TPL VISION ESSENTIAL EBAR+ 125 User Manual

PREAMBLE
This Technical User Guide contains warnings and guidance for correct and safe operation of the product.
These instructions must be followed at all times. TPL Vision will not be held responsible for problems
caused by using the product contrary to these instructions and the Warranty will be deemed invalid.
UNPACKING
Products are packed in our factory, using suitable materials for a safe transport through the usual means of trans-
portation, in France and internationally. However, a damaged package must be reported to the carrier on delivery.
Hand-written reservations must be indicated on the delivery order. Moreover, please send a letter or an email to TPL
Vision as soon as possible (up to 24 hours after the delivery). If the transportation damage has not been stipulated
on the delivery order and reported to TPL Vision in time, the package will not be taken back nor exchanged. To open
the package, do not use any cutting blade to avoid damaging the product(s). Please use the delivered accessories, if
needed (do not use any other products or equivalents to replace the delivered accessories).
RISK CLASS
The EN-62471 norm about lighting fluxes enables the classification of led lightings in 4 distinct groups, according to
their hazardousness degree. Please find below an indicative table, recapitulating the classes of risk for our standard
products.
Colour
White WHI, Green 525 nm, Red 630 nm
Blue 470 nm, IR 850 nm
–
UV 405 nm, UV 365 nm, UV 385 nm
TPL Vision can provide calculation notes about the nominal distance of eye risks (security distance).
BEWARE to the infrared light, invisible to the eyes.
To know if the light is on, please refer to the LED indicators.
USER GUIDE
Class Risk
0 none
1 low
2 moderate
3 high
In all cases, TPL Vision recommends
the use of the protection glasses
that are listed in its catalog.
For more information about photo-
biological risks, do not hesitate to
contact us.
