DEWESOFT DS-IS-10 Product Manual

10 n inertial shaker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model DS-IS-10
10 N Inertial Shaker
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-IS-10 and is the answer not in the manual?

Questions and answers

Related Manuals for DEWESOFT DS-IS-10

Summary of Contents for DEWESOFT DS-IS-10

  • Page 1 Model DS-IS-10 10 N Inertial Shaker Product Manual...
  • Page 2 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Product Support If at any time you have questions or problems with the DS-IS-10 shaker, please contact a DEWESoft engineer at: DEWESOFT d.o.o.

  • Page 3: Table Of Contents

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ............................4 2) General Information ..........................4 2.1) Unpacking and Inspection ......................4 2.2) System Components ........................

  • Page 4: Introduction

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 1) Introduction The inertial shaker (DS-IS-10) is used for relatively small structures requiring excitation in low frequency bands. The shaker is directly connected to the structure and the inertia motion of the shaker mass provides the necessary forces to the structure.

  • Page 5: Theory Of Operation

    The moving element can be a coil or magnet depending on the design requirements. The moving element is usually suspended by an elastic spring. DS-IS-10 has a stationary coil (drive coil) whose current is controlled to produce vibration. The stationary magnetic field is produced by a magnet.

  • Page 6: Specifications

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.4) Specifications Parameters Specifications Excitation Type Vertical or Horizontal Output Force (Sinus) 10 N Frequency 10-3000 Hz Displacement (Peak to Peak) 5 mm Moving Mass 0.1 kg...

  • Page 7: Outline Drawing

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.5) Outline Drawing The dimensional properties of DS-IS-10 shakers are given below. All dimensions are in mm’s.

  • Page 8: Operation And Installation

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3) Operation and Installation 3.1) General The general shaker connector configuration is given below. The Gain Knob is a push-pull and rotational switch. The amplifier is in External Signal Mode when the Gain Knob is pushed in and the amplifier is in Internal Signal Mode when it is pulled out.

  • Page 9: Internal Signal Mode

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.1.2-) Internal Signal Mode: The amplifier can generate sine signal from 1Hz to 15kHz with 1 Hz increments that the user can adjust with the Sine Frequency Generator Switch.

  • Page 10: Power Requirements

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.2) Power Requirements DS-IS-10 has an external power amplifier which is powered by its power adaptor. Please note the output voltage and current ratings of the adaptor if a replacement adaptor is to be used.

  • Page 11: Mounting Interface

    3.5) Mounting Interface 4) Maintenance and Troubleshooting The DS-IS-10 shaker is a sealed device requiring no maintenance if the operating instructions described in this manual are followed. Repair of the coil, exciter body or magnet core should not be attempted. Please return the shaker to Dewesoft for proper repair.
  • Page 12 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors.
