DIGITAL Gigabit Ethernet Interface Module DELVM-UA User’s Guide...
Page 3
DIGITAL Gigabit Ethernet Interface Module DELVM-UA User’s Guide Part Number: 9032764 September 1998 This manual describes the DELVM-UA features. It also describes how to install and troubleshoot this device. Revision/Update Information: This is a new document.
Printed in the United States of America LANVIEW is a registered trademark of Cabletron Systems, Inc. DIGITAL and the DIGITAL logo are trademarks of Digital Equipment Corporation. All other product names mentioned in this manual may be trademarks or registered trademarks of their respective companies.
Page 5
FCC Notice — Class A Computing Device: This equipment generates, uses, and may emit radio frequency energy. The equipment has been type tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC rules, which are designed to provide reasonable protection against such radio frequency interference.
Page 6
CABLETRON SYSTEMS, INC. PROGRAM LICENSE AGREEMENT IMPORTANT: Before utilizing this product, carefully read this License Agreement. This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (the “Program”) contained in this package.
Page 7
SAFETY INFORMATION CLASS 1 LASER TRANSCEIVERS THE DELG1-UA AND DELG9-UA GIGABIT ETHERNET MODULES USE CLASS 1 LASER TRANSCEIVERS. READ THE FOLLOWING SAFETY INFORMATION BEFORE INSTALLING OR OPERATING THIS ADAPTER. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments.
DECLARATION OF CONFORMITY 89/336/EEC Application of Council Directive(s): 73/23/EEC Cabletron Systems, Inc. Manufacturer’s Name: 35 Industrial Way Manufacturer’s Address: PO Box 5005 Rochester, NH 03867 Mr. J. Solari European Representative Name: Cabletron Systems Limited European Representative Address: Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England...
Page 11
Page DELVM-UA (shown with fiber GPIMs)........1-1 Removing the VHSIM Coverplate from the Host Device..2-3 Installing the DELVM-UA in the Host Device ......2-4 GPIM ..................2-6 Installing a GPIM into the DELVM-UA........2-6 DELVM-UA Fiber Port Designations ........2-7 DELG9-UA Launch Mode Conditioning Cable Connection ..
Page 12
Table Page GPIM Options ................1-3 DELVM-UA LED Functionality ..........3-2 Physical Properties of the DELVM-UA ........A-1 Environmental Requirements of the DELVM-UA ..... A-1 Regulatory Compliance of the DELVM-UA ......A-1 Minimum Gigabit Ethernet (802.3z) Distance Specifications ... B-1 GPIM Physical Properties ............B-3 GPIM Environmental Requirements ........
User’s Guide. This manual describes the DELVM-UA and provides information concerning features, installation, troubleshooting, information on Local Management, and specifications for the DELVM-UA. The DELVM-UA is a Gigabit Ethernet interface module. This manual refers to the DELVM-UA as a VHSIM (Very High Speed Interface Module). USING THIS GUIDE A general working knowledge of Gigabit Ethernet and Draft IEEE 802.3z/D5.0 type data communications networks and their physical layer...
RELATED DOCUMENTATION The documentation for the device in which the DELVM-UA is to be installed provides additional information about the setup of the DELVM-UA. This user’s guide references procedures in these documents, where appropriate, but does not repeat them.
A description of your network environment (layout, cable type, etc.) • Network load and frame size at the time of trouble (if known) • The device history (i.e., have you returned the device before, is this a recurring problem, etc.) DELVM-UA User’s Guide xiii...
Contains information essential to avoid CAUTION damage to the equipment. Liefert wichtige Informationen, um einen ACHTUNG Geräteschaden zu vermeiden. Informations indispensables permettant ATTENTION d'éviter les dommages matériels. Contiene información esencial para evitar PRECAUCIÓN daños al equipo. DELVM-UA User’s Guide...
Klasse 1. Verwenden Sie keine optischen Geräte, um den Laserausgang zu betrachten, da dies die Gefahr für die Augen erhöhen VORSICHT würde. Wenn Sie den optischen Laserausgang betrachten wollen, muß zuvor die Stromversorgung des Netzwerkadapters ausgeschaltet werden. DELVM-UA User’s Guide...
Page 19
1. No use instrumentos ópticos para ver la salida de láser. El uso de instrumentos AVISO ópticos para ver la salida de láser aumenta el riesgo para la vista. Cuando mire al puerto óptico de salida, asegúrese siempre de haber desconectado DELVM-UA User’s Guide xvii...
Page 20
Si vous ne tenez pas compte de ces conseils, vous risquez d'endommager cet équipement. DELVM-UA, GPIM y el hub o módulo de host es sensible a la descarga estática. Utilice una banda antiestática para la muñeca y observe PRECAUCIÓN...
Page 21
PRECAUCIÓN conector, para evitar doblarlas. De lo contrario, podría deteriorar el DELVM-UA y el módulo. The DELVM-UA and the device are sensitive to static discharges. Use an antistatic wrist strap CAUTION and observe all static precautions during this procedure.
Page 22
ATTENTION alignées, afin d'éviter d'endommager l'appareil et le DELVM-UA. Al insertar el DELVM-UA en las patillas del dispositivo, asegúrese de que éstas no se PRECAUCIÓN doblen, puesto que ello podría deteriorar el dispositivo y el DELVM-UA.
Page 23
Si los extremos se contaminan, limpie su superficie con un plumero hermético. Un cepillo especial de limpieza para puertos de fibra óptica con alcohol isopropílico de calidad óptica también puede resultar útil para limpiar los extremos. DELVM-UA User’s Guide...
Module (GPIM) ports that provide Gigabit Ethernet connections. The GPIMs are hot swappable, allowing the user to reconfigure the DELVM-UA when it is installed and the host device has power applied to it. One port is active and the other is redundant. Redundancy is triggered based on link activity.
1000Base-CX is supported with the DELG4-UA providing a connection to style-2 shielded twisted pair copper cable. For more specifications on GPIMs, see Appendix The DELVM-UA operates in full duplex mode, and follows the 802.3x specifications for auto-negotiation. 1.1.2 LANVIEW Diagnostic LEDs Cabletron Systems provides a visual diagnostic and monitoring system called LANVIEW.
Overview 1.1.3 Options The options for the DELVM-UA are GPIMs, as listed in Table 1-1. The GPIMs support high speed connections at full duplex Gigabit speeds. Table 1-1 GPIM Options Part Number Description Application SC fiber Supports 50 or 62.5 micron...
The DELVM-UA and the host module or device (platform) are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. Failure to do so could result in damage to the DELVM-UA or host platform. Unpack the DELVM-UA as follows: Remove the DELVM-UA from the shipping box.
VHSIM slot and connector locations. 2.2.1 Installing the DELVM-UA in an Interface Module To install a DELVM-UA in an interface module that supports VHSIM technology, perform the following steps: Note the ports of the interface module that have cables attached to them.
Page 31
Installing the DELVM-UA The DELVM-UA and the host module are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. Failure to do so could result in damage to the DELVM-UA or host module.
Page 32
This can damage both the DELVM-UA and the module. Press down firmly on the DELVM-UA until the connectors slide all the way onto the pins. Ensure that the standoffs on the interface module align with the standoff screw holes on the DELVM-UA.
Reinstall the interface module in the chassis. Reattach the network cabling to the interface module. INSTALLING GPIMs The DELVM-UA has three different GPIMs that can be installed into the DELVM-UA. All GPIMs are installed into the DELVM-UA in the same manner, as listed in this procedure.
Page 34
Chapter 2: Installation Hold the GPIM with the network connection port facing away from the DELVM-UA. The 20-pin connector should be facing towards the empty GPIM slot, with the wide part of the connector oriented up in relation to the printing on the DELVM-UA. See...
DELG1-UA and DELG9-UA Network Connections To remove a GPIM from the DELVM-UA, squeeze both locking tabs in towards the center of the GPIM, and pull it out of the port. DELG1-UA AND DELG9-UA NETWORK CONNECTIONS The DELG1-UA and the DELG9-UA each have an SC style connector for the network port that is used to connect to the Gigabit Ethernet network.
To connect the DELG9-UA to the network using multimode fiber, perform the following steps: Connect Launch Mode Conditioning cable to the multimode fiber on both ends of the multimode cable, before connecting the DELVM-UA with a DELG9-UA to the multimode fiber cabling. See Figure 2-6.
DELG9-UA device. 2.4.2 DELVM-UA Network Connection To connect the DELVM-UA using fiber cable to the network, perform the following steps: If connecting the DELVM-UA with a DELG9-UA to the network using multimode fiber cable, refer to Section 2.4.1...
Page 38
Gigabit Ethernet compatible. Verify proper crossover of fiber strands between the port on the DELVM-UA and the fiber optic device at the other end of the fiber optic link segment. Verify that the fiber connection meets the specifications outlined Appendix B for the installed GPIM.
Figure 2-8 DELVM-UA with Two Fiber Ports Refer to Chapter 4 for information on Local Management for the DELVM-UA. If a link has not been established, refer to Chapter 3 to use the LEDs for troubleshooting before contacting a DIGITAL Representative.
Page 40
Verify proper pinouts (refer to Appendix B) for the style-2 shielded twisted pair between the port on the DELVM-UA and the device at the other end of the segment. Verify that the twisted pair connection meets the specifications outlined in...
LANVIEW LEDs This chapter describes how to use the LANVIEW LEDs to monitor the DELVM-UA status and diagnose DELVM-UA problems. Figure 3-1 shows the location of the DELVM-UA LEDs. Refer to Table 3-1 for a description of the LEDs. Section 3.2 describes redundancy.
Diagnostic failure. REDUNDANCY The DELVM-UA supports redundancy. Only one of the two ports on the DELVM-UA is active at one time. The port with link status showing (either a green LED, solid or blinking, or an amber LED) is the active port.
This chapter provides information about using Local Management with the DELVM-UA. Local Management of the DELVM-UA is done through the host platform. Since the DELVM-UA is a Gigabit Ethernet device, the Local Management screens used for configuration and statistics are the regular Ethernet screens, seen on the host platform Local Management.
Figure 4-1. NAVIGATING LOCAL MANAGEMENT SCREENS In order to view the DELVM-UA Local Management screens, you must navigate through a series of Local Management screens on the host platform. Figure 4-1 shows a typical hierarchy of screens to navigate through in order to reach the DELVM-UA statistics screens.
Page 45
Configuration VLAN Forwarding Configuration 802.1p Priority Configuration Menu Port Priority Configuration Advanced Port Priority Configuration Device Switch Statistics Statistics Menu Interface Statistics RMON Statistics HSIM/VHSIM Statistics Network Tools 2555hier Figure 4-1 Typical Hierarchy of Local Management Screens DELVM-UA User’s Guide...
APPENDIX A DELVM-UA SPECIFICATIONS This chapter lists the specifications and regulatory requirements for the DELVM-UA. Cabletron Systems reserves the right to change these specifications at any time without notice. Refer to Appendix B specifications for the optional GPIMs. PHYSICAL AND ENVIRONMENTAL...
(DELG9-UA) in 5000 meters 1000 Base-CX (DELG4-UA) in meters 1. In order to obtain the distance of 550 m for the DELG9-UA using multimode fiber, Launch Mode Conditioning cable must be used. Refer to Section 2.4.1 for details. DELVM-UA User’s Guide...
