- Page 1 Reference Guide Avitech HTTP Commands Sequoia 4K60/4K60L Revision 1.0.8 (January, 2024)
-
Page 2: About This Reference Guide
To assist us in making improvements to this reference guide, we welcome any comments and constructive criticism. Please send all such – in writing to: sales@avitechvideo.com. WARNING Do not attempt to disassemble the Avitech device(s). Doing so may void the warranty. There are no serviceable parts inside. Please refer all servicing to qualified personnel. TRADEMARKS All brand and product names are trademarks or registered trademarks of their respective owners. -
Page 3: Table Of Contents
Contents ABOUT THIS REFERENCE GUIDE ....................i Warranty ............................iv Limitation of Liability ........................iv Extended Warranty Options ....................... iv Services and Repairs Outside the Warranty Period ..............iv Regulatory Information ......................iv Federal Communications Commission (FCC) Statement ............iv European Union CE Marking and Compliance Notices ............ - Page 4 Fullscreen Mode – Set ......................18 1.3.3 Commands for Sequoia 4K60 .................19 Routing – Set (Quad Multiview + Workstation mode) ............19 Routing – Set (Seamless Switching mode) ................19 Routing – Get ........................20 Audio – Set (Quad Multiview + Workstation mode) ..............20 Audio –...
-
Page 5: Warranty
Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. Avitech is not responsible for any Limitation of Liability radio or television interference caused by using other than Avitech’s liability under this warranty shall not exceed the purchase... -
Page 6: Http Command
This is equivalent to actions done by the web browser when visiting websites, and may not actually send commands to the Sequoia 4K60/4K60L. Using the private browsing mode will solve this problem. The following shows you how to use the HTTP command on Google Chrome: Step 1. - Page 7 Step 3. Select a New incognito window to open an incognito window (private browsing mode). Figure 1.2.1 Google Chrome Menu: New Incognito Window A new incognito window is opened (an incognito window can also be opened by using keyboard “Ctrl + Shift + N” hotkey instead of performing steps 2 and 3). Figure 1.2.2 Incognito Window of Google Chrome...
- Page 8 Step 4. Type the IP address assigned to the Sequoia 4K60/4K60L, the HTTP command, and the associated Cmd-Values in the address bar. Example: To reset your Sequoia 4K60/4K60L’s settings to its factory-default state = http://192.168.0.5/cgi-bin/command.cgi?cmd=Info¶m={"func":"set","type":"default"} Figure 1.2.3 HTTP Command in the Address Bar ...
-
Page 9: Http Command Summary
None Format http://192.168.0.5/cgi-bin/command.cgi?cmd=Info¶m={"func":"get","type":" device"} Example Obtain and display the Sequoia 4K60/4K60L’s MCU / Scaler / Web / KM firmware version. Sample See the below screenshot. Response Table 1.3.1.1 Get Sequoia’s Firmware Version Command Figure 1.3.1.1 Response of Getting Firmware Information Command Signal Type –... -
Page 10: Network - Get
Cmd-Value None Format http://192.168.0.5/cgi-bin/command.cgi?cmd=Info¶m={"func":"get","type": "machinelist"} Example Obtain and display the Sequoia 4K60/4K60L’s IP address / Mac address / Machine name in the same network. Sample See the below screenshot. Response Table 1.3.1.3 Get Sequoia’s Network Setting Command Figure 1.3.1.3 Response of Get Network Setting Command Output Resolution –... -
Page 11: Default Preset - Load
Default Preset – Load Function Set the Sequoia 4K60/4K60L display to conform to one of the default layouts. default_layout = 1/2/3 ): quad layout Cmd-Value ): 3 (smaller windows) + 1 (large) layout Format ): 1 (large) + 3 (smaller windows) layout response = 0(ignore response) / 1(response) http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"load","type":... -
Page 12: User Icon Preset - Load
User Icon Preset – Load Function Load one of the five preconfigured user icon presets. preset_unm = 1/2/3/4/5 1: user icon preset number one( 2: user icon preset number two( Cmd-Value 3: user icon preset number three( Format 4: user icon preset number four( 5: user icon preset number five( response = 0(ignore response) or 1(response) http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"load","type"... -
Page 13: Custom Preset - Load
Custom Preset – Load Function Load a designated custom preset. name = "custom preset filename" (acceptable character set that can be used in the naming of preset file includes the following (special characters are not allowed): Cmd-Value “A”~ “Z”; “a”~“z”; “0”~“9”; “.”(period); “–”(dash); “_”(underline)) Format response = 0(ignore response) or 1(response) http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"load","type"... -
Page 14: Custom Preset - Delete
Defaults Reset your Sequoia 4K60/4K60L’s settings to its factory-default state. Upon resetting your Sequoia 4K60/4K60L to its factory-default state, your previously saved presets stored in the Function Sequoia 4K60/4K60L's flash memory will be automatically removed; make sure to have your files saved externally before resetting the Sequoia 4K60/4K60L to the factory-default state. -
Page 15: Fading Level (Speed) - Set
Sequoia 4K60L is in Quad Multiview + Bypass (Daisy Chain Capable) mode. Function Sequoia 4K60 is in Quad Multiview + Workstation mode. winid = 0(Host mode) / 1(Window 1’s Remote mode) / 2(Window 2’s Remote mode) / Cmd-Value Format 3(Window 3’s Remote mode) / 4(Window 4’s Remote mode) -
Page 16: Osd Show/Hide - Set (Global Setting)
Set (global setting) simultaneously.) Function Set the OSD show / hide in Sequoia 4K60/4K60L. The OSD contains label/border/audio tally. port = 1 / 3(port 3 is only available for Sequoia 4K60 in Dual Independent Quad Multiview Cmd-Value + Bypass mode) Format enable = 0(hide) or 1(show) http://192.168.0.5/cgi-bin/command.cgi?cmd=Info¶m={"func":"set","type":... -
Page 17: Window Border - Set (Global Setting)
= R(0-255),G(0-255),B(0-255),255(fixed) http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"set","type": "osd","data":{"border_width":6}} Example 1 Set the border width of the four windows of Sequoia 4K60/4K60L in 6 pixels. http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"set","type": "osd","data":{"border_width":2,"border_color":[177,181,249,255]}} Example 2 Set the border width in 2 pixels and border color RGB value = 177/181/249 of the four windows of Sequoia 4K60/4K60L. -
Page 18: Audio Tally Color - Set (Global Setting)
Example 2 :[225,0,254,255]}} Set the “Tally1” (HDMI audio switch) on and off color for Sequoia 4K60/4K60L. “Success” – this indicates a successful transmission of HTTP command. Response “Wrong format” – this indicates a failure of HTTP command. Table 1.3.1.19 Set System Audio Tally Command Audio Tally Show/Hide –... -
Page 19: Alert Display - Set
Format http://192.168.0.5/cgi-bin/command.cgi?cmd=Info¶m={"func":"lock","type": "km","idle_time":120} Example To enable idle detecting duration time for 2 minutes of Sequoia 4K60/4K60L. “Success” – this indicates a successful transmission of HTTP command. Response “Wrong format” – this indicates a failure of HTTP command. Table 1.3.1.24 Set Keyboard/Mouse Idle Detecting Duration Time Command... -
Page 20: Mouse - Set
Mouse – Set To configure the essential features of mouse for controlling the Sequoia 4K60/Sequoia Function 4K60L. mode = right (right-handed) or left (left-handed) Cmd-Value Format speed = 0 (slowest) – 14 (fastest) http://192.168.0.5/cgi-bin/command.cgi?cmd=Info¶m={"func":"set","type": "mouse","mode":"right","speed":14} Example To configure the left mouse button the one you use for primary functions such as selecting and dragging;... -
Page 21: Commands For Controlling Window
Note: Be aware of the monitor’s display resolution when setting the size of a window so as Function not to exceed the display boundary. port = 1 / 3(port 3 is only available for Sequoia 4K60 in Dual Independent Quad Multiview + Bypass mode) win:... -
Page 22: Window Label Text - Get
Blu-ray player for Sequoia 4K60/4K60L. http://192.168.0.5/cgi-bin/command.cgi?cmd=Info¶m={"func":"set","type": Example 2 "genlabel","label":[{"port":3,"label":"Server_1"}]} Set the label of input port 3 to become Server_1 of Sequoia 4K60/4K60L. “Success” – this indicates a successful transmission of HTTP command. Response “Wrong format” – this indicates a failure of HTTP command. -
Page 23: Window Aspect Ratio - Set
Example "win","port":1, "winid":1, "data":{"aspect":2}} Set the aspect ratio of the window 1 of Sequoia 4K60/4K60L to follow 16:9 aspect ratio. “Success” – this indicates a successful transmission of HTTP command. Response “Wrong format” – this indicates a failure of HTTP command. -
Page 24: Commands For Sequoia 4K60
1.3.3 Commands for Sequoia 4K60 Routing – Set (Quad Multiview + (This command only available for Sequoia 4K60 in Quad Multiview + Workstation Workstation mode) configuration mode) To route an input port to a window/output port or to multiple windows/output ports. -
Page 25: Routing - Get
= 0(turn off the audio) http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"set","type": "audio","port":2,"winid":254} Example Turn on audio source for HDMI OUT 2 of Sequoia 4K60. port = 5 (only available for HDMI OUT 5) Cmd-Value winid = 1 (only avialable for HDMI OUT 5) Format 3 winid = 0(turn off the audio) http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"set","type":... -
Page 26: Audio - Set (Seamless Switching Mode)
= 0(turn off the audio) http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"set","type": "audio","port":3,"winid":1} Example Turn on audio source for HDMI OUT 3 of Sequoia 4K60. “Success” – this indicates a successful transmission of HTTP command. Response “Wrong format” – this indicates a failure of HTTP command. -
Page 27: Commands For Sequoia 4K60L
1.3.4 Commands for Sequoia 4K60L Routing – Set (Quad Multiview + Bypass (Daisy Chain Capable) mode) – HDMI (This command only available for HDMI OUT 1 of Sequoia 4K60L in Quad Multiview OUT 1 + Bypass (Daisy Chain Capable) configuration mode) To route an input port’s source to display a window or multiple windows on HDMI OUT 1 of Function Sequoia 4K60L. -
Page 28: Routing - Get
Routing – Get Display the input and output port’s routing information. Function None Cmd-Value Format http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"get","type": "hdmi_output"} Example Obtain and display window/output port’s routing information. See the below screenshot. Response Table 1.3.4.4 Get the Input / Output Routing Information Command Figure 1.3.4.1 Example 1: Response of Input / Output Routing Information (Quad Multiview Mode) Figure 1.3.4.2 Example 1: Response of Input / Output Routing Information (Seamless Switching Mode) K/M Mode –... -
Page 29: K/M Control - Set (Randomly Switch Km Control)
= 1(turn on the audio), or 0(turn off the audio) http://192.168.0.5/cgi-bin/command.cgi?cmd=2060¶m={"func":"set","type": Example "audio","port":3,"winid":1} Turn on audio source for HDMI OUT 3 of Sequoia 4K60. “Success” – this indicates a successful transmission of HTTP command. Response “Wrong format” – this indicates a failure of HTTP command. -
Page 30: Output Resolution - Set (Quad Multiview + Bypass (Daisy Chain Capable) Mode)
Output Resolution – Set (Quad Multiview + Bypass (Daisy Chain Capable) mode) Function Set the frame rate and resolution of HDMI OUT for Sequoia 4K60L. port = 1 (only port 1 is available when Sequoia 4K60L is in this mode.) mode = 0/107/106/199/200/99/98/96/95/181/209/74/70/143/205 Cmd-Value Format... -
Page 31: Command For Sequoia 4K60L In Daisy Chain
1.3.5 Command for Sequoia 4K60L in Daisy Chain The IP address for receiving http command will be the IP address of the primary Sequoia 4K60L in daisy chained. (This command is only available for Sequoia 4K60L in daisy chain configuration.) Label Text –... -
Page 32: K/M Control - Set (Randomly Switch Km Control)
K/M Control – Set (Randomly switch KM control) Allows randomly switching the K/M (keyboard/mouse) control in Remote or Host mode of the Function Sequoia 4K60L in daisy chain configuration. winid = 1 – 16 (Window’s Remote mode) / 0 (Host mode) Note: The corresponding window ID number in default layout of different daisy chain configurations is as below table.
