- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. LG LRTB2023BS Owner's Manual Shop genuine replacement parts for LG LRTB2023BS Find Your LG Refrigerator Parts - Select From 834 Models -------- Manual continues below --------...
-
Page 2: Refrigerator- Freezer
LRTB2023W, LRTB2023BS LRTB2023BK REFRIGERATOR- FREEZER OWNER'S MANUAL PLEASE READ THIS OWNER'S MANUAL THOROUGHLY BEFORE OPERATING AND KEEP IT HANDY FOR REFERENCE AT ALL TIMES. RÉFRIGÉRATEUR- CONGÉLATEUR MANUEL DE L’UTILISATEUR LISEZ ATTENTIVEMENT CE MANUEL AVANT FAIRE FONCTIONNER L’APPAREIL ET CONSERVEZ-LE POUR TOUTE RÉFÉRENCE À... -
Page 3: Table Of Contents
REFRIGERATOR SAFETY ......3 TABLE OF INSTALLING YOUR REFRIGERATOR ..4 CONTENTS Unpacking Your Refrigerator ....... 4 Installation ............ 4 Electrical Requirements ....... 5 FEATURES CHART ........6 OPERATION ..........7 Starting ............7 Temperature Control ........7 Ice Making ........... 8 Defrosting ............ -
Page 4: Refrigerator Safety
REFRIGERATOR SAFETY Your safety and the safety of others is very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the safety alert symbol. This symbol alerts you to hazards that can kill or hurt you and others. AII safety messages will be preceded by the safety alert symbol and the word DANGER or WARNING. -
Page 5: Installing Your Refrigerator
w w WARNING INSTALLING YOUR REFRIGERATOR w w WARNING Explosion Hazard Keep flammable materials and vapors, Excessive Weight Hazard such as gasoline, away from refrigerator. Use two or more people to move and Failure to do so can result in death, install refrigerator. -
Page 6: Electrical Requirements
Electrical Requirements w w WARNING Electrical Shock Hazard Plug into a grounded 3-prong outlet. Do not remove ground prong. Do not use an adapter. Do not use an extension cord. Failure to follow these instructions can result in death, fire, or electrical shock. Before you move your refrigerator into its final location, it is important to make sure you have the proper electrical connection:... -
Page 7: Refrigerator Compartment
FEATURES CHART FREEZER COMPARTMENT Freezer Shelf Freezer Door Bin General Type Ice Tray Door Cooling Freezer Temperature On the refrigerator Control Dial door, the cold air passageway is REFRIGERATOR installed to supply COMPARTMENT cold air to the doorside of the Temperature refrigerator Control Dial... -
Page 8: Operation
FREEZER OPERATION Freezer Control Starting When your refrigerator is first installed, allow to run 2-3 hours to stabilize at normal operating Normal temperature prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. -
Page 9: Ice Making
ICE MAKING (For General Defrosting Type Ice Maker) Defrosting takes place automatically. If the tray is filled with water to the highest Defrosted water flows down to the level, it will be difficult to remove ice cubes. evaporating tray which is located in the lower back side of the refrigerator and is For quick freeze, adjust the freezer dial to 3. -
Page 10: Freezer Shelf
w w CAUTION Freezer Shelf Lift the front side of the shelf slightly and pull it Make sure that a shelf is placed forward to remove it. horizontally. Failure to do so may result in falling of the shelf, causing spilling or spoiling of food. -
Page 11: Suggestions On Food Storage
Refrigerator Compartment SUGGESTIONS ON Avoid placing moist food on deep interior FOOD STORAGE refrigerator shelves, it could freeze upon direct contact with chilled air. To avoid this, it is better to store food in a covered container. Storing Food Always clean food prior to refrigeration. Store fresh food in the refrigerator Vegetables and fruits should be washed and compartment. -
Page 12: Cleaning Your Refrigerator
Additional cleaning tips are listed below: CLEANING YOUR PART COMMENTS REFRIGERATOR Outside Waxing external painted metal surfaces helps provide w w WARNING rust protection. Do not wax plastic parts. Wax painted metal surfaces at least twice a year using appliance wax (or auto paste wax). -
Page 13: Lamp Replacement
Power Failure LAMP Most power failures are corrected in an hour or REPLACEMENT two and will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is 1. Unplug the power cord from the outlet. off. -
Page 14: Replacement Of Door Opening Type
2. Removing Refrigerator Door REPLACEMENT OF Loosen the screw (9) and separate off the middle hinge (10). DOOR OPENING TYPE Lift the door (11) sightly and separate it. Take off the Grille (12). w w PRECAUTION Loosen the screw (14) and fix the pin (15) 1. - Page 15 3. Moving Freezer Handle 4. Moving Refrigerator Handle Loosen 2 screws (4). Separate the cap (8) and loosen 2 screws (9). Loosen the screws (1) (two on the top and two on the bottom), take off the handle (2), Loosen 1 screw (6) (on the bottom), pull the and attach it on the right.
- Page 16 5. Attaching Refrigerator Door 7. After Completing the job Fix the base Grille (1). Make sure that the four corners of the door gasket are not folded. It is recommended to Fix the door (3) to the bottom hinge pin. apply a small amount of silicon grease on Fix the middle hinge (4) on the opposite side them.
-
Page 17: Before Calling For Service
BEFORE CALLING FOR SERVICE SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE CAUSES FIRST: PROBLEM POSSIBLE CAUSES REFRIGERATOR DOES NOT Has a house fuse blown or circuit breaker tripped? OPERATE Has the power cord plug been removed or loosened from the electrical wall outlet? REFRIGERATOR OR... - Page 18 NOTE...
