Summary of Contents for THERMOROSSI COMPACT S32 CLASS 5

  • Page 2: Table Of Contents

    1.2.1 RECOMMENDATIONS ................................5 1.2.2 GENERAL WARNINGS ................................6 1.3 TRANSPORTATION AND STORAGE ......................6 2 – TECHNICAL CHARACTERISTICS...................... 7 2.1 COMPACT S32 CLASS 5 ..........................7 3 – GENERAL DESCRIPTION ........................9 3.1 OPERATING TECHNOLOGY ........................... 9 3.2 THE PELLET ..............................9 3.3 THE FEEDBOX ..............................
  • Page 3 12.2 GUIDELINES FOR CORRECT INSTALLATION ..................56 13 TROUBLESHOOTING CAUSE / SOLUTION ..................57 14 SPARE PARTS ........................... 59 14.1 SPARE PARTS BOILER COMPACT S32 CLASS 5 ..................59 14.2 SPARE PARTS BOILER COMPACT S32 CLASS 5 ..................60 14.3 KEY TO SPARE PARTS ..........................61...
  • Page 4 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 DICHIARAZIONE DI CONFORMITA’ DECLARATION OF CONFORMITY La THERMOROSSI S.P.A., VIA GRUMOLO N° 4 36011 ARSIERO (VI), sotto la sua esclusiva responsabilità DICHIARA che l’apparecchiatura descritta in appresso: DECLARES that the product:...

  • Page 5: Introduction

    If the appliance is sold or transferred to another user ensure that the manual is handed over with it. Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or used in any other way without the necessary authorisation.

  • Page 6: General Warnings

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 1.2.2 GENERAL WARNINGS Attention: the appliance must be connected to a system provided with a PE conductor (in compliance with the specifications concerning low voltage equipment). Before installing the appliance check the efficiency of the earth circuit of the power supply system.

  • Page 7: Technical Characteristics

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 2 – TECHNICAL CHARACTERISTICS 2.1 COMPACT S32 CLASS 5 COMPACT S32 CLASS 5 M.U. VALUES Height 1373 Depth Width Empty weight Firebox power Min. / Max. * 9.54 / 31.94 Thermal output to water Min / Max * 8.73 / 29.40...
  • Page 8 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 DETTAGLIO A DETAIL A DETAIL A Page 8...

  • Page 9: General Description

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 3 – GENERAL DESCRIPTION 3.1 OPERATING TECHNOLOGY Your appliance has been built to fully satisfy all your heating and practical requirements. Top-grade components and functions managed with microprocessor technology guarantee high reliability and optimal performance.
  • Page 10 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 AE AE PARAGRAFO 3 _4_ 32.DFT Page 10...

  • Page 11: Installation

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 4 – INSTALLATION 4.1 APPLIANCE LOCATION Follow the general guidelines set out in paragraph 1.1 to the letter. Above all keep in mind that the flooring of the room in which the stove is being installed must withstand the weight of the stove with the added weight of the pellet load and the water contained in it.
  • Page 12 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 ATTENTION IMPORTANT: HANDLE THE BOILER WITH CARE AS DAMAGE CAUSED DURING THE UNPACKING OPERATION WILL NOT BE COVERED BY THE WARRANTY. Figura 1 Legenda FIGURA FIGURE Page 12...
  • Page 13 Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 Figura 2 Figura 3 Page 13...
  • Page 14 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 Figura 4 Figura 5 Page 14...
  • Page 15 Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 Figura 6 Figura 7 Page 15...

  • Page 16: Connecting The Appliance To The Flue Outlet

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 4.3 CONNECTING THE APPLIANCE TO THE FLUE OUTLET Connection of the appliance to the flue outlet must be carried out in strict compliance with the instructions contained in this booklet and particularly with those in Chapter 9.

  • Page 17: -Hydraulic Connection

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 5 –HYDRAULIC CONNECTION 5.1 HYDRAULIC DIAGRAM System circulating pump 3/4" boiler fill/drain tap Automatic air purge valve Plant water return Sensor PTC boiler Plant delivery Air thermostat bulb 100°C 1/2’’...

  • Page 18: Guidelines For Plants With Zone Valves

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 5.1.1 GUIDELINES FOR PLANTS WITH ZONE VALVES Note: above 61°C, the generator pump is always active as it is essential to dissipate the heat; therefore the solenoid valve must be open for the following reasons: •...

  • Page 19: Hydraulic Diagram With Heating Only

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 5.2 HYDRAULIC DIAGRAM WITH HEATING ONLY s c a r i c o VM3 VT andata impianto riscaldamento ritorno impianto riscaldamento saracinesca VNR : valvola di non ritorno VEC : vaso di espansione chiuso per protezione impianto...

  • Page 20: Example Of Hydraulic Diagram With Interspaced Boiler Coils Or Boiler Coils

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 5.3 EXAMPLE OF HYDRAULIC DIAGRAM WITH INTERSPACED BOILER COILS OR BOILER COILS VM3 VT s c a r i c o andata impianto riscaldamento ritorno impianto riscaldamento saracinesca VNR : valvola di non ritorno...

  • Page 21: Example Of Hydraulic Drawing With Boiler Coils And Heating

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 5.4 EXAMPLE OF HYDRAULIC DRAWING WITH BOILER COILS AND HEATING Co n t a t t o Cr o n o t e r m o s t a t o...

  • Page 22: Hydraulic Diagram With Thermocell (Or Thermopuffer) + Additional Thermopuffer + High Temperature Heating And Low Temperature Heating

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 5.5 HYDRAULIC DIAGRAM WITH THERMOCELL (OR THERMOPUFFER) + ADDITIONAL THERMOPUFFER + HIGH TEMPERATURE HEATING AND LOW TEMPERATURE HEATING. Sonda PT100 S1 ai pin 1 e 2 della morsettiera M5...

  • Page 23: Instructions For Executing The Hydraulic System Closed Expansion Tank

    The nominal volume of the additional closed expansion tank must be sized in relation to the volume of expansion of the water contained in the system. Thermorossi prescribes that the size of the additional closed expansion tank must be equal to 10% of the water contained in the system.

  • Page 24: Use Of The Appliance

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 6 – USE OF THE APPLIANCE The appliance, when operating, could be hot to the touch, particularly the door of the combustion chamber: take care when handling the appliance components. Your appliance has obtained the CE marking and has been made to run for at least one hour to check that it functions correctly.
  • Page 25 Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 This button is used to set the day of the week, the hour and minutes. (see para. 6.3) DATE/TIME This button is used to set the programmed on and off sequences. (see Para. 6.4) CHRONO Is used to change the rotation speed of the smoke suction unit.

  • Page 26: Description Of The Power Panel

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 Indicates the room temperature detected by the thermocouple, if connected. (see para. 6.8) The thermometer icon, on the right of the display, indicates the target room temperature set by the user if the optional sensor is connected (see para.
  • Page 27 Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 2) Press the Scroll Buttons to select the day of the week on which you want to set the program. Each number corresponds to one day of the week (e.g. 1 corresponds to Monday, 2 corresponds to Tuesday, etc...). To confirm the selected day of the week for the programming press the Degrees Button.
  • Page 28 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 Press the Flame button once again to copy all the cycles programmed for Tuesday to Wednesday. The following screen will appear: Using the same logic we can copy the programmed cycles to the other days.

  • Page 29: Level: Operating Level Setting

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 6.5 LEVEL: OPERATING LEVEL SETTING The appliance must be energised and the I/0 switch in position “I". Your appliance is delivered with an excellent program installed that favours combustion efficiency; the program is called LEVEL 1.

  • Page 30: Thermocontrol: Controlling A Puffer

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 6.6 THERMOCONTROL: CONTROLLING A PUFFER The appliance must be energised and the I/0 switch in position “I". This function enables you to control the operating temperature of a stratification puffer through the use of two sensors PT 100 (optional) connected to the respective terminal block on the electronic board (see para.

  • Page 31: Acs Summer: Activation Of The Boiler Tube Control From A Chrono Command

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 By setting THERMOCONTROL ON, when the puffer is requesting heat the temperatures detected by the sensors S1 and S2 and the word PUF will appear on the display. When is it important to use the THERMOCONTROL function? In systems configured like the diagram on the right, where the appliance is connected directly to a stratification puffer.

  • Page 32: T.ambient: Controlling The Room Temperature

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 ATTENTION: If an external chronothermostat is connected to the appliance, it is not necessary to program any operating time band as the appliance will follow the cycles set in the external chronothermostat. Consequently simply press the Menu Button several times to exit the screen, until the initial screen appears.

  • Page 33: Thermo Acs: Controlling A Configured Boiler Tube In A System

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 Press one of the two Scroll Buttons and the following screen will appear (Select ON to activate). Press the Menu Button several times, to confirm and exit the screen, until the initial screen appears. .
  • Page 34 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 The THERMO ACS function can be activated by proceeding as follows: Quickly press the Menu Button until the following screen appears: After a few seconds the following screen will appear on the display: Press one of the two Scroll Buttons and the following screen will appear (Select ON to activate).

  • Page 35: Operation Of The Generator

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 When is it important to use the THERMO ACS function? In systems configured like the nearby diagram, where the appliance is connected directly to a domestic hot water boiler tube and to the system.

  • Page 36: Setting Range

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 ATTENTION: It is recommended to verify at least once a month that when the appliance is in OFF mode in the time interval specified above, the brazier cleaning mechanism “Pellet Power” operates in continuous mode to clean the brazier.

  • Page 37: Manual Operating Cycle

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 Potenza di funzionamento STOP 80°c 61°c 65°c Intervallo modulazione con T max 65°c Potenza di funzionamento STOP 80°c 61°c 70°c Intervallo modulazione con T max 70°c Legenda Potenza di funzionamento Operating power Intervallo modulazione con T max 65 °C...

  • Page 38: Switching Off The Appliance

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 • Check the pressure in the appliance system once again and if necessary bleed any air bubbles from the valve. Press the Flame button repeatedly to set the appliance in AUTO or manual operating mode. The mode will be activated at the end of the start up phase.

  • Page 39: Additional Room Temperature Thermostat / Additional Chronothermostat (Not Supplied)

    230 V or lower voltages as this would seriously damage the control board, and is not covered by warranty. ATTENTION: In the event of connections to the chronothermostat Thermorossi shall not be held responsible for the appliance not starting up, smoke leaks, breakage of the lighting component.
  • Page 40 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 Legenda Cronotermostato Modem Chronothermostat - Modem Contatti 9-10 della morsettiera CN7 Contacts 9-10 of the terminal block CN7 Termostato Ambiente Room Temperature Thermostat Contatti 7-8 della morsettiera CN7 Contacts 7-8 of the terminal block CN7...

  • Page 41: Cleaning And Maintenance

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 8 CLEANING AND MAINTENANCE 8.1 FOREWORD Before beginning any maintenance operation ensure that the appliance is switched OFF and disconnected from the electric power socket. Your stove, being a pellet-fuelled appliance, requires regular general controls and cleaning.
  • Page 42 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 door of the combustion chamber must only be opened when the appliance has completely cooled down: when it is opened it is normal for some ash to spill onto the floor.
  • Page 43 Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 Figura 2 Figura 3 Page 43...
  • Page 44 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 Figura 4 Figura 5 Page 44...
  • Page 45 Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 Legenda Figura Figure Page 45...

  • Page 46: Smoke Discharge Tube And Ventilation Of The Rooms

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 9 – SMOKE DISCHARGE TUBE AND VENTILATION OF THE ROOMS 9.1 FOREWORD Due to the frequent accidents caused by poor functioning of flue outlets installed in private dwellings, we have prepared the following paragraph to assist the installer in his inspection of the parts concerned with eliminating the gases produced by combustion.

  • Page 47: Smoke Outlet

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 9.3 SMOKE OUTLET The smoke channel, the exhaust pipe, chimney and flue outlet (defined as the system for the evacuation of combustion products), are parts of the heating system and they must comply with the legislative requirements of the Ministerial Decree DM 37/08 (ex Italian Law 46/90) and to the applicable specific installation regulations, according to the type of fuel.

  • Page 48: Controls Prior To Installing The Appliance

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 COMIGNOLO E CANNA FUMARIA SECONDO NORMA UNI 10683 LASTRA DI COPERTURA INTERNO ESTERNO LAMIERA DI ACCIAIO A TENUTA STAGNA ISPEZIONE ISPEZIONE LEGENDA COMIGNOLO E CANNA FUMARIA CHIMNEY CAP AND FLUE OUTLET...
  • Page 49 Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 ATTENTION: if the flue outlet is not sufficiently insulated and /or if it is too long it could generate condensation. It is advisable to provide a condensation drain near the smoke outlet of the appliance. The appliance must always and only be installed in a single flue outlet system dedicated exclusively to the appliance.

  • Page 50: Alarms

    ATTENTION: The appearance of one of the alarms described below, does not necessarily imply a defect in the product, but simply Thermorossi S.p.A.’s intention to inform the user of the need for corrective actions in order to guarantee maximum safety, greater reliability and high performance of the appliance .

  • Page 51: Electrical Wiring

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 11 - ELECTRICAL WIRING Figura 1 Figura 2 Figura 3 Page 51...
  • Page 52 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 Figura 4 To access the electronic board it is necessary to follow the instructions indicated in the above drawings: - Open the tank cover (Figure 1) and remove the top cover by pulling it upwards (Figure 2).
  • Page 53 Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 Page 53...
  • Page 54 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 LEGENDA Sensore Hall aspiratore fumi Hall Sensor smoke suction unit Pannello comandi Control panel Sonda fumi Smoke sensor Sonda PT 100 (ACS) optional Sensor PT 100 (ACS) optional Sonda PT 100 (Generatore)

  • Page 55: Information For The Skilled Technician

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 12 – INFORMATION FOR THE SKILLED TECHNICIAN 12.1 MAIN COMPONENTS AND THEIR POSITION SMOKE PRESSURE SWITCH This is a safety switch that stops the screw feeder motor whenever necessary. The main cause for the pressure switch tripping is a blocked flue outlet or smoke exhaust pipe.

  • Page 56: Guidelines For Correct Installation

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 12.2 GUIDELINES FOR CORRECT INSTALLATION • Read this instruction booklet. • The appliance must always be switched off from the control panel. It is forbidden to switch off the appliance by means of the main switch 0/I.

  • Page 57: Troubleshooting Cause / Solution

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 13 TROUBLESHOOTING CAUSE / SOLUTION PROBLEM CAUSE SOLUTION CLEAN THE BRAZIER AS INDICATED IN THIS USE AND PELLET TANK IS EMPTY MAINTENANCE GUIDE, THEN FILL UP THE TANK WITH THE ALARM “NO PELLET-CLEAN BURNER”...
  • Page 58 Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 THE SPARK PLUG IS NOT WORKING CLEAN THE BRAZIER AS INDICATED IN THIS USE AND THE ALARM “FAILED START-CLEAN BURNER” IS DISPLAYED. MAINTENANCE GUIDE, THEN REPLACE THE SPARK PLUG...

  • Page 59: Spare Parts

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 14 SPARE PARTS 14.1 SPARE PARTS BOILER COMPACT S32 CLASS 5 70021264 Coperchio mobile completo 70021265 Coperchio 70021015 Fianco rivestimento sx completo 60011280 Maniglia a scatto 70018697 Fianco rivestimento sx...

  • Page 60: Spare Parts Boiler Compact S32 Class 5

    Manuale d'installazione, uso e manutenzione Pellet boiler Compact S32 CLASS 5 14.2 SPARE PARTS BOILER COMPACT S32 CLASS 5 70012125 70012125 70012128 70020264 70020263 70021037 70021339 60006519 70021027 60011706 70021029 60013559 60013559 70012129 70020266 70014051 60014350 70021028 Scheda completa di supporto...

  • Page 61: Key To Spare Parts

    Installation, use and maintenance guide Pellet boiler Compact S32 CLASS 5 14.3 KEY TO SPARE PARTS Legenda Fianco rivestimento sx completo Complete LH casing side Fianco rivestimento sx LH casing side Magnete Magnet Paracolpi Bumper Isolante Insulation Coperchio mobile completo...
