Operating & Installation Instructions
EN
Fully Automatic Washing Machine
Model SF-P75XB
Thank you for purchasing a Hitachi fully automatic washing machine.
■
Please read these operating & installation instructions carefully for proper
operation of the machine.
■
Please keep these operating & installation instructions for future reference.
Contents
2
2
5
6
8
9
14
21
21
23
24
25
30
30
Advertisement
Table of Contents
Related Manuals for Hitachi SF-P75XB
Summary of Contents for Hitachi SF-P75XB
-
Page 1: Table Of Contents
Troubleshooting Error Codes How to Install the Washing Machine Customer Service Specifications Thank you for purchasing a Hitachi fully automatic washing machine. ■ Please read these operating & installation instructions carefully for proper operation of the machine. ■ Please keep these operating & installation instructions for future reference. -
Page 2: Environmentally Friendly Waste Disposal
Environmentally Friendly Waste Disposal Disposing of the The shipping package has protected your new washing machine on its way to your home. All materials are ecologically harmless and recyclable. packaging Please contribute to a better environment by disposing of packaging materials in an environmentally conscious manner. - Page 3 Safety Instructions Warning Issues which could cause death or serious injury. ■ Do not dismantle, repair or modify the washing machine. General safety ÆThis could cause malfunction, fire, electric shock or injury. ÆContact your local service center for repairs. ■ Do not put fire sources or anything inflammable in or near the washing machine (gas, diesel, petroleum, thinner, alcohol, or clothes stained with these substances).
- Page 4 ■ Do not put heavy objects, liquid-filled containers or equipment which produces heat on the washing machine. SF-P75XB ÆThis may damage the washing machine or its top. ■ If detergent, fabric softener or bleach spills on the surface of the machine, Care and clean it up with a damp cloth immediately.
-
Page 5: Parts And Accessories
Parts and Accessories Detergent Into the Tub Softener Dispenser Power Cord Liquid Load Balancer Lid Lock Lint Filter (cassette type) Pulsator Adjustable Foot Control Panel Attachments Check that the followings are contained in the washer package. If not provided, please contact your retailer immediately. Rat Guard (3 pieces) Water supply hose x 1... -
Page 6: Control Panel And Display
Control Panel and Display While using the control panel (lid open) display Press this button to switch power on and off. The washing machine Power button automatically switches off when operations are finished. The washing machine also turns off automatically if it is not operated or no button is pressed for 10 minutes after the power has been turned on. - Page 7 Control Panel and Display LED multi function Display Delay Timer indicator Lights in the Delay Timer mode. Lid Lock indicator Locks the lid during the start. The lid cannot be opened while this indicator is lighted. To release the lock, press the Start/Pause button to pause operation.
-
Page 8: Before You Start Washing
Before You Start Washing ■ Preparation of Remove any foreign objects (coins, safety pins, etc.). ■ Put delicate clothes (knits, lingerie, etc.) in a net. the laundry ■ Remove large lumps of lint, mud, sand, hair, and pet hair from laundry. ■... -
Page 9: How To Use The Washing Machine
Do not exceed the maximum load. ■ Laundry shall not exceed this line. Otherwise, laundry may jump out SF-P75XB Press the Power button to turn on the power ■ If no program is selected within 10 minutes, the washing machine automatically switches itself off. - Page 10 How to Use the Washing Machine Put detergent into the Tub and close Lid ■ The amount of detergent is based on a single 35-gram scoop of powder detergent. Since the required amount of detergent varies depending on the type of detergent, follow the instructions on the package of detergent.
- Page 11 How to Use the Washing Machine Program ends ■ The alarm sounds when a program ends. Press the Water Level button for 3 seconds to deactivate the alarm or to change the sound in the following way Melody Mono *initial setting ■...
- Page 12 How to Use the Washing Machine How to Wash 1. Prepare the laundry. ■ the Blanket Fold large items, such as quilts or blankets, as follows. They should not be taller than 25 cm after they are folded. 25 cm About 25 cm If it exceeds 25 cm, use a laundry net, which is sold separately.
- Page 13 How to Use the Washing Machine ■ Use this program separately from other washing programs. (Do not put How to use laundry into the tub.) the Tub Clean 1. Press the Power button to turn on the power. program 2. Select the Tub Clean program. 3.
-
Page 14: List Of Programs
List of Programs : Default settings : Changeable settings (via corresponding button) Program Fuzzy Powerful Speedy Maximum P75XB 7.5 kg 3 kg load 25 to 59 L (Automatically) 35 L Amount P75XB of water 25 to 59 L 25 to 59 L 15 min 18 min 3 min... - Page 15 List of Programs : Default settings : Changeable settings (via corresponding button) Soak Program Fragrance 1 hrs 3 hrs 5 hrs Maximum P75XB 7.5 kg 6 kg load 25 to 59 L (Automatically) 59 L Amount P75XB of water 25 to 59 L 25 to 59 L 15 min 60 min...
- Page 16 List of Programs : Default settings : Changeable settings (via corresponding button) Program Water Save Energy Save Small Load Maximum P75XB 7.5 kg 7.5 kg 0.6 kg load 25 to 50 L (Automatically) 25 to 59 L (Automatically) 25 L Amount P75XB of water...
- Page 17 Amount of detergent is indicated according to following table as a guide. Load (guide) Water Level Detergent (guide) Amount of detergent 6~7.5 kg 50~59 L 1.0~1.1 cup 33~39 g (SF-P75XB) 4~6 kg 40~59 L 0.8~1.1 cup 27~39 g 2~4 kg 35~50 L 0.7~1.0 cup 23~33 g...
-
Page 18: Partial Operations Using The Fuzzy Program
Partial Operations Using the Fuzzy Program To not spin the To reuse the wash To customize laundry because If you want... water and separate the wash program you are worried your laundry about wrinkles Wash ⇒ Rinse ⇒ Operations Wash only Wash ⇒... - Page 19 Partial Operations Using the Fuzzy Program If you want... To rinse only To rinse and spin To drain and spin Operations Rinse only Rinse ⇒ Spin Drain ⇒ Spin Setting method Turn on the power. Select the Fuzzy program. Display show Set the amount of water.
- Page 20 9 Min 30 L 6 Min 25 L 3 Min (Auto) No washing SF-P75XB ■ ■ You can set the number and You can set the spin time each type of rinses by pressing the time you press the Spin button Rinse button.
-
Page 21: In Case Of Power Outage
In Case of Power Outage If there is a The washing machine is equipped with a restart function. If a power outage occurs while the washing machine is operating, the power outage cycle (i.e., wash, rinse, or spin) at that time is saved, and when the power is restored, automatically restart from the interrupted cycle. - Page 22 Care and Maintenance 1. Close the tap. Cleaning 2. Disconnect the water supply hose from the top of the washing the water machine. (Water in the hose may be drained when you disconnect supply inlet the hose.) 3. Use a brush or something to clean the water supply inlet of the washing machine.
-
Page 23: Troubleshooting
Troubleshooting Problem Possible cause ● Does not operate The power plug is not inserted in the power outlet. ● There is a power outage. ● The Delay Timer has been set. ● It is wet, even though it is There may be moisture or water left in the tub or hoses from the the first time to use it (drain performance test before shipping from the factory. -
Page 24: Error Codes
Error Codes Error Description Things to check Solution code ● Water is not Is the tap open? Check the tap, water supplied supply inlet filter, water ● Has dirt collected in the water supply inlet pipes, and water supply filter? hose. -
Page 25: How To Install The Washing Machine
How to Install the Washing Machine ■ Safety Do not use a damaged power plug, doing so is dangerous. Contact a repair center that is certified by the manufacturer to replace the plug. precautions ■ If the outlet you are using is a 2-pin outlet, use an adapter to change from three pins to two pins. - Page 26 How to Install the Washing Machine Connecting the Main unit ● Screw the union nut to arrow direction to firmly attach the water supply water supply opening. hose Precautions Make sure that the union nut between water supply hose and main unit is tightly screwed.
- Page 27 How to Install the Washing Machine Connecting (Note) ● How to set the “Drain hose hanger” to “Water drain hose” the drain hose Drain hose hanger Locking position Water drain hose Water supply hose Connecting ● to the tap ■ The optimum water pressure is 0.03 to 0.8 MPa.
- Page 28 How to Install the Washing Machine If the water supply hose installs, tighten the water Connecting ● supply hose to water tap. water supply hose to the tap Water supply hose ■ Dismantling 1. Turn off water tap. 2. Press start button and run for 10 seconds. ●...
- Page 29 How to Install the Washing Machine ■ Connecting Connect the washing machine correctly to a grounded AC power supply. the power ■ The voltage of the power supply must match the voltage rating of the washing machine. ■ Do not use extension cords or overload the power outlet by using power strips.
-
Page 30: Customer Service
When you call the service center, you will need to tell them the model of the washing machine, describe the malfunction, and give them your address and phone number. Specifications Model SF-P75XB Power supply See the rating plate on the back of the washing machine. Standard water level 59 L (maximum water level) - Page 31 Memo...
