  • Page 1 Model DS-IS-5 5 N Inertial Shaker Product Manual...
  • Page 2 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Product Support If at any time you have questions or problems with the DS-IS-5 shaker, please contact a DEWESoft engineer at: DEWESOFT d.o.o.

  • Page 3: Table Of Contents

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Table of Contents 1) Introduction ............................4 2) General Information ..........................4 2.1) Unpacking and Inspection ......................4 2.2) System Components ........................

  • Page 4: Introduction

    The moving element can be a coil or magnet depending on the design requirements. The moving element is usually suspended by an elastic spring. DS-IS-5 has a stationary coil (drive coil) whose current is controlled to produce vibration. The...
  • Page 5 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. Item Description Shaker Head Shaker Body Signal Output DC Power Input Sine Freq Gain Knob External Signal Input LCD Display...

  • Page 6: Specifications

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.4) Specifications Parameters Specifications Excitation Type Vertical or Horizontal Output Force (Sinus) Frequency 10-1000 Hz Displacement (Peak to Peak) 0.5 mm Moving Mass 0.05 kg...

  • Page 7: Outline Drawing

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 2.5) Outline Drawing The dimensional properties of DS-IS-5 shakers are given below. All dimensions are in mm’s.

  • Page 8: Operation And Installation

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3) Operation and Installation 3.1) General The general shaker connector configuration is given below. The Gain Knob is a push-pull and rotational switch. The amplifier is in External Signal Mode when the Gain Knob is pushed in and the amplifier is in Internal Signal Mode when it is pulled out.

  • Page 9: Internal Signal Mode

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.1.2-) Internal Signal Mode: The amplifier can generate sine signal from 1Hz to 15kHz with 1 Hz increments that the user can adjust with the Sine Frequency Generator Switch.

  • Page 10: Power Requirements

    3.4) Frequency Response The DS-IS-5 has a relatively flat force response of 5N after 140Hz and can achieve 5N at approximately 50 Hz. The following figure shows the Force (Newton) over applied Voltage (Volt) frequency response of DS-IS-5.

  • Page 11: Force Transducer Mounting

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 3.5) Force Transducer Mounting The DS-IS-5 has a 10-32 UNF screw interface for force transducer mounting. Simply remove the Shaker Head by turning it counter clockwise and mount the force transducer.
  • Page 12 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. NEVER APPLY FORCE ON THE SHAKER BODY TO REMOVE THE SHAKER FROM THE MOUNTING SURFACE!
  • Page 13 All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. ALWAYS USE A WRENCH AT THE FORCE TRANSDUCER TO REMOVE THE SHAKER FROM THE MOUNTING SURFACE!

  • Page 14: Maintenance And Troubleshooting

    All rights reserved. Reproduction or issue to third parties in any form whatsoever is not permitted without written authority from the proprietors. 4) Maintenance and Troubleshooting The DS-IS-5 shaker is a sealed device requiring no maintenance if the operating instructions described in this manual are followed. Repair of the coil, exciter body or magnet core should not be attempted.
