Dimension:
Φ210
Φ232
Installation Steps:
Cut Ceiling Hole
1
3
Retract the 2 Snap Clamps on the speaker
into their open position.
Then push the speaker up through the
ceiling opening.
When Clamp Arms press against the
ceiling, the Snap Clamps will rotate and
clamp down closed to the ceiling surface.
COAXIAL CEILING SPEAKER TCI-208F
Φ232mm
┐╠╚ 25.400
2
Connect Wiring
4
When inserted correctly, both 2 Snap
Clamps will be in the snap down
position,thus securing the speaker
securely into position in the ceiling.
Coaxial Ceiling Speaker
TCI-208F
User's Manual
Advertisement
Related Manuals for TCi TCI-208F
Summary of Contents for TCi TCI-208F
- Page 1 COAXIAL CEILING SPEAKER TCI-208F Dimension: Φ232mm Φ210 Coaxial Ceiling Speaker Φ232 ┐╠╚ 25.400 Installation Steps: TCI-208F Cut Ceiling Hole Connect Wiring User’s Manual Retract the 2 Snap Clamps on the speaker When inserted correctly, both 2 Snap into their open position.
- Page 2 COAXIAL CEILING SPEAKER TCI-208F COAXIAL CEILING SPEAKER TCI-208F Features: Dear customers: Your use of the this speaker series,we would like to extend my heartfelt thanks to you, the commitment to keep its quality. Compact size with new rimless design. ※...
