- Page 1 INSTALLER MANUAL Wood Stove ©2024 CADEL srl | All rights reserved - Tutti i diritti riservati HUBLOT wood - FLOS wood...
-
Page 2: Table Of Contents
5 EXAMPLES OF CORRECT INSTALLATION ..8 6 INSTALLATION ..........10 6.1 INTRODUCTION .............10 6.2 OVERALL DIMENSIONS .........12 6.3 GENERAL INSTALLATION ........13 6.4 ELECTRIC CONNECTION .........14 7 MAINTEINANCE ..........15 7.1 INTRODUCTION .............15 7.2 FUME PASSAGES CLEANING ........15 7.3 FANS CLEANING ............16 HUBLOT Wood - FLOS Wood... -
Page 3: Manual Simbology
REMOVING THE STOVE FROM THE PALLET Proceed as follows: Fig. 1 - Bracket removal • Remove the brackets which secure the feet of the stove (see Fig. 1). Then remove the stove from the pallet. HUBLOT Wood - FLOS Wood... -
Page 4: Stove Handling
The Manufacturer declines all liability for malfunctions caused by a badly sized and non-compliant smoke expulsion system. CHIMNEY COMPONENTS Fig. 2 - Chimney components LEGEND Fig. 2 Chimney pot Fume outlet Chimney flue Termal insulation External wall Chimney union Fume pipe Heat generator Inspection door T-union with inspection plug HUBLOT Wood - FLOS Wood... -
Page 5: Smoke Duct (Smoke Fitting) Ø 150 Mm
• The chimney flue must be provided CE in accordance with EN 1443 regulation. Please find attached an example of label: HUBLOT Wood - FLOS Wood... -
Page 6: Chimney Pot
The flow of air between the outside and the installation room can take place with a free air inlet or by channelling the air directly to the outside (***). The free air inlet must be: • be made at floor level and in any case not higher than the height of the appliance; HUBLOT Wood - FLOS Wood... - Page 7 Fig. 6 - Direct air inflow Fig. 7 - installation LEGEND Fig. 6|Fig. 7 Room to ventilate External air inlet Shield grid Curve inlet to turn downwards HUBLOT Wood - FLOS Wood...
-
Page 8: Examples Of Correct Installation
Fig. 8 - Example 1 LEGEND Fig. 8 Insulating material Exhaust stub pipe Inspection plug Minimum safety distance = 0,5 mt Damper • Chimney flue installation Ø150 mm with an enlarged drilling for pipe transit. HUBLOT Wood - FLOS Wood... - Page 9 Minimum safety distance = 0,5 mt Inclination ≥ 3° Level section ≤ 1 mt Damper • Old chimney flue with an inserted pipe of minimum Ø150 mm and with an external door which enables the chimney cleaning. HUBLOT Wood - FLOS Wood...
-
Page 10: Installation
• the appliance is connected to a smoke expulsion system correctly sized according to EN 13384-1, which is resistant to soot fire and which complies with the distances prescribed by the combustible materials indicated on the plate data; HUBLOT Wood - FLOS Wood... - Page 11 Consequently, there will be more draughts of cold air in the room, thus making it more comfortable and increasing the overall efficiency of the system. The sealed stove in a sealed installation is compatible with the presence of forced ventilation or premises that might have negative pressure with respect to the outside. HUBLOT Wood - FLOS Wood...
-
Page 12: Overall Dimensions
OVERALL DIMENSIONS Fig. 11 - Overall dimensions: HUBLOT Wood POS. Fig. 11 Exhaust fumes d.15 cm Hole combustion air inlet d.8 cm HUBLOT Wood - FLOS Wood... -
Page 13: General Installation
Fig. 12 Exhaust fumes d.15 cm Hole combustion air inlet d.8 cm GENERAL INSTALLATION • According to the choosed model, the wood stove can be installed apart, pulled over a wall or recessed between two walls. HUBLOT Wood - FLOS Wood... -
Page 14: Electric Connection
• Please further assure you that your network is endowed with an efficient earth connection: if it does not exist or if it is not efficient, please endow you with one in compliance with the law. HUBLOT Wood - FLOS Wood... -
Page 15: Mainteinance
• Scrape and vacuum the combustion residues at the bottom of the stove (see Fig. 15). • Unscrew the air conveyor (see Fig. 16). Fig. 17 - . Fig. 18 - . Fig. 19 - . • Pull out the top tile (see Fig. 17). HUBLOT Wood - FLOS Wood... -
Page 16: Fans Cleaning
Ignition difficulties Lack of chimney Open the registers completely. (If the problem persists, contact and draught expert stove repairer who will check the chimney flue efficiency). Ambient without air Create immediately a ventilation grid. recycling HUBLOT Wood - FLOS Wood... - Page 17 Bad quality fuel Use fuel described in Too much wood in the heart (red Close all registers and open the oven door in order to have a faster Cooker overheating coloured plate or cooling. oven over 300°C) HUBLOT Wood - FLOS Wood...
-
Page 18: Features
80 mm MUM LENGTH 2 m) DISTANCE FROM COMBUSTIBLE MATERIAL (back/side/bottom) 320 / 350 / 0 mm 320 / 350 / 0 mm DISTANCE FROM COMBUSTIBLE MATERIAL (ceiling/front) 750 / 1100 mm 750 / 1100 mm HUBLOT Wood - FLOS Wood... - Page 19 80 mm MUM LENGTH 2 m) DISTANCE FROM COMBUSTIBLE MATERIAL (back/side/bottom) 320 / 350 / 0 mm 320 / 350 / 0 mm DISTANCE FROM COMBUSTIBLE MATERIAL (ceiling/front) 750 / 1100 mm 750 / 1100 mm HUBLOT Wood - FLOS Wood...
- Page 20 Rev. 00- 2024 CADEL srl www.cadelsrl.com 31025 S. Lucia di Piave - TV www.free-point.it Via Martiri della Libertà, 74 - Italy Tel. +39 0438 1520200...
