Dimension:
MODEL: TCI-206F
INPUT: 100V
BLACK-------COM
RED------------10W
WHITE----------5W
Frequency Response(-10dB): 90-20KHz
SPL(1W/1M): 88dB
Cutout Size: Φ170mm
170mm
188mm
Installation Steps:
1
Cut Ceiling Hole
3
Retract the 2 Snap Clamps on the speaker
into their open position.
Then push the speaker up through the
ceiling opening.
When Clamp Arms press against the
ceiling, the Snap Clamps will rotate and
clamp down closed to the ceiling surface.
COAXIAL CEILING SPEAKER TCI-206F
INPUT: 100V
BLACK-------COM
RED------------10W
WHITE----------5W
Frequency Response(-10dB): 90-20KHz
SPL(1W/1M): 88dB
Cutout Size: Φ170mm
MODEL: TCI-206F
INPUT: 100V
BLACK-------COM
RED------------10W
WHITE----------5W
Frequency Response(-10dB): 90-20KHz
SPL(1W/1M): 88dB
Cutout Size: Φ170mm
2
Connect Wiring
4
When inserted correctly, both 2 Snap
Clamps will be in the snap down
position,thus securing the speaker
securely into position in the ceiling.
Coaxial Ceiling Speaker
TCI-206F
User's Manual
