DEWESOFT DS-MS-100 Product Manual

100 n ms shaker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model DS-MS-100
100 N MS Shaker
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-MS-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEWESOFT DS-MS-100

Summary of Contents for DEWESOFT DS-MS-100

  • Page 1 Model DS-MS-100 100 N MS Shaker Product Manual...
  • Page 2 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Product Support If at any time you have questions or problems with the DS-MS-100 shaker, please contact a DEWESoft engineer at: DEWESOFT d.o.o.

  • Page 3: Table Of Contents

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ............................4 2) General Information ..........................4 2.1) Unpacking and Inspection ......................4 2.2) System Components ........................

  • Page 4: Introduction

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 1) Introduction The DS-MS-100 is designed to provide dynamic force excitation for vibration and shock testing of small sized mechanical structures.
  • Page 5 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. DS-MS-100 has a moving coil (driving coil) whose current is controlled for vibration generation. The stationary magnetic field is produced by a permanent magnet.

  • Page 6: Specifications

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.4) Specifications Parameters Specifications Output Force (Sinus) 100 N Frequency 0-7.5 kHz Displacement (Peak to Peak) 10 mm Suspension Carbon Fiber Maximum Acceleration...

  • Page 7: Outline Drawing

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.5) Outline Drawing The dimensional properties of DS-MS-100 shakers are given below.

  • Page 8: Operation And Installation

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3) Operation and Installation 3.1) General The general shaker connector configuration is given below. 3.1.1) External Signal Mode Connect DC power source and drive signal to shaker power input and signal input respectively.

  • Page 9: Internal Signal Mode

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.1.2 ) Internal Signal Mode The amplifier can generate sine signal from 1Hz to 15 kHz with 1 Hz increments that the user can adjust with the Sine Frequency Generator Switch.

  • Page 10: Shaker-Structure Interaction (Stingers)

    Force or impedance head sensors can be mounted on the other side. The Dewesoft modal shakers stinger sets include 4 collet, 1 nut and 3 stinger rod sizes .The chuck consists of two pieces. The collet squeezes the stinger with the tightening effect of the nut.

  • Page 11: Shaker Mounting

    Additional inertial weight may be attached to the bottom of the shaker using hot glue. 3.5) Power Requirements DS-MS-100 has an integrated power amplifier which is powered by its power adaptor. Please note the output voltage and current ratings of the adaptor in a replacement adaptor is to be used.

  • Page 12: Frequency Response

    4 ) Maintenance and Troubleshooting The DS-MS-100 shaker is a sealed device requiring no maintenance if the operating instructions described in this manual are followed. Repair of damage to the coil, exciter body or magnet core should not be attempted.
