- Page 1 User Manual Model： CX 62150 KOS (EU)/CX 63130 KOS (EU) www.teka.com...
-
Page 2: Table Of Contents
CONTENTS Safety Precaution......................2 Important Information....................7 Product Overview......................7 Packing List.........................8 Installation........................8 Instruction......................10 Maintenance Services....................11 Parts Removal......................12 Circuit Diagram......................14 General Troubleshooting.....................14... -
Page 3: Safety Precaution
NOTE Dear users: Thank for your buying our range hood. Please accept our best regards. Please read this user manual carefully before installation and operation. The pictures in this manual only for your reference, if the picture isn’t accord with object, subject to the object. - Page 4 Danger Don’t allow children or weakling to use range hood separately, or it may cause electric shock or other accident. Prohibit Prohibit water on motor, switches or other electric parts. Prohibit wash range hood by water spray. Don’t use range hood if wet or it may cause electric leakage or shock.
- Page 5 Warning Range hood must be installed, disassembled or maintained by processional person. Prohibit Disassembly Stove fire shall be extinguished timely when it is not used; do not flambe under the range hood and it’s prohibited to bake food under range hood directly to prevent range hood from damaging and causing accidents.
- Page 6 This appliance just for household use only. And it’s not allowed to exhaust dangerous or explosive matter or air. It should be put under dry and ventilation environment without dangerous air. Strict Execution The range hood and electric circuit must be installed by skilled and trained personnel with required qualification.
- Page 7 Before removing range hood for installation, clean or maintenance, power must be cut off avoiding from electric shock. When installation, clean or maintenance, protective gloves must be worn avoiding form injury. Strict Execution The temperature for range hood working can’t exceed 40℃ Strict Execution Because the installation is difficult and hood is heavy, the installation shall be...
-
Page 8: Important Information
DISPOSAL: Do not dispose this product as unsorted municipal waster. Collection of such waste separately for special treatment is necessary. This product must not be disposed together with the domestic waster. This product has to be disposed at an authorized placed for recycling of electrical and electronic appliances. -
Page 9: Packing List
Packing List Please check lists if open the package. Quantity Quantity Name Name Range Hood Operation Manual assembly spare part Outer outlet Installation Warning 1. The air must not be discharged into a flue that is used for exhausting fumes form appliances burning gas or other fuels, the discharge of air must fulfill the requirements of local regulations. -
Page 10: Installation Notice
●Method B ( Cabinet only ): According to the distance of the holes on the top of the slim hood, measure the position and then tighten 4pcs ST4X16 screws on the bottom of the cabinet, and left around 2mm length. Place the hood onto the tighten screws and made them stay in the narrow side of the assembling holes. -
Page 11: Use Instruction
The measurement and calculation methods used to establish compliance with the requirements: EN61591, EN 60704-2-13, EN 50564. Environmental protection: Your new appliance is particularly energy-efficient. Here you can find tips on how to save even more energy when using the appliance, and how to dispose of your appliance properly. Saving energy. -
Page 12: Maintenance And Services
Maintenance and Services Warning 1.There is a fire risk if cleaning is not carried out in accordance with the instructions. Do not flambé under the range hood 2.Cleaning and maintenance shall be conducted under outage. Electrical components such as motor, switch, and connector shall not be spoiled by water so as to prevent from accidents. 3.It’s prohibited to wash with water so as to prevent accidents. -
Page 13: Parts Removal
Parts Removal Warning 1.The machine body doesn't need to be disassembled in ordinary conditions . Disassembly shall be operated by professional serviceman . 2. Before cleaning , installation or maintenance for the range hood , cut off the power supply to avoid electric shock . - Page 14 Replace any cracked protective shield Use hand holding the glass plate, then disassemble the screw (one side), then take out the glass. Use hand holding the glass plate, then fix to the holes on the hinges, afterwards, assemble the screw (one side).
-
Page 15: Circuit Diagram
Circuit Diagram CIRCUIT DIAGRAM CONTROL BOARD Power box Power Supply MOTOR MOTOR 220-240V~/50Hz CIRCUIT DIAGRAM CONTROL BOARD Power box Power Supply MOTOR 220-240V~/50Hz General Troubleshooting Fault Cause Fault Phenomenon Elimination Methods No response by pressing any Power plug is not well connected Well connect the power plug or power outage switch(e.g. - Page 25 Los métodos de medición y cálculo utilizados para establecer el cumplimiento de los requisitos: EN61591, EN 60704-2-13, EN 50564. Protección ambiental: Su nuevo electrodoméstico es especialmente eficiente desde el punto de vista energético. Aquí puede encontrar consejos sobre cómo ahorrar aún más energía al utilizar el electrodoméstico y cómo desecharlo correctamente.
- Page 29 MOTOR MOTOR 220-240V~/50Hz MOTOR 220-240V~/50Hz...
- Page 43 220-240V~/50Hz 220-240V~/50Hz...
- Page 57 MOTOR MOTOR 220-240V~/50Hz MOTOR 220-240V~/50Hz...
- Page 71 MOTOR MOTOR 220-240V~/50Hz MOTOR 220-240V~/50Hz...
- Page 85 MOTOR MOTOR 220-240V~/50Hz MOTOR 220-240V~/50Hz...
- Page 99 220-240V~/50Hz 220-240V~/50Hz...
- Page 113 220-240V~/50Hz 220-240V~/50Hz...
- Page 114 www.teka.com...
