BAR HEIGHT CHAIR &
COUNTER HEIGHT CHAIR
I N ST R U C T I O N S
Sunrise chair back different than shown.
Crescent chair back different than shown.
Counter Height Chairs are 5" shorter than
Bar Height Chairs.
ASSEMBLY
STEP 1. Cut zip ties to remove spreader bar arms from leg
assembly. Use (4) 2" screws to attach left and right spreader
bar arms to foot rest and spreader bar.
2" SCREW
HARDWARE PACK
Hardware Pack Weight: 10.9 oz.
CHAIR PARTS
• CHAIR BACK
• CHAIR SEAT
• LEFT ARM/LEFT LEG ASSEMBLY
• RIGHT ARM/RIGHT LEG ASSEMBLY
• SPREADER BAR
• FOOT REST
• LEFT SPREADER BAR ARM
• RIGHT SPREADER BAR ARM
SUGGESTED TOOLS
• RUBBER MALLET
• KNIFE OR SCISSORS
• PHILLIPS HEAD SCREWDRIVER
• DRILL
(2) 1.5" BARREL BOLTS
(14) 2" BARREL BOLTS
(16) BARREL NUTS
(6) 2" SCREWS
(2) 1" PEGS
(1) ALLEN WRENCH
(1) SQUARE-HEAD BIT
Advertisement
Related Manuals for Pawleys Island SRCC1-K
Summary of Contents for Pawleys Island SRCC1-K
- Page 1 HARDWARE PACK Hardware Pack Weight: 10.9 oz. (2) 1.5” BARREL BOLTS (14) 2” BARREL BOLTS BAR HEIGHT CHAIR & COUNTER HEIGHT CHAIR I N ST R U C T I O N S (16) BARREL NUTS Sunrise chair back different than shown. (6) 2”...
- Page 2 ASSEMBLY STEP 2. Use (14) 2” barrel bolts, (14) barrel STEP 3. Use (2) 1.5” barrel bolts and (2) barrel STEP 4. PUSH FORWARD TO NOTCH IN nuts and (2) pegs to attach right & left arm/ nuts to attach chair back to right & left arm/ FRAME.
