- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE 76921 Owner's Manual Shop genuine replacement parts for FISHER PRICE 76921 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
- Page 2 Kawasaki Motors Corp., U.S.A. All Rights Reserved. This product is neither manufactured nor distributed by Kawasaki Motors Corp., U.S.A. Consumer inquiries should be directed to Power Wheels by Fisher-Price. Fisher-Price and Power Wheels by Fisher-Price are U.S. trademarks of Mattel, Inc. Owner’s Manual with Assembly Instructions Please read this manual and save it with your original sale’s receipt.
-
Page 3: Table Of Contents
Table of Contents Important Information ..............2 Warnings and Cautions . -
Page 4: Warnings And Cautions
Warnings and Cautions ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Do not bypass a Power Wheels ® fuse. It is a safety device. - Use only a Power Wheels ®... -
Page 5: Parts
Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. -
Page 6: Parts Diagram
Parts Diagram IMPORTANT! Some parts were placed under the seat for shipment. Unlock the seat lock fastener, using a slotted screwdriver to rotate the lock fastener turn to the unlocked position . Lift the seat to access the battery compartment. Note: Some parts shown are assembled on both sides of the vehicle. -
Page 7: Battery Charging
Battery Charging ELECTRICAL HAZARD WARNING CAUTION • Battery can fall out and injure a child Use the charger in dry locations only. if vehicle tips over. Always use battery clamp. Important Notes • PREVENT FIRE • Your new battery must be charged for at least - Do not bypass a Power Wheels ®... - Page 8 Battery Charging IMPORTANT! The battery must be removed from your vehi- cle for the initial charge in order to complete assembly. You do not need to remove the battery from your vehicle to Charger recharge it. Charger Connector Battery Connector Battery Clamp •...
-
Page 9: Assembly
Assembly IMPORTANT! Some parts were placed under the seat for shipment. Unlock the seat lock fastener, using a slotted screwdriver to rotate the lock fastener turn to the unlocked position Lift the seat to access the battery compartment. WARNING Center Axle Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. - Page 10 Assembly Front Axle Handlebar Wire Harness Guides Round Handlebar Bushing • Turn the handlebar upside down. • Align the handlebar wire harness with the guides on the underside of the handlebar. • Slide a round bushing onto the front axle and press it into •...
- Page 11 Assembly Steering Column RPM x 100 RPM x 100 FUEL FUEL Rectangular Steering Column Opening Bushing Vehicle Body Handlebar • Apply labels #7 and #8 to the handlebar, as shown. Steering • Position the vehicle body upright. Column • Insert the curved end of the steering column through the rectangular opening in the vehicle body.
- Page 12 Assembly Handlebar Wire Handlebar Harness Connector Handlebar Wire Main Wire Harness Harness Connector Steering Cap Nut Column Hole Opening Bottom View • Insert the wire connector on the main wire harness • Position the vehicle body upright. through the large opening in the center of the •...
- Page 13 Assembly Lock Seat Fastener Vehicle Body Footrest Lock Fastener Lock Fastener • Fit the footrest to the peg on the underside of the vehicle body. LOCKED UNLOCKED Note: If you have already charged your Power Wheels ® 6 Volt (4.0 Amp/Hr.) battery for at least 18 hours, you may want to install it in the battery compartment before assem- bling the seat to your vehicle.
-
Page 14: Label Decoration
Label Decoration Proper label application will help to keep the labels looking their best! When applying labels, keep the fol- lowing guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •... -
Page 15: Battery Installation
Battery Installation IMPORTANT! Use only a Power Wheels ® 6 Volt (4.0 Amp/Hr.) Battery battery with a Power Wheels 25 amp fuse installed. Use of ® Clamp any other battery or fuse will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ®... -
Page 16: Battery Care And Disposal
Battery Care Battery Care and Disposal and Disposal Care Disposal If a battery leak develops, avoid contact with the leaking • Your Power Wheels ® battery is a sealed lead-acid battery. acid and place the damaged battery in a plastic bag. See It must be recycled or disposed of in an environmentally information below for proper disposal. -
Page 17: Rules For Safe Driving
Rules for Safe Driving RIDING HAZARD WARNING Prevent Injuries and Deaths • Direct Adult Supervision Required • Keep Children Within Safe Riding Areas These areas must be: - away from swimming pools and other Use vehicle on generally level ground ONLY! bodies of water to prevent drownings - generally level to prevent tipovers 7. -
Page 18: How To Operate Your Vehicle
How to Operate Your Vehicle Your vehicle can be used either as a motorized vehicle or as a free-wheeling foot-to-floor vehicle. It has been pre-assembled at the factory for free-wheeling fun and converts easily for use as a motorized vehicle simply by switching the selector lever located under the seat. Motorized Use Motorized Use Press Here... -
Page 19: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center. - Page 20 Problems and Solutions Guide Problem Possible Cause Solution Vehicle was running but Vehicle is overloaded Make sure you do not overload the vehicle by allowing more suddenly stopped (cont.) than 1 rider at one time, by exceeding the 40 lbs. (18 kg) maximum weight capacity, or by towing objects behind the vehicle.
- Page 21 Problems and Solutions Guide Problem Possible Cause Solution Sometimes the vehicle doesn’t Loose wire or connector Check all wires around the motor and all connectors to run, but other times it does make sure they are tight. Motor or electrical switch damage Contact your local Power Wheels ®...
-
Page 22: N Statement Of Limited Warranty
Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on 6 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ® ride-on vehicle (purchased from Power Wheels ®... -
Page 23: Authorized Service Centers
Authorized Service Centers We are continually expanding our Authorized Service Center Network. Please check this listing for the Authorized Service Center nearest you. If there is not one in your area, please call Power Wheels ® Consumer Relations at 1-800-348-0751. ALABAMA FRESNO - Valley Small Appliance, 4005 E. - Page 24 Authorized Service Centers VERO BEACH - Hoppe’s Authorized Vacuum and LINCOLN - Rexx Battery Specialists, 504 Keokuk, JUNCTION CITY - R/C Hobbies, 115 W. 7th Street, Appliance, 1872 Commerce Ave., 32960, 62656, (217) 732-2885 66441, (913) 238-1877 (561) 562-4466 LOVES PARK - Hi-Tech Controls Inc., 2198 Nimtz KANSAS CITY (OVERLAND PARK) - Mar-Beck WEST PALM BEACH - Satisfaction TV Video, Road, 61111, (815) 637-4015...
- Page 25 Authorized Service Centers MASSACHUSETTS MISSISSIPPI MAPLEWOOD - Kiss Electrical, 36 Newark Way, 07040, (973) 275-9400 BOSTON (MEDFIELD) - Wills Hardware, HATTIESBURG - Champion Cycle & Fitness, 5 Janes Avenue, 02052, (508) 359-4381 2625 Lincoln Road, 39402, (601) 310-0270 SOUTHAMPTON - Southampton Auto Center, 1831 Rt.
- Page 26 Authorized Service Centers NORTH CAROLINA OKLAHOMA PUERTO RICO ANDREWS - Smoky Mountain Hobbies, 200 Stewart ADA - Bert's Supply Co, Hwy 99, 74820, MAYAGUEZ - Cardona Appliance Service, Road, 28901, (828) 321-9836 (580) 332-7295, (800) 259-7202 8 San Vicente Street, 00680, (787) 832-8366 ASHEVILLE - Skyland Hardware, 3179 Sweeten McCALESTER - Quality Upholstery, 803 East Gene MAYAGUEZ - AAA Melendez Rental, Calle Post 319...
- Page 27 Authorized Service Centers CORPUS CHRISTI - Brand Appliance & Microwave, WEST VIRGINIA VIRGINIA 2751 South Staples, 78404, (361) 854-1851 BECKLEY - Jerry’s Detectors, Vacuum & Appl. Svc., ALEXANDRIA - D & S Repair Service, 20 South Dove DALLAS - All Type Sales and Service Co., Inc., 411 Second Street.
- Page 28 Authorized Service Center list in this manual. Fisher-Price and Power Wheels by Fisher-Price are U.S. trademarks of Mattel, Inc. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2001 Mattel, Inc. All Rights Reserved. Printed in the Mexico...
