Instruction Manual
Washing Machine
Twin Tub
Model
LTT H0JWT
Thank you for purchasing a Hitachi twin tub washing
machine.
■ P lease read this Instruction Manual carefully for proper
operation of the machine.
■ P lease keep this Instruction Manual for future reference.
Contents
1. Safety Precaution ......................................... 3
2. Precautions for Proper Use ........................... 6
3. Installation ................................................... 7
4. Usage method ............................................. 7
5. Structure Instruction .................................... 9
6. Usage method ............................................. 10
7. Various Washing Modes .............................. 12
8. Hints for Effective Washing ......................... 13
9. Maintenance ................................................ 14
10. Before Calling for Service .......................... 14
11. After-Sales Service and Warranty .............. 15
For household use only
HK only
EN
Advertisement
Table of Contents
Related Manuals for Hitachi LTT H0JWT
Summary of Contents for Hitachi LTT H0JWT
-
Page 1: Table Of Contents
9. Maintenance ..........14 10. Before Calling for Service ......14 11. After-Sales Service and Warranty ....15 Thank you for purchasing a Hitachi twin tub washing For household use only machine. ■ P lease read this Instruction Manual carefully for proper operation of the machine. - Page 2 Please read this instruction manual first! Dear Customer, Thank you for choosing Hitachi product. We hope that you get the best results from your product which has been manufactured with high quality and state-of-the-art technology. Therefore, please read this entire instruction manual and all other accompanying documents carefully before using the product.
-
Page 3: Safety Precaution
1. Safety Precaution Examples of Warning Pictographs: • The “ ” marks indicate “warnings This washing machine is designed for and precautions to which all home use only. Before operating the users must pay and direct their washing machine, please read these safety attention.”... - Page 4 If the spin basket does not stop Never put any of the following within 15 seconds after opening things into the wash tub or spin its lid during the spin cycle, basket: kerosene, gasoline, immediately stop using the machine benzene, alcohol, thinners, or and contact an authorized service clothes wet with any of these dealer to request repair.
- Page 5 Place the inner spin cover (for Do not use the unit when the power spinning operation) in the spin cord or power plug is damaged, or the plug insertion in the socket is basket correctly when you spin-dry laundry. loose. Balancer •...
-
Page 6: Precautions For Proper Use
Close the washer lid, if necessary, when washing Do not wash, rinse or spin dry the water splashes. water proof sheets and clothes (e.g., sleeping bag, diaper cover, Put this cover on the washing tub. sauna suit, wet suit, rain coat and covers for bicycles motorcycles and cars). -
Page 7: Installation
● Change the position of the drain hose To select the water supply selector, select the washing or drying side by moving the water outlet The ex-factory installation position of the drain adjustment all the way to the end. (Do not leave hose is located at the wash side. - Page 8 Attachment: Reference of laundry quantity corresponding to different capacities Laundry Shirt Uniform Jeans Jacket about 500 g about 650 g about 900 g about 1600 g Capacity 2.0 kg about 4 pcs. about 3 pcs. about 2 pcs. about 1 pcs. 3.0 kg about 6 pcs.
-
Page 9: Structure Instruction
5. Structure Instruction Name Of Parts Spin cover Wash cover Safety cover Wash tub Spin basket Lint filter Frame Pulsator Power plug Cabinet Drain hose Base Accessories Inner spin cover Water inlet hose Hose clamp (1 Piece) (1 Piece) (1 Piece) Introduction Of Control Panel water supply selector Wash selector... -
Page 10: Usage Method
6. Usage method Quick Start 2. Put detergent and laundry 1. Install the washing machine into wash tub 4. Turn wash timer knob to 3. Fill water into wash tub set wash time 5. Turn drain selector knob to 6. Repeat water filling and step “Drain”... -
Page 11: Spinning Method
n Recommendable spinning time: Spin time Laundry Spinning time Linen (cotton, towel, etc.) 3-5 min. Underwear (cotton) 2-4 min. Spinning Method Shirt (blended yam fabric) 1-2 min. 1. Shake out the laundry and put them into the Thin clothes (chemical fibers) 1 min. -
Page 12: Various Washing Modes
7.2 When washing blanket • It the washer makes any abnormal noise during the spin cycle, atop the spinning operation end n Machine-washable blankets are as follows: spread the laundry uniformly Inside the spin • Those blankets that are labeled with “Hand basket once again. -
Page 13: Hints For Effective Washing
Main Technical Parameters Capacity Input Power Power Overall Maximum Model No Supply dimension weight Wash Spin Wash Spin water pressure 220-240V LTT H0JWT 10.5kg 8.0kg 0.03-0.1Mpa 895x485x1,020(mm) 25kg 380-440W 250-270W 50Hz 13 / EN Washing Machine / Instruction manual... -
Page 14: Maintenance
9. Maintenance Cleaning the lint filter ● Press the button head, and pull the lint filter out. Attention To Maintenance ● Clean lint filter and rinse it. Cabinet maintenance ● Insert lint filter into place . After using the washing machine,wipe the moisture Button head and stain on it with a piece of soft cloth.To avoid damage to the surface, do not use corrosive or... -
Page 15: After-Sales Service And Warranty
Please describe any easy-to see building, Product’s name Electric Washing Machine Your address sings, etc. in your neighborhood as well Model Type Your Name LTT H0JWT Your Telephone Date of Purchese Trouble & Please specify it in detail as much as Request date for Problem possible. - Page 16 Arcelik Hitachi Home Appliances (Thailand) Ltd. 2WPL18750A...
