Pawleys Island Durawood Essentials/Sunrise Chair Assembly Instructions

Durawood Essentials/
Sunrise Chair
CHAIR PARTS
chair seat
left arm/ right arm/
leg
assembly assembly
HARDWARE PACK
Before beginning assembly, make sure you have all parts. Note that
not all parts pictured are to scale.
Congratulations on purchasing this Durawood Essentials/Sunrise Chair! You're going to love the quality, durability and
simple assembly — plus the full Residential Lifetime Warranty. QUESTIONS REGARDING THIS PRODUCT? Call our customer-
service line toll-free at (800) 643-3522.
Your Durawood Furniture comes with several
pegs to increase sturdiness. Wherever you
find a peg hole, insert peg. You may need to
use a small mallet to tap the plug into place.
ASSEMBLY
STEP 1.
Align chair
back holes with
chair seat holes.
( ).
FIGURE 1
FIGURE 1
WITH ARMS
chair back
bottom
chair
frame
leg
14 - 2" Barrel Bolt
Assemblies
6 - 1" Pegs
1 - Allen Wrench
x6
Hardware pack
weight: 8.31 oz
ASSEMBLY INSTRUCTIONS continue, back of page; Residential Lifetime Warranty, back of page
USING BARREL BOLTS
To correctly thread Barrel Bolts to Bolt Fasteners:
Fit the Fastener over the bottom of the Bolt,
turning the Fastener at first counterclockwise,
then
until you hear a slight click, then begin
tightening clockwise as you normally would.
REQUIRED TOOL
Standard Phillips Head Screwdriver
•
STEP 2.
Take apart one
Barrel Bolt Assembly,
inserting the Barrel Bolt
into the lined-up holes
( ), if the Barrel Bolt
FIGURE 2
doesn't go in easily, push
it all the way in using the
Allen Wrench.
Line up the other set of
holes, repeating this step
with a second Barrel Bolt
Assembly.
EXTREMELY
IMPORTANT:
Use ONLY
a Standard
Phillips Head
Screwdriver to
tighten Barrel
Bolt Assemblies;
using a drill can
strip the Barrel
Bolt head,
marring the
appearance of
your chair.
(NOT PROVIDED)
FIGURE 2
