Setup the Sequoia 4K60

(The following figure shows a typical setup with an Avitech Sequoia 4K60 module connected to four computer systems and a touchscreen display device via a USB hub.)
2. Connect one end of the HDMI signal cable
1. Connect one end of the USB A/B cable to
to the port marked HDMI IN 1 on the rear
the USB Type-B port marked 1 on the
panel of Sequoia 4K60. Connect the other
rear panel of Sequoia 4K60. Connect the
end to the first computer's HDMI / DVI (a
other end to the first computer's USB
DVI-to-HDMI converter may be required)
Type-A port. Connect another USB A/B
port. Connect another HDMI signal cable
cables to the USB Type-B ports marked 2
to the port marked HDMI IN 2 connector
/ 3 / 4 on the rear panel of Sequoia 4K60
on the rear panel of Sequoia 4K60 and the
and the other end to the second / third /
other end to the second computer's HDMI
fourth computer's USB Type-A ports.
/ DVI port. Do the same for the third and
fourth computer.
3. Connect one end of the HDMI signal cable to 6. Connect the 12 V DC power adapter to Sequoia
the port marked HDMI OUT 1 on the front
panel of Sequoia 4K60. Connect the other end
7.
to the touchscreen display device's HDMI port.
8. Turn on power of the four computers and the
9. Press Ctrl + T on your keyboard or tap
4. Connect a USB hub to the USB Type-A port
marked 1 on the front panel of Sequoia
4K60. Then connect one end of the USB A/B
cable to the USB Type-B port to the
touchscreen display device and connect other
end to the USB hub.
5. Connect the mouse and keyboard devices to
the USB hub.
Congratulations and thank you for purchasing the Avitech Sequoia 4K60
This guide provides step-by-step instructions for a quick setup of your Sequoia 4K60
10. Upon completing touchscreen calibration,
4K60.
Press the power switch to the ON position of
Sequoia 4K60. The image will be displayed on
touchscreen display device around 20 seconds.
11. Move the mouse pointer to the window's top
touchscreen display device.
anywhere (except the yellow and orange marks
shown in below figure) and hold the spot for 7
seconds to perform touchscreen calibration
(when using the touchscreen display device
with the Sequoia 4K60 for the very first time, or
upon resetting your Sequoia 4K60 to the
default state).
2
Host Operation Mode
When the Sequoia 4K60 is in the Host operation
mode, the mouse cursor is controlled by a local
mouse device connected to the master Sequoia
device. There is a Host cursor to control all the
Use your finger tip or a stylus to tap and
position and size of up to four remote
continue pressing on the center of the
computers.
symbol that will appear on the top left portion
for approximately five (5) seconds until the next
Remote Operation Mode
symbol appears on the top right portion.
Perform the same step for this, as well as the
When the Sequoia 4K60 is in the Remote
symbol that would appear on the lower left
operation mode, the mouse cursor and
portion and lower right portion of your monitor
keyboard is used to control a specific computer
display.
connected to the Sequoia.
Quick Start Guide
tap anywhere on the touchscreen display
device or press the Pause/Break key and the
mouse pointer will appear on touchscreen
display device.
right portion of the particular computer.
When the pop-up menu appears
click the " " symbol. You can now use the
mouse or keyboard hotkeys to perform
various tasks. The default mouse and
keyboard is located on the Sequoia 4K60
Host operation mode.

Operating Modes
