DRL-60-230
Laser distance sensor,
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collec� on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
Purpose
The DRL-60-230 is a laser sensor designed to control lighting,
especially in corridors and staircases.
As the control element here is a separated relay contact, this
sensor can also be used for integration into any home automa-
tion system.
The principle of operation is to emit a light beam and measu-
re the delay of returning light as a result of reflection from an
obstacle. On this basis, it is possible to precisely determine the
distance to the obstacle, which is then compared with the set
detection range.
The condition for switching on the light is the presence of an
obstacle at a distance smaller than the set detection range and a
brightness level below the value set on the sensor.
This solution is perfect for switching on lighting circuits for exam-
ple on open stairs, where it is important that the sensor detects
presence only on the stairs and ignores everything that happens
outside.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
230 V
