AVK7W1 7" WIRELESS HEAVY DUTY QUAD VIEW
MONITOR 1080P HD CAMERA KIT
5
ADVANCED SAFETY
VISION SYSTEMS
USER MANUAL
USER MANUAL
USER MANUAL
DVR
RECORDING
1080P
QUAD
12 24V
COMPATIBLE
CAMERA INPUTS
07-08-2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVK7W1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aerpro AVK7W1

  • Page 1 ADVANCED SAFETY VISION SYSTEMS AVK7W1 7” WIRELESS HEAVY DUTY QUAD VIEW MONITOR 1080P HD CAMERA KIT USER MANUAL USER MANUAL USER MANUAL QUAD 12 24V COMPATIBLE RECORDING 1080P CAMERA INPUTS 07-08-2024...
  • Page 2: Product Overview

    ADVANCED SAFETY VISION SYSTEMS Product overview Bracket installation 1. Fix the U-bracket into position. Insert and lock the monitor into the bracket using the mounting screw knobs. 2. Adjust to your desired angle.
  • Page 3 ADVANCED SAFETY VISION SYSTEMS Installation options Installation options Monitor Monitor Camera Camera Option1 Option2 Socket Hardwired wired Powerwires 10-32V DC car Powerwires (Reversing light10-32V) accessory socket (10-32V Accessory)
  • Page 4: Product Information

    ADVANCED SAFETY VISION SYSTEMS Product information 1. Monitor wireless antenna 2. Screen 3. Adjustable monitor angle mount 4. Camera wireless antenna 5. - Selection button 6. Menu button: Click to enter/exit the menu settings 7. + Selection button 8. AV button 9.
  • Page 5: Menu Operation

    ADVANCED SAFETY VISION SYSTEMS Menu operation When the monitor is on, press the “MENU” button to enter into the menu settings. Press the “+ / -“ buttons to cycle through setting options. Press the “AV“ button to confirm setting. Main menu Cameras / Pairing / Record / Playback / View Mode / Setting NOTE: To change settings within the menu will only be accessible when in single channel mode.
  • Page 6 ADVANCED SAFETY VISION SYSTEMS Pairing NOTE: This monitor can pair up to 4 cameras at once. The monitor must be told how many cameras are to be used in “Settings: , :CAM select: and select CAM1, CAM2, CAM3 or CAM4. Select in order from 1 to 4. For connection press the “+ / -“...
  • Page 7 ADVANCED SAFETY VISION SYSTEMS Record NOTE: This monitor can record footage from each of the paired cameras when used with an SD card up to 128GB Class 10 (not included). Select the Record icon on screen. Press the “AV” button to enter. Select record time and press the “AV”...
  • Page 8 ADVANCED SAFETY VISION SYSTEMS Playback Select the Playback icon on screen. Press the “AV” button to enter. Press the “+ / -“ buttons to cycle through recorded video files. Press the “AV” button to open the file and playback. Each recorded file is coloured differently depending on what camera the footage was recorded, highlighted at the top of the screen (CAM1, CAM2,CAM3,CAM4 and Merge).
  • Page 9: View Mode

    ADVANCED SAFETY VISION SYSTEMS View mode NOTE: This monitor can display different camera views depending on how many cameras are being used. Select the View mode icon on screen. Press the “AV” button to enter, then press the “+ / -“ buttons to cycle through view options as pictured below. Press the “AV” button to confirm.
  • Page 10 ADVANCED SAFETY VISION SYSTEMS Setting Select the Setting icon on screen. Press the “AV” button to enter, then press the “+ / -“ buttons to cycle through setting options. Scan Time Changes the amount of time the cameras are displayed on screen when in switching view mode.
  • Page 11: Specifications

    ADVANCED SAFETY VISION SYSTEMS Specifications • Display: 7" IPS Display • Resolution: ° Monitor: 1024x600 ° Camera: 1080P • Lens Angle: 110 Degrees • Wireless Frequency: 2.4Ghz • Wireless Range: 200 metres • 4x IR LEDs • Luminance: 500 cd •...
  • Page 12: Technical Assistance

    ADVANCED SAFETY VISION SYSTEMS Technical assistance If you need assistance setting up or using your Aerpro product now or in the future, call Aerpro Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST or EMAIL: service@tdj.com.au If you would like to download a digital copy of this manual, or other Aerpro manuals/software, please visit the Aerpro.com website and search for the product...
