Summary of Contents for Centon Elegande EL505
-
Page 2: Table Of Contents
CONTENTS Pages 1. Important Safety Information ............. 2 - 3 2. Heater Contents Checklist ..............4 3. Part Description .................. 5 4. Electrical Requirement ............... 6 5. Water Requirement ................7 6. Installation Procedures ............... 8 - 9 7. Operating The Shower ................ 10 8. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING 4) The outlet point of this heater, hose and 1) Check the RCD in this heater (refer A) & the handshower act as a vent. They must not RCD at the main switch board (refer B) of the premise at least once a month. - Page 4 CENTON and its technicians will also not be liable to reimburse back any damages or replacement cost for such removal works. SAF EGUAR DI NG THE ENVI RONMENT This product may not be treated as household waste.
-
Page 5: Heater Contents Checklist
HEATER CONTENTS CHECKLIST POWER 4 x Wall Plugs & Screw Set 1 x Heater Unit 1 x Instruction Manual & Accessory Set Content Checklist * Please refer to the Accessory Set Content Checklist (separate printed attachment). -
Page 6: Part Description
PART DESCRIPTION MODEL: ELEGANDE EL505 & ELEGANDE EL505E 1. Heater Cover 13. Double Function Thermostat 2. Power Indicator 14. Heating Element 3. RCD Indicator * 15. Indicator Board 4. Temperature Control Knob 16. Heater Tank 5. Terminal Block 17. Water OUTLET 6. -
Page 7: Electrical Requirement
ELECTRICAL REQUIREMENT WARNING THIS APPLIANCE MUST BE EARTHED Note: An approved type of Residual Current Device (RCD) of 10mA sensitivity should be installed in conjunction with the heater. Installation must be carried out by a qualified electrician. The shower heater unit must be connected to its own independent electrical circuit. Lead the power cable from the indoor fuse distributor board or Miniature Circuit Breaker (MCB) to an ‘ON/OFF’... -
Page 8: Water Requirement
WATER REQUIREMENTS PLUMBING SCHEMATIC DIAGRAM Diagram on right shows a typical system layout. Cold water system Do not use joining compounds on any pipe fittings for the installation. Stop Valve The unit works at minimum water flow rate of 2 litre/min. An incoming water flow rate of 5 litre/min and above would excel its Minimum performance. -
Page 9: Installation Procedures
INSTALLATION PROCEDURES FIXING THE SHOWER TO THE WALL CAUTION: It is important to mount the shower unit to a flat surface otherwise difficulty may be encounter when fitting the cover and subsequent. Unscrew the screw at bottom of heater and remove the cover by lifting the bottom of cover upward. -
Page 10: Plumbing Connections
INSTALLATION PROCEDURES PLUMBING CONNECTIONS CAUTION: Complete Plumbing Connections before Electrical Connection Connect the water supply to the inlet of stop valve via 15mm plastic pipe using a 15mm x 15mm elbow compression fitting. Note: i) DO NOT apply excessive force when making these connections. -
Page 11: Operating The Shower
OPERATING THE SHOWER 1. Switch on the heater switch outside the bathroom. Warning Improper earthing may results in malfunctioning of the RCD & harmful to user. Never use the heater if there is doubt on the earthing installation. 3. Turn on temperature control knob by turning it clockwise. Power indicator will turn ON. -
Page 12: User Maintenance
USER MAINTENANCE DO NOT USE THINNER, ALCOHOL OR PETROL You may clean the heater with a damp cloth and mild detergent but do not use thinner, alcohol, petrol or any other corrosive solutions. THINNER CLEAN FILTER REGULARLY It is recommended that the filter is periodically cleaned in order to maintain the performance of the shower. -
Page 13: Quality Assured
QUALITY ASSURED Centon heaters are tested before leaving the factory. With proper care and usage, the heaters are durable, safe and reliable. Use only accessories recommended by manufacturer. WARNING The appliance must be earthed. Do not use plumbing cement on connection. If necessary, use only thread or sealant tape. -
Page 14: Temperature Rise Guideline
TEMPERATURE RISE GUIDELINE Outlet Water Temperature Inlet Water Temperature Water Temperature Rise Water temperature rise depends on 3 factors: Inlet Water Temperature Heating Element Power Water Flow Rate Inlet Water Temperature Water Temperature Rise Heating Element Power Water Temperature Rise Water Flow Rate Water Temperature Rise High... -
Page 15: Specification
SPECIFICATION Model Electrical Rating – Available from 3kW - 6.0kW, 220-240Vac, 50/60Hz Minimum Water Flow Rate – 2 liters/min Minimum Water Inlet Pressure – 20kPa (0.2bar / 2.9psi) Maximum Water Inlet Pressure (Open Outlet) – 3.87kg f/cm² (55 psi) Shower Temperature Control –... -
Page 16: Accessory Installation
ACCESSORY INSTALLATION Fixed Shower Accessory Determine the suitable height for shower accessories & mark for the mounting holes. 2. Mark the mounting holes for Fixed Shower Holder. 3. Drill the mounting holes & insert Wall Plugs provided. 4. Feed the Flexible Hose by securing to the heater outlet & Handshower. 5. - Page 17 ACCESSORY SET CONTENT CHECKLIST 1 x Fixed Shower Holder 1 x Handshower 1 x Filter Mesh Washer 1 x Right Angle Stop Valve 1 x Flexible Hose 1 x Pop Start Stop Valve...
