JADEMAR LIGHTING JWP-NC-CPS Series Installation Instructions

JWP-NC STATIC NON-CUTOFF WALL PACK
PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTING INSTALLATION
• To prevent personal injury or product damage only licensed electricians should install.
• To avoid electric shock or component damage disconnect power before a emp ng installa on or servicing.
• This product must be installed in accordance with the na onal electric code (NE0) and all applicable federal, state and local electric
codes and safety standards.
• Disconnect product and allow cooling prior to servicing.
• Any altera on or modifica on of this product is expressly forbidden as it may cause serious personal injury, death, property damage
and/or product malfunc on
• To prevent product malfunc on and/or electrical shock this product must be properly grounded.
• This luminaire is designed to operate in ambient temperatures ranging from -30°C to 40°C and to be horizontally mounted with the LEDs
facing down.
MOUNTING INSTRUCTIONS: WALL MOUNT
Step 1: Take off the screw of the heat sink and take off the front lid carefully from the back. The angle between the front cap and the back cap should be 0-45
degrees. (Figure 1)
Step 2A: A er determining a place to put a conductor, take off the ½" cap and make a hole according to the example. Fix it on the wall with an appropriate screw.
(Please use glue to block the hole to prevent water leakage.)
Step 2B: When installing the junc on box, take off the ½" cap of the C wire in the middle. This product supports standard 3 ¼" and 4" junc on box. A er installing
the back cap on the wall use waterproof sealer to seal it (Figure 2)
Step 3: Connect wire A with wire C (The black one is L, white one is N, and the yellow one is ground wire), installing the front cap (Figure 3)
Step 4: Make sure all wires are connected correctly, and lock up with the screw. (Figure 4)
Figure 1
INSTALLATION OF THE PHOTOCELL
Step 1: Connect the wiring terminal between photocell and driver. (Figure 1)
Step 2A: If you need the light photocell fund on, remove the light control cover A.
CHECKING
• Do all the wires connect in a correct way as the pictures show below?
• Is the ground lead installed appropriately?
• Make sure the photocell func ons well.
Miami, FL USA - info@jademar.com
T: 305.640.0465 - F: 305.640.0468
WWW.JADEMAR.COM
INSTALLATION INSTRUCTIONS
Figure 2
Revised 12/2022
Page 1 of 2
Figure 3
WARNING
Figure 4
