Safety and Installation Instructions
This document applies to Maxeon PV modules
This  document  includes  references  to  X‐Series,  MAX3  and  MAX6  modules.
These modules do not have grounding restrictions and all are compatible with
high‐efficiency transformerless inverters.
Contents of this manual are subject to change without notice.
For the latest version please refer to https://www.maxeon.com/us/InstallGuideUL






United States
listed in Table 1.







Maxeon Solar Technologies, Ltd.
www.maxeon.com








Document 544753   Rev.B

Advertisement

loading
Need help?

Need help?

Do you have a question about the X Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Maxeon X Series

  • Page 1                       Safety and Installation Instructions     United States    This document applies to Maxeon PV modules   listed in Table 1.       This  document  includes  references  to  X‐Series,  MAX3  and  MAX6  modules.    These modules do not have grounding restrictions and all are compatible with  high‐efficiency transformerless inverters.      Contents of this manual are subject to change without notice.         For the latest version please refer to https://www.maxeon.com/us/InstallGuideUL   ...
  • Page 2: Safety And Installation Instructions

    Maxeon  installation  instructions  and  Switch off the inverter before disconnecting, reinstalling or making any action  operations  and  maintenance  instructions  of  any  type,  as  may  be  amended  and  with the modules.  updated  from  time  to  time  at  Maxeon’s  sole  discretion,  and  all  national,  state,   For connectors, which are accessible to untrained people, it is imperative to  and local laws, codes, ordinances, and regulations); (iii) repair or modification by  use the locking connectors and safety clips, if applicable, in order to defend ...
  • Page 3: Module Mounting

      MAXEON SOLAR TECHNOLOGIES, LTD.    Safety and Installation Instructions ‐ Document 544753 Rev.B      irradiance per IEC 60904‐3 or irradiation of (air mass) AM 1.5 global (G) spectrum.  sunlight and do not place the connector in a location where water could easily  Each module contains three bypass diodes. The maximum series fuse rating is  accumulate. Installers must refer to connector manufacturer’s instruction for  15A(X‐Series), for MAX3 and MAX6 modules it is 20A  further installation and connection requirements.  Under normal conditions, a photovoltaic module may experience conditions that  Connectors are factory assembled with intentional gaps between the cable nut  produce more current and/or voltage than reported at Standard Test Conditions.  and the body of the connector. Do not retighten module connector nuts as this  Accordingly, the values of ISC and VOC marked on UL Listed modules should  may lead to stress cracking of the connector assembly and will void the warranty.  always be multiplied by a factor of 1.25 when determining component voltage    ratings, conductor capacities, fuse sizes and size of controls connected to the  4.1 Equipment Grounding  module output. Refer to Section 690‐8 of the NEC for an additional 1.25 Safety  To reduce the possibility of electrical shock, ground the frame of the module or  factor which may be applicable.   array per NEC before wiring the circuit. In order to install in accordance with their    UL Listing, Maxeon modules must be grounded using grounding hardware that  Table 1: Electrical Characteristics   meets requirements for grounding systems in UL 61730 and UL 61215 on  anodized aluminum frames. Maxeon recommends to refer to the applicable  Voltage  Open  Short  Rated  Current  Current  Voltage  Power  regional and local codes and requirements on grounding PV arrays and mounting  at Rated ...
  • Page 4: Mounting Configurations

    Modules are designed for a maximum altitude of 2000 m.  allowed location should be according  top frame flange or   glass may break Force to Appendix. Installers should ensure  Excluded Operating Environments    has to the clamps are of sufficient strength  Certain operating environments are not recommended for Maxeon modules, and  to allow for the maximum design  applied are excluded from the Maxeon Limited Warranty. No Maxeon module should be  pressure of the module. Clamps are  in line mounted at a site where it may be subject to direct contact with salt water, or  with not provided by Maxeon. Clamps must  other aggressive environment.  frame apply force collinear with the ‘wall’ of  Modules should not be installed near flammable liquids, gases, or locations with  wall the module frame and not only to the  hazardous materials; or moving vehicles of any type.  Figure 1a: Clamp Force Locations top flange. Clamps shall not apply ...
  • Page 5: Module Handling

      MAXEON SOLAR TECHNOLOGIES, LTD.    Safety and Installation Instructions ‐ Document 544753 Rev.B      disclaims all warranties, express or implied, applicable to those modules    should they be damaged in any way by such clamps. Therefore, the use of  the above mentioned clamps by the Installer is at the Installer's sole risks.      5.2 Module Handling Do not place modules face forward in direct contact with abrasive surfaces like  roofs, driveways, wooden pallets, railings, stucco walls, etc…  The module front surface glass is sensitive to oils and abrasive surfaces, which  may lead to scratches and irregular soiling.  During storage, modules need to be protected from rain or any kinds of liquids.  Required storage temperature is between 10°C to 40°C in a dry environment  (humidity between 30 to 80%). Do not store modules outdoor to avoid moisture  and wet conditions.    Modules that feature antireflective coated glass are prone to visible finger print  marks if touched on the front glass surface. Maxeon recommends handing  modules with anti‐reflective glass with gloves (no leather gloves) or limiting  touching of the front surface.  Any finger print marks resulting from installation  will naturally disappear over time or can be reduced by following the washing  guidelines in Section 6.0 below. Any module coverage (colored plastic tarps or  similar) during installation can lead to permanent front glass discoloration and is  not recommended. The use of vacuum lifting pads can cause permanent marks  on the front glass. Never lift or move the module using the cables or the junction  box under any‐circumstances.  System energization and shutdown procedures need to be followed based on  respective National guidelines and local regulations. Safe site operational  practices must be adhered before energizing the PV system (e.g. electrical  continuity, avoiding direct contact with electrical/framing equipment, wearing  safety PPE, etc.). System should be electrically disconnected during maintenance,  upgrades, and modification works which can affect the operation of PV system.  Systems should be disconnected in any cases of maintenance which can cause  shading (e.g. chimney sweeping, any roof maintenance, antenna/dish  installations, etc).       ...
  • Page 6   MAXEON SOLAR TECHNOLOGIES, LTD.    Safety and Installation Instructions ‐ Document 544753 Rev.B      Recommended Cable Managemen Maxeon Product Line: Portrait Stringing Leapfrog Stringing (Portrait) Landscape Stringing *The image is for illustration purposes only         © 2022 Maxeon Solar Technologies, Ltd. All rights reserved. Specifications included in these instructions are subject to change without notice.   Page | 6...
  • Page 7 5 In the cases where hybrid moun ng is necessary (combina on of long and short side moun ng), the lowest par es, unless there is a formal authoriza on by Maxeon. design load values should be considered as allowable design load.
  • Page 8 The design loads listed in this table supersede all other loads that may be defined by other moun ng), the lowest design load values should be considered as allowable design load. par es, unless there is a formal authoriza on by Maxeon. 5 Bo om flange moun ng.
  • Page 9 5 In the cases where hybrid moun ng is necessary (combina on of long and short side moun ng), the lowest par es, unless there is a formal authoriza on by Maxeon. design load values should be considered as allowable design load.
  • Page 10 5 In the cases where hybrid moun ng is necessary (combina on of long and short side moun ng), the lowest par es, unless there is a formal authoriza on by Maxeon. design load values should be considered as allowable design load.
  • Page 11 5 In the cases where hybrid moun ng is necessary (combina on of long and short side moun ng), the lowest par es, unless there is a formal authoriza on by Maxeon. design load values should be considered as allowable design load.
