iNtrodUctioN /
This User Guide contains warnings and guidance for correct and safe operation of the product. These instructions
must be followed at all times. TPL Vision will not be held responsible for problems caused by using the product
contrary to these instructions and the Warranty will be deemed invalid.
Cette notice comporte tous les conseils et précautions permettant l'installation et l'utilisation en toute sécurité
du produit. TPL Vision se dégage de toutes responsabilités et annule l'effet de la garantie si l'un des points
décrits dans cette notice n'était pas respecté.
UNPackiNg /
This product is packed at the factory using suitable materials for safe transport. To open the package, do not use
any cutting blade to avoid damaging the product(s). Please use the delivered accessories if needed. (Do not use
any other products or equivalents to replace the delivered accessories). In the event of damage occurring during
shipping, it must be reported to the carrier at time of delivery (including noting the damage in writing on the
delivery documents). It is also your responsibility to notify TPL Vision in writing of the damage within 24 hours of
receipt of the package. If these instructions are not followed, TPL Vision reserves the right not to accept requests
for return and exchange of damaged products.
Le produit est conditionné dans notre usine en utilisant les matériaux appropriés permettant un transport sans endom-
magement en France et à l'étranger par des moyens de transport habituels. Toutefois, l'endommagement du colis
doit être signalé au transporteur à la réception du colis et stipulé par écrit à la réception de ce colis (sous  forme
de «réserve»). De plus, merci de le signaler par écrit à la société TPL VISION dans les plus brefs délais (24h à réception
du colis). Tout colis endommagé lors du transport ne sera ni repris ni échangé si cela n'a pas été signalé sur le bon
de transport et à la société TPL VISION dans les délais. Lors de l'ouverture du sachet contenant le produit, toute lame
coupante est à proscrire afin de ne pas endommager le produit. L'ensemble des accessoires livrés avec le colis doit
être utilisé si nécessaire (ne pas utiliser d'autres produits ou équivalents pour remplacer les accessoires fournis).
PréambUle
déballage
User gUide /
Notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Modular Ringlight and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TPL VISION Modular Ringlight

  • Page 1 être signalé au transporteur à la réception du colis et stipulé par écrit à la réception de ce colis (sous  forme de «réserve»). De plus, merci de le signaler par écrit à la société TPL VISION dans les plus brefs délais (24h à réception du colis).
  • Page 2 User gUide / Notice P2/12 dimeNsioNs / eNcombremeNt Length / Width / Height / Length / Width / Height / RING DARK FIELD longueur largeur hauteur longueur largeur hauteur (mm) (mm) (mm) (mm) (mm) (mm) Ring 80 Dark Field 80 27.5 Ring 130 Dark Field 130...
  • Page 3: Connexion Électrique

    M12 – 8 pôles et appliquer un signal PNP sur les pôles correspondants. Le Modular Ringlight possède un mode «Teach & Run». Pour le paramétrer, appuyez sur les boutons «colour» et «sector» de manière simultanée pendant 3-4 secondes.
  • Page 4: Continuous Mode

    User gUide / Notice P4/12 coNtiNUoUs mode mode coNtiNU (coNNectioN) (braNchemeNt) grey CONTINUOUS MODE / MODE CONTINU : gris DIM 0-10V black blue + 24 V + 24 V noir blue STROBE Ground Ground white brown blanc marron STROBE + 24 V Dim 0-10V Dim 0-10V The M12 male connector 5 points is cOMPLIANt with the M12 female connector 4 points.
  • Page 5: Remote Control

    P5/12 remote coNtrol coNtrôle à distaNce (coNNectioN) (braNchemeNt) grey/gris 1: Active overdrive /Overdrive actif 2: Change colours /Changement des couleurs pink/rose yellow/jaune 3: GND 4: Sector 1 / Secteur 1 blue/bleu green/vert 5: Sector 2 / Secteur 2 6: Sector 3 / Secteur 3 white/blanc brown/marron...
  • Page 6 User gUide / Notice P6/12 Standard mode Triggering input Mode standard Entrée déclenchement PNP/NPN Active Overdrive Overdrive actif 2 ms max 5 µs to Continuous (CW) Mode continu (CW) 5 µs overdrive Overdrive mode Mode Overdrive LED current courant Led 24 V 10 µs 10 µs...
  • Page 7: Contrôle Manuel

    P7/12 keyPad coNtrol / coNtrôle maNUel sector and colour selection • Program settings: push the 2 buttons together for 3 - 4 seconds, • Change settings: 1 push of Colour and / or Sector button(s) until desired configuration is selected, •...
  • Page 8 User gUide / Notice P8/12 sector & coloUr selectioN trigger timiNg sélectioN des secteUrs et de la coUleUr To control the LED Colour and illuminated Sector, the PNP or NPN trigger signal should be enabled in addition to the Sector or Colour control signal(s). Timing diagrams below illustrate rise, fall and delay times. If PNP and sectors are connected to 24V and if you strobe colours, there can be some delays between the trigger signal and the LED current.
  • Page 9: Power Supply

    P9/12 dimmiNg coNtrol / coNtrôle dU dimmiNg • Potential dimming between 0 & 10 V. 100% With 0V applied to the Dimming pin, the product is at 100% of its lighting power. With 10V applied, it is reduced to 30% of lighting power. •...
  • Page 10: User Safety

    User gUide / Notice P10/12 User saFety / sécUrité de l’UtilisateUr Do not modify or dismantle all or part of the ne pas modifier ou démonter tout ou une partie du produit. product. respecter les tensions d’alimentation et les Respect the power supply voltages and the bornes de connexion.
  • Page 11: Informations De Garantie

    IR 860 nm faible TPL Vision can provide guidance notes to minimise TPL Vision peut fournir des indications afin de réduire photo-biological risks, including the nominal mini- les risques photo-biologiques, y compris sur la dis- mum operating distance. Please contact TPL Vision tance nominale de risques oculaires.
  • Page 12 10 nm. Here are the following bandpass camera filters we recom- Voici la liste des filtres passe-bandes que nous recom- mend to fit with the Modular Ringlight: mandons d’utiliser avec le Modular Ringlight : • White LEDs: no filter •...
