTALLATION Rotation of fan motor After completing the electrical connection of the burner, remember to check the rotation of the fan motor. The motor should rotate in an anti-clockwise direction looking at cooling fan. In the event of incorrect rotation reverse the three-phase supply and check again the rotation of the motor.
Page 14 PART II: INSTALLATION GAS TRAIN CONNECTIONS The diagrams show the components of the gas train included in the delivery and which must be fitted by the installer.The diagrams are in compliance with the current laws. ATTENTION: BEFORE EXECUTING THE CONNECTIONS TO THE GAS PIPE NETWORK, BE SURE THAT THE MANUAL CUTOFF VALVES ARE CLOSED.
Page 15 PART II: INSTALLATION GAS TRAIN CONNECTIONS WARNING: before executing the connections to the gas pipe network, be sure that the manual cutoff valves are closed. ATTENTION: it is recommended to mount filter and gas valves to avoid that extraneous material drops inside the valves, during maintenance and cleaning operation of the filters (both the filters outside the valves group and the ones built-in the gas valves).
Page 16: Mounting Positions
PART II: INSTALLATION MultiBloc MB-DLE - Assembling the gas train Mounting Mount flange onto tube lines: use appropriate sealing agent Insert MB-DLE: note position of O rings Remove MultiBloc between the threaded flanges After installation, perform leakage and functional test Disassembly in reverse order MB-DLE 405..
Page 17 PART II: INSTALLATION DUNGS MBE - Components and position of pressure switches DUNGS MBE.. VD-V VD-R Mounting positions VD-V VD-R On equipment versions Facile VD-R must be installed upstream valve PGMIN minimum gas pressure switch Actuator with integrated pressure stabiliser PGMIN minimum gas pressure switch (alternative to 1) On-Off actuator PGCP leakage control gas pressure switch...
Page 18 PART II: INSTALLATION Siemens VGD20.. e VGD40.. Components and position of pressure switches SKP25 SKP25 SKP15 SKP15 SIEMENS VGD.. Mounting positions PGMIN minimum gas pressure switch Actuator with integrated pressure stabiliser PGMIN minimum gas pressure switch (alternative to 1) On-Off actuator PGCP leakage control gas pressure switch Valve body (Threaded) PGMAX maximum gas pressure switch...
Page 19 PART II: INSTALLATION Gas Proving System VPS504 The VPS504 check the operation of the seal of the gas shut off valves. This check, carried out as soon as the boiler thermostat gives a start signal to the burner, creates, by means of the diaphragm pump inside it, a pressure in the test space of 20 mbar higher than the supply pressure.
Page 20 ADJUSTMENTS ATTENTION: before starting the burner up, be sure that the manual cutoff valves are open and check that the pressure upstream the gas train complies the value quoted on paragraph “Technical specifications”. Be sure that the mains switch is closed.
Page 21: Gas Filter
Pressure - rate in combustion head curves P60 - VS P72 - VS 100 110 120 Gas rate Stm Gas rate Stm P73 - VS 100 125 150 175 200 225 250 Gas rate Stm Gas Filter The gas filters remove the dust particles that are present in the gas, and prevent the elements at risk (e.g.: burners, counters and regu- lators) from becoming rapidly blocked.
Page 22 remove cover T, reverse it upside down and use it as a toolto rotate screw VR. Decrease the ignition flow rate by screwing, increase it by unscrewing. Do not use a screwdriver on the screw VR! Note: the screw VSB must be removed only in case of replacemente of the coil (see picture on page 24). turn the burner on by means of the burner switch (placed on the burner control panel - see Ðèñ.
Page 23 the rod TR towards the air damper shaft, the air damper opens and consequently the air flow rate increases, moving it far from the shaft the air damper closes and the air flow rate decreases. Note: once the procedure is perfomed, be sure that the blocking nut RA is fasten. Do not change the position of the air damper rods.
Page 24 Calibration of air and gas pressure switches The air pressure switch locks the control box if the air pressure is not the one requested. If it hap- pens, unlock the burner by means of the control box unlock pushbutton, placed on the burner control panel.
Page 25: Limitations Of Use
PART II: OPERATION PART II: OPERATION LIMITATIONS OF USE THE BURNER IS AN APPLIANCE DESIGNED AND CONSTRUCTED TO OPERATE ONLY AFTER BEING CORRECTLY CONNEC- TED TO A HEAT GENERATOR (E.G. BOILER, HOT AIR GENERATOR, FURNACE, ETC.), ANY OTHER USE IS TO BE CONSIDE- RED IMPROPER AND THEREFORE DANGEROUS.
Page 26 PART II: OPERATION Fig. 17 - Control panel with startup switch Legend Main switch on - off Lock indicator light Burner control unit release button Gas pressure switch consent indicator light Gas valve tightness control block indicator light (only burners with tightness control) High-flame warning light (or open air damper, when preventive) Low flame warning light Ignition transformer operation indicator lamp...
Page 27: Pressure Taps
PART II: OPERATION MultiBloc MBE Regulation VD-R whith PS Setting scale is „Not“ linear! Various sensors available. Output pressure according to sensor‘s measuring range. Increasing pressure Adjust the outlet pressure to the value specified by the burner or equipment manufacturer! While making outlet pressure adjustments, do not Decreasing pressure exceed a value that creates a hazardous condition to the...
Page 28 PART II: OPERATION Adjusting the gas valves group Multibloc MB-DLE VS T(VR) The multibloc unit is a compact unit consisting of two valves, gas pressure switch, pres- sure stabilizer and gas filter. The valve is adjusted by means of the RP regulator after slackening the locking screw VB by a number of turns.
Page 29: Periodical Servicing
PART III: MAINTENANCE PART III: MAINTENANCE At least once a year carry out the maintenance operations listed below. In the case of seasonal servicing, it is recommended to carry out the maintenance at the end of each heating season; in the case of continuous operation the maintenance is carried out every 6 months.
Page 30 PART III: MAINTENANCE Removing the filter in theMULTIBLOC DUNGS MB-DLE 415 - 420 B01 1” 1/2 - 2” Check the filter at least once a year!  Change the filter if the pressure difference between pressure connection 1 and 2 (Fig. 24-Fig. 25) p> 10 mbar. ...
Page 31 PART III: MAINTENANCE Removing the combustion head To disassemble the combustion head assembly, proceed as follows: unscrew the four VF fixing screws that secure cap C from the rest of the burner: remove the cap; unscrew the grub screws GR securing the head adjustment ring G Unscrew the threaded rod A for head adjustment;...
Page 32 PART III: MAINTENANCE to replace the nozzles, if damaged, unscrew the BB screws and remove each nozzle by pulling it towards you as shown in the figure below; Replace EC electrode cables, if damaged, following the sequence of combustion heads indicated by the letters on the electrode cables (see page 10);...
Page 33 PART III: MAINTENANCE CAUTION: When refitting the manifold, remember to insert the 'O' ring. When centring the heads, do not fasten the screws completely at the base of the collector. Secure them after centring. Do not touch the hinge and burner flange screws. 15 For reassembly, follow the steps in reverse order, paying attention to the dimensions of the electrodes.
Page 34 PART III: MAINTENANCE Matching the combustion heads and the control boxes The combustion head is modae of four heads: one is provided with Siemens QRA detection probe connected to the Siemens LFL control box (Fig. 57-Fig. 59-A); the other three heads are provided with Krom-Schroeder UVS5 probes, connected to the Krom- Schroeder IFW15 flame detectors (Fig.
Page 35 PART III: MAINTENANCE Checking the detection current To check the detection current follow the diagram on the following pictures. If the signal is less than the quoted value, check the posi- tion of the detector, the electrical contacts and, if necessary, replace the detector. Control box Minimum detection signal Siemens LGB..
Page 36: Troubleshooting
TROUBLESHOOTING TROUBLE CAUSE  MAIN SWITCH OPEN   LACK OF GAS MAXIMUM GAS PRESSURE SWITCH DEFECTIVE (IF   PROVIDED)    THERMOSTATS/PRESSURE SWITCHES DEFECTIVE  OVERLOAD TRIPPED INTERVENTION  AUXILIARIES FUSE INTERRUPTED      CONTROL BOX FAULTY ...
Page 37: Spare Parts
PART III: MAINTENANCE SPARE PARTS Desription P60..VS P72..VS P73A..VS 2020468 2020468 2020468 CONTROL BOX Siemens LME.. 2020114 2020114 2020114 CONTROL BOX - Krom-Schroeder IFW15 2080108 2080116 2080116 DETECTION ELECTRODE 2080218 2080218 2080218 IGNITION ELECTRODE 2090119 2090119 2090119 GAS FILTER - Rp2 2090117 2090117 2090117...
Page 40 C.I.B.UNIGAS S.p.A. Via L.Galvani ,9 - 35011Campodarsego (PD) - ITALY Tel. +39 049 9200944 - Fax +39 049 9200945 website:www.cibunigas.it-e-mail:cibunigas@cibunigas.it Note: specifications and data subject to change. Errors and omissions exceptd.
Page 41 LME73.000Ax + PME73.831AxBC LME73.831AxBC Service instruction manual M12921CB Rel.1.2 02/2016...
Page 42: General Features
GENERAL FEATURES LME/ is suitable for gas, light and heavy oil burners LME7 series has two devices: LME73.000 (hardware) and PME73.831AxBC (programmable unit). The LME73.831AxBC is also available: it has a built in software and it isa not programmable. LME7 is inside the control panel. If supplied, PME73.831BC is inside the LME7; The display AZL23..
Page 43: User Interface
User interface : Button A - Display preset output - In lockout position: Power value to the time of fault Info and Enter button - Reset in the event of fault, changeover visual diagnostic of the cause of fault (refer to chapter Diagnostics of cause of fault ) - button - Display flame signal current 2 or phases display - In lockout position: MMI phase to the time of fault...
Page 44 List of phase display on board LME : Phase number of Function 7-segment display Standby Standby, waiting for heat demand Mains ON / test phase (e.g. detector test) Startup Yellow Safety valve ON, air pressure switch test / POC test (timeout / locking Yellow Fan motor ON / air pressure switch test / settling time Yellow...
Page 45 Operation : The lockout reset button (info button) (EK) is the key operating element for resetting the burner control and for activating / deactivating the diagnostics functions. The multicolor signal lamp (LED) is the key indicating element for visual diagnostics. Both lockout reset button (EK) and signal lamp (LED) are located in the control panel.
Page 46: Program Sequence
Program sequence : Version 1: • Ignition load < low-fire • Prepurging in high-fire • Parameter 515 = 1 (condition parameter 259.01 > 0 seconds)
Page 47 Program sequence : Version 2: • Ignition load > low-fire • Prepurging in high-fire • Parameter 515 = 1 (condition parameter 259.01 = 0 seconds)
Page 48 Phase Function number Lockout phase Standby, waiting for heat demand Operation, modulating operation Interval until release of load controller target (analog or 3-position step input) Under voltage Safety loop open Extraneous light on burner startup (timeout/locking after 30 seconds) Mains ON/test phase (e.g. detector test) Shutdown, actuator opens in CLOSE position (homerun) Safety valve ON, air pressure switch OFF, actuator opens in CLOSE position Part 1: Fan motor ON...
Page 49 Error code table : Red blink code of fault signal lamp (LED) Possible cause 2 x blinks No establishment of flame at the end of the safety time (TSA) - Faulty or soiled flame detector - Faulty or soiled fuel valves - Poor adjustment of burner, no fuel - Faulty ignition equipment 3 x blinks...
Page 50 Flame detection – detection electrode : Short-circuit current Max. AC 1 mA Required detector current Min. DC 2 μA, display approx. 45 % Possible detector current Max. DC 3 μA, display approx. 100 % Permissible length of detector cable (laid separately) 30 m (core-earth 100 pF/m) Measuring circuit Keys...
Page 51 Gas proving system : Valve proving is dependent on input valve proving ON / OFF (X2-02). When a leak is detected, the gas valve proving function ensures that the gas valves will not be opened and that ignition will not be switched on. Lockout will be initiated. Valve proving with separate pressure switch (P LT) Step 1: td4 –...
Page 52 Instruction, control and modify via AZL2x : The AZL2x.. display/programming unit is shown below: The keys functions are the following: Key F + A While pressing the two keys contemporarly, the code message will appear: by entering the proper password it is possible to access the Service mode. Info and Enter keys Used for Info and Service menues Used as Enter key in the setting modes...
Page 53 The display will show these data: Lock+unlock codes Flame Open valves Ignition transformers energised Fan motor energised Oil pre-heater energised Plant heat request Parameter setting mode Info mode Service mode Closing actuator Opening actuator Unit measure While pushing the button together with whatever else button, LME73 locks out; the display shows On stand-by position, appears On operation, all the phases appears with their number.
Page 54 List of phase with display AZL2x : Phase number Function Standby Standby, waiting for heat request Ph08 Power ON / test phase (e.g. detector test) Startup Ph21 Safety valve ON, air pressure switch test / POC test (timeout / locking after 5 seconds), actuator opens in low-fire position / CLOSE position Ph22 Fan motor ON or air pressure switch test / settling time...
Page 55 Error code list with operation via internal AZL : Error code Clear text Possible cause Loc 2 No establishment of flame at the - Faulty or soiled fuel valves end of the safety time (TSA) - Faulty or soiled flame detector - Poor adjustment of burner, no fuel - Faulty ignition equipment Loc 3...
Page 56 Entering the Parameter levels: y means of a proper use of the keys, it is possible to enter the various level parameters, as shown in the following flow chart :...
Page 57 Info level : Keep pushing the button until appears. Use + or - for scrolling the parameter list. If on the right side a dash-dot appears, it means the display doesn't show the full description. Push again for 1 to 3 s in order to show the full description. Below the visible Info parameters: Parameter Parameter list...
Page 58 Service level : Keep pushing the button until appears. Use + or - for scrolling the parameter list. . If on the right side a dash-dot appears, it means the display doesn't show the full description. Push again for 1 to 3 s in order to show the full description. Below the visible Info parameters: Parameter Parameter list...
Page 59 Process data Normalized speed Read only 100% 0.01 % Service Mains voltage Read only LME73.000A1: Service 175 V LME73.000A2: 350 V Flame intensity Read only 100% Service...
Page 60 Parameter level (Heating engeneering) : This level lets the engineer to modify some burner parameters. It is protect with a 4 digit password (SO level) and a 5 digit password (OEM level) Password input : push F and A buttons together until the display shows "code" and 7 underlines. The left one flashes. By move the flashing underline until it is on the desired position and push "enter".
Page 61 Repetition in the event of loss of flame during operation Edit 0 SO 0 = None 1 = None 2 = 1 x Repetition 241.00 Valve proving Edit 1 SO 0 = Off 1 = On 241.01 Valve proving Edit 0 SO 0 = During prepurge time (t1) 1 = During postpurge time (t8)
Page 62 Power setting Analog input (feedback potentiometer ASZxx.3x required) Edit 0 SO 0 = 3-position step input 1 = 0...10 V 2 = 0...135 Ω 3 = 0...20 mA 4 = 4...20 mA with lockout at I <4 mA 5 = 4...20 mA WARNING Parameter Num.
Page 64 Note: Specifications and data subject to change. Errors and omissions excepted.
