- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. FISHER PRICE 74765 Owner's Manual Shop genuine replacement parts for FISHER PRICE 74765 Find Your FISHER PRICE Ride On Parts - Select From 999 Models -------- Manual continues below --------...
- Page 2 JEEP and the Jeep grille design are registered trademarks of DaimlerChrysler Corporation and are used under license. ©DaimlerChrysler Corporation. Fisher-Price, Power Wheels by Fisher-Price, Sunjammer and Power Lock are U.S. trademarks of Mattel, Inc. Goodyear (and winged foot design) and Wrangler (for tires) are trademarks of The Goodyear Tire & Rubber Company, used with permission.
-
Page 3: Table Of Contents
Parts Important Information ..............2 Warnings and Cautions . -
Page 4: Warnings And Cautions
Warnings and Cautions ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Do not bypass a Power Wheels ® fuse. It is a safety device. - Use only a Power Wheel ®... -
Page 5: Parts
Parts • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. - Page 6 Parts Key Assembly Microphone 6 Volt Charger 25 Amp Fuse - 2* Radio Dial Shifter 6 Volt Battery Steering Wheel Cap Gas Cap Assembly Traction Band - 4 Radio Knob - 2 Not Shown: Label Sheets - 2 #8 x 1" Screw – 12 #6 x "...
-
Page 7: Parts Diagram
Parts Diagram Note: Some parts shown are assembled on both sides of the vehicle. Vehicle Body Windshield Key Assembly Steering Column Windshield Frame 25 Amp Fuse Grille Dash Type H 6 Volt Battery Sport Bar Hood Cap Nut - 2 Sport Bar Cover Set Microphone #6 x... -
Page 8: Battery Charging
Battery Charging ELECTRICAL HAZARD WARNING CAUTION • Battery can fall out and injure a child Use the charger in dry locations only. if vehicle tips over. Always use battery clamp. Important Notes • PREVENT FIRE • Your new battery must be charged for at least - Do not bypass a Power Wheels ®... - Page 9 Battery Charging 25 Amp Fuse GOOD FUSE "BLOWN" FUSE • Plug the charger into a standard 120 volt wall outlet. • If you are charging the battery for the first time, insert a Note: If power flow to the wall outlet is controlled by a 25 amp fuse into the battery.
-
Page 10: Assembly
Assembly Steering WARNING Column Children can be harmed by small parts, sharp edges and sharp points in the vehi- cle’s unassembled state, or by electrical Guides items. Care should be taken in unpacking and assembly of the vehicle. Children Steering Linkage should not handle parts, including the battery, or help in assembly of the vehicle. - Page 11 Assembly Steering Wheel Cap Radio Knobs Steering Wheel Shifter Activity Panel • Fit the steering wheel cap into the center of the steering • From the front of the activity panel, insert and snap the radio knobs. wheel with the screw holes aligned. •...
- Page 12 Assembly Windshield Hole Microphone Slot Frame Windshield Plastic • Fit the windshield into the windshield frame. • Insert five #6 x " screws through the holes in the wind- shield and into the windshield frame. • Tighten the screws with a Phillips screwdriver. Do not over-tighten.
- Page 13 Assembly Hood Grille Sport Bar Sport Bar Cover (BAC) Holes • Lift the hood. • Fit the tabs at the bottom of the grille into the slots in the vehicle body. • With the ends of the sport bar angled toward you, fit •...
- Page 14 Assembly Taillight Lens Taillight Housing Sport Bar Hole Seat Rear of Vehicle • Using safety scissors, separate the taillight lenses and taillight housings from the plastic connectors. Dispose of Hole the plastic connectors properly. • Fit a taillight lens in a taillight housing. •...
- Page 15 Assembly Battery Clamp (Engine Cover) Traction Spark Plug Band Wire Set Spark Plug Wire End Ridge Wheel Hole • Snap the center of the spark plug wire set onto the battery clamp (engine cover). • Fit each of the spark plug wire ends into the holes on Bottom View the sides of the battery clamp (engine cover).
-
Page 16: Label Decoration
Label Decoration Proper label application will help to keep the labels looking their best! Keep the following guidelines in mind when applying labels: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. -
Page 17: Battery Installation And Battery Clamp (Engine Cover) Assembly
Battery Installation and Battery Clamp (Engine Cover) Assembly IMPORTANT! Use only a Power Wheels Type H 6 Volt bat- ® tery with a Power Wheels ® 25 Amp fuse installed. Use of any other battery or fuse will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels ®... -
Page 18: Battery Care And Disposal
Battery Care and Disposal Disposal Care If a battery leak develops, avoid contact with the leaking • Your Power Wheels ® battery is a sealed lead-acid acid and place the damaged battery in a plastic bag. See battery. It must be recycled or disposed of in an environ- information below for proper disposal. -
Page 19: Rules For Safe Driving
Rules for Safe Driving RIDING HAZARD WARNING Prevent Injuries and Deaths • Direct Adult Supervision Required • Keep Children Within Safe Riding Areas These areas must be: Use vehicle on generally level ground ONLY! - away from swimming pools and other bodies of water to prevent drownings 7. -
Page 20: How To Operate Your Vehicle
How to Operate Caring For Your Vehicle Your Vehicle To Drive • Check all screws, retainers and protective coverings regularly and tighten as required. Check plastic parts on • Push the top button (FWD) on the FORWARD/REVERSE a regular basis for cracks or broken pieces. switch to drive forward •... -
Page 21: Problems And Solutions Guide
Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels authorized service center. - Page 22 Problems and Solutions Guide Problem Possible Cause Solution Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the battery suddenly stopped connector is tightly plugged into the motor harness connector, and that there are no loose wires around the motors.
- Page 23 Problems and Solutions Guide Problem Possible Cause Solution Vehicle runs sluggishly Undercharged battery Charge the battery. A new battery should have been charged for at least 18 hours before using the vehicle for the first time. After first-time use, recharge the battery for at least 14 hours after each use.
- Page 24 Problems and Solutions Guide Problem Possible Cause Solution Vehicle constantly blows fuses Wrong type of fuse used Your vehicle requires a Power Wheels ® 25 amp fuse in the battery. Make sure the Power Wheels ® 25 amp fuse is properly installed.
-
Page 25: N Statement Of Limited Warranty
Bumper-to-Bumper* Limited Warranty *One year limited warranty from the date of purchase on the Power Wheels ® vehicle. Six month limited warranty on 6 volt battery. For the original purchaser, this one year limited warranty covers the Power Wheels ® ride-on vehicle (purchased from Power Wheels ®... -
Page 26: Authorized Service Centers
Authorized Service Centers We are continually expanding our Authorized Service Center Network. Please check this listing for the Authorized Service Center nearest you. If there is not one in your area, please call Power Wheels ® Consumer Relations at 1-800-348-0751. ALABAMA SAN FRANCISCO - California Electric Service Center, 1090 ROCKLEDGE - Neelco Do-It Center, 400 Barton Blvd., 32955,... - Page 27 Authorized Service Centers IOWA MICHIGAN NEVADA BETTENDORF - K & K True Value Hardware, 1818 Grant Street, ALMONT - Almont Hardware, 4545 Van Dyke, P.O. Box 511, las vegas - Burney’s Commercial Service, Inc., 52722, (319) 359-4473 48003, (810) 798-8922 4480 Aldebaran Avennue, 89103, (702) 736-0006 CEDAR RAPIDS - Stalker Electric, Inc.,110 3rd Ave.
- Page 28 Authorized Service Centers OHIO RHODE ISLAND VIRGINIA AKRON - Advanced Appliance Service Company, PROVIDENCE - Marshall Electric Co., 200 Broad Street, 02903, FREDERICKSBURG - Logan Electric Service, Inc., 98 Industrial 73 W. Exchange Street, 44308, (330) 762-8968 (401) 331-4482 Drive, 22408, (540) 898-8873 CANTON - Appliance Parts Co., 1267 Dueber Avenue, HARRISONBURG (PENN LAIRD) - J.L.
- Page 29 Authorized Service Center list in this manual. Fisher-Price and Power Wheels by Fisher-Price are U.S. trademarks of Mattel, Inc. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2000 Mattel, Inc. All Rights Reserved. Printed in the U.S.A.
