Model DS-MS-250
250 N MS Shaker
Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-MS-250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEWESOFT DS-MS-250

Summary of Contents for DEWESOFT DS-MS-250

  • Page 1 Model DS-MS-250 250 N MS Shaker Product Manual...
  • Page 2 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Product Support If at any time you have questions or problems with the DS-MS-250 shaker, please contact a DEWESoft engineer at: DEWESOFT d.o.o.

  • Page 3: Table Of Contents

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ............................4 2) General Information ..........................4 2.1) Unpacking and Inspection ......................4 2.2) System Components ........................

  • Page 4: Introduction

    The moving element is usually suspended by an elastic membrane. DS-MS-250 has a moving coil (driving coil) whose current is controlled for vibration generation. The stationary magnetic field is produced by a...
  • Page 5 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Item Description Amplfier Input Cooling Port Trunnion Handle...

  • Page 6: Specifications

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.4) Specifications Parameters Specifications Output Force (Sinus) 250 N Frequency 0-5 kHz Displacement (Peak to Peak) 25 mm Suspension Spring Maximum Acceleration...

  • Page 7: Outline Drawing

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.5) Outline Drawing The dimensional properties of DS-MS-250 shakers are given below.

  • Page 8: Operation And Installation

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3) Operation and Installation 3.1) General Refer to the figure below that shows the shaker connector configuration. Connect the shaker/amplifier cable to the shaker and amplifier.

  • Page 9: Amplifier

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.2) Amplifier DS-MS-250 uses an external power amplifier for drive signal amplification. Please note the wiring of the power amplifier given below.

  • Page 10: Amplifier Internal Signal

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.2.2 ) Amplifier Internal Signal The amplifier can generate sine signal from 1Hz to 15kHz with 1 Hz increments that the user can adjust with the Sine Frequency Generator Switch.

  • Page 11: Amplifier Maintenance And Troubleshooting

    Force or impedance head sensors can be mounted on the other side. The Dewesoft modal shakers stinger sets include chuck and 3 stinger rod sizes. The chuck consists of two pieces. The collet squeezes the stinger with the tightening effect of the nut.

  • Page 12: Shaker Alignment

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.4) Shaker Alignment Shaker alignment is a very important step of modal testing. Poor alignment can cause force components in unmeasured directions and can even damage the shaker.

  • Page 13: Cooling

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.6) Cooling DS-MS-250 does not require forced cooling up to 125N operation. In order to achieve full performance level of 250N use the cooling unit supplied with the shaker.

  • Page 14: Shaker Maintenance And Troubleshooting

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 4 ) Shaker Maintenance and Troubleshooting The DS-MS-250 shaker is a sealed device requiring no maintenance if the operating instructions described in this manual are followed. Repair of damage to the coil, exciter body or magnet core should not be attempted.
