Load cell specifications

Model No
Rated Capacity
Rated Out put
Excitation
Voltage
IP Level
Material
Cable
Input Resistance
Out put
Resistance
Temperature
Range
Safe overload
Ultimate overload 200 %RC
Repeatability
Creep
Zero Balance
- 26 -
AHC/QHC series technical manual
NA22
6~40 (kg)
2.0mV/V± 0.2 mV/V
15 VDC
IP65
Aluminium Alloy
Φ 4x 35 cm
390Ω ±15Ω
350Ω ±5Ω
-20° C - 60° C
150 %RC
0.03 %R.O
0.03 %R.O/ 3 min
± 0.02 mV/V
C2X1
6~50 (kg)
2.0 mV/V±0.2 mV/V
20 VDC
IP64
Aluminium Alloy
Φ 8.2 four core shield
420Ω ±30Ω
350 Ω ± 5 Ω
-10° C - 50° C
150 %R.C
200 %R.C
0.02 %R.O
0.02 %R.O/ 20min
± 0.1 mV/V
