JADEMAR LIGHTING JFPL-SOL Series Installation And Instructions

INSTALLATION KIT FOR LUMINAIRE
(1 set) Two moun ng pieces to place around the pole for desired height adjustment
SOLAR PANEL SYSTEM INSTALLATION KIT
(1 set) Two moun ng pieces to place around the pole for desired height adjustment
NOTE: The Solar Panel must be mounted below the luminaire to avoid light leakage on solar panel.
WIRE LENGTH
(6.5FT) The luminaire and solar panel connect by 6.5FT wire.
CONTROLLER AND BATTERY
• Controller Type: MPPT
BMS included
•
• DoD% of ba ery set with the controller. Ba ery low-capacity protec on, minimum 20% safety margin for
ba ery. (i.e. 80%DoD)
• Replaceable Ba ery replaceable
Replaceable Controller
•
Compartment for Ba ery (IP65 Rated) & Controller (IP68 Rated)
•
• Working mode (3 modes)
1. 100% brightness
2. 80% 3-4Hrs
3. 60% 5Hrs - Dawn 25%
Miami, FL USA - info@jademar.com
T: 305.640.0465 - F: 305.640.0468
WWW.JADEMAR.COM
JFPL-SOL SERIES
LED SOLAR FLAGPOLE LUMINAIRE
INSTALLATION KIT AND INSTRUCTIONS
Informa on contained herein is subject to change without no ce.
Values are nominal.
Revised 11/2022
Page 1 of 2
