Summary of Contents for Atlas Copco FX 8
- Page 1 Instruction book Refrigerant dryers...
- Page 3 Atlas Copco Refrigerant dryers Instruction book Original instructions COPYRIGHT NOTICE Any unauthorized use or copying of the contents or any part thereof is prohibited. This applies in particular to trademarks, model denominations, part numbers and drawings. This instruction book is valid for CE as well as non-CE labelled machines. It meets the requirements for instructions specified by the applicable European directives as identified in the Declaration of Conformity.
-
Page 4: Table Of Contents
Instruction book Table of contents Safety precautions......................4 Safety icons..........................4 Safety precautions, general....................4 Safety precautions during installation................5 Safety precautions during operation..................6 Safety precautions during maintenance or repair.............. 7 Dismantling and disposal......................8 General description...................... 10 Introduction..........................10 Air system..........................11 Refrigeration system...................... - Page 5 Instruction book During operation........................25 Stopping.............................25 Maintenance instructions.................... 27 Device settings......................28 Problem solving......................29 Technical data....................... 33 Reference conditions and limitations.................. 33 Air dryer data...........................33 Pressure equipment directives................... 35 Declaration of conformity.................... 36...
-
Page 6: Safety Precautions
Instruction book Safety precautions Safety icons Explanation Danger to life Warning Important note Safety precautions, general General precautions All responsibility for any damage or injury resulting from neglecting these precautions, or non-observance of the normal caution and care required for installation, operation, maintenance and repair, even if not expressly stated, will be disclaimed by the manufacturer. -
Page 7: Safety Precautions During Installation
Instruction book Safety precautions during installation Precautions during installation 1. The dryer must only be lifted using suitable equipment and in accordance with the applicable safety regulations. Loose or pivoting parts must be securely fastened before lifting. It is strictly forbidden to dwell or stay in the risk zone under a lifted load. -
Page 8: Safety Precautions During Operation
Instruction book 16. If no safety valve is present in the air net close to the desiccant dryer (e.g. safety valve of compressor), full flow safety valves must be installed on the dryer vessels. 17. If the maximum pressure of the compressor is higher than the design pressure of the dryer, a full flow safety valve must be installed between the compressor and the dryer in order to blow off the excessive pressure. -
Page 9: Safety Precautions During Maintenance Or Repair
Instruction book 9. If warm cooling air from dryers is used in air heating systems, e.g. to warm up a working area, take precautions against air pollution and possible contamination of the breathing air. 10. Do not remove any of, or tamper with, the sound dampening material. 11. -
Page 10: Dismantling And Disposal
Instruction book 16. Before clearing the machine for use after maintenance or overhaul, check that operating pressures, temperatures and time settings are correct. Check that all control and shut-down devices are fitted and that they function correctly. 17. Protect the motor, electrical and regulating components, etc. to prevent moisture from entering them, e.g. - Page 11 Instruction book The equipment is labelled in accordance with the European Directive 2012/19/EU with the crossed- out wheelie bin symbol. At the end of life-time of the electric and electronic equipment (EEE) it must be taken to separate collection. For more information check with your local waste authority, customer center or distributor. Disposal of other used material Used filters or any other used material (e.g.
-
Page 12: General Description
Instruction book General description Introduction General views Figure 1: Closed view... -
Page 13: Air System
Instruction book Figure 2: Open view Refrigerant compressor Condenser Motor fan Evaporator Condensate drain Hot gas bypass valve Refrigerant filter Expansion capillary tube Introduction The FX air dryers remove moisture from compressed air by cooling the air to near freezing point. This causes water to condense. -
Page 14: Refrigeration System
Instruction book Reference Name Evaporator Condensate separator Impurity trap Heat exchanger Digital controller Condensate drain Description Compressed air enters heat exchanger (10) and is cooled by the outgoing cold, dried air. Water in the incoming air starts to condense. The air then flows through heat exchanger/evaporator (10 and 4) where the refrigerant evaporates, causing the air to be cooled further to close to the evaporating temperature of the refrigerant. -
Page 15: Automatic Regulation System
Instruction book The liquid flows through the refrigerant dryer/filter (8) to capillary tube (7). The refrigerant leaves the capillary tube at evaporating pressure. The refrigerant enters evaporator (4) where it withdraws heat from the compressed air by further evaporation at constant pressure. The heated refrigerant leaves the evaporator and flows through the liquid separator (9) back to the compressor (1). -
Page 16: Installation
Instruction book Installation Dimension drawings Type L (mm) W (mm) H (mm) Weight (Kg) FX 8 FX 9 FX 10 FX 11 FX 12 Installation proposal Moving Use a suitable tool (e.g., pallet carrier, fork lift truck) to move the dryer. - Page 17 Instruction book Example of compressor/dryer room Figure 3: Installation proposal The disconnector switch (1) and the fuses are not supplied with the machine. Table 1: Attention Reference Description Install the refrigerant air dryer on a level floor, suitable for its weight. Install the dryer where the ambient air is as clean as possible and where the temperature of the air will never exceed the limits.
-
Page 18: Pictographs
Instruction book • Please keep environmental conditions stable (temperature and humidity) in order to avoid refrigerant compressor/fan overload and/or reduction of dryer performance. Similar failures shall affect warranty reimbursements. • Please ensure the appropriate composition of the air within the machine room: •... -
Page 19: Operating Instructions
Instruction book Operating instructions Warnings Safety precautions The operator must apply all relevant safety precautions, including those mentioned in this manual. Altitude operation Consult your supplier if operating above 3000 m (9843 ft). Dryer control panel Description Reference Name Digital controller, used for: 1. -
Page 20: Digital Dryer Controller
Instruction book Digital dryer controller Identification Figure 4: Front panel of the controller Reference Name Alarm icon Refrigerant compressor icon Fan icon PDP (dewpoint) temperature Unit (°C or °F) Alarm LED Button to snooze or to reset the alarm (only for remote alarm function). SET button UP button DOWN button... - Page 21 Refer to the table below to identify the availability of the function and refer to the related picture to identify the physical location of the free contact. Model Fault message availability FX 8 to FX 12 Table 2: Availability of the remote alarm function Figure 5: Location of the free contact (1)
- Page 22 Instruction book Fault messages Flashing fault message Description Remedy Fan control probe failure Replace the probe. Dewpoint temperature probe Replace the probe. failure Refrigerant compressor discharge temperature probe Replace the probe. failure Refer to the fault and remedies Pressure dewpoint too high section.
- Page 23 Instruction book Flashing fault message Description Remedy Reset by pressing one of the four buttons. Internal EPROM error If the problem persists, replace the controller. Perform the maintenance and Maintenance required reset the alarm. Resetting the maintenance warning Figure 6: Front panel of the controller To reset the maintenance warning, follow steps 1 to 12: 1.
- Page 24 Instruction book 8. Push and release the UP button (9). 9. Message “y” appears on display. 10. Push and release SET (8) to reset service alarm. 11. Message “y” blinks for 3 seconds. 12. Then “rL” is fixed and “°C” blinks on display for about 10 seconds. The service alarm is now reset.
- Page 25 Instruction book 6. Select desired service interval using the UP or DOWN button. (40=4000h, 55=5500h, 80=8000h,…) 7. Push and release SET to confirm the new service interval. 8. The selected value blinks during 3 seconds. 9. Then “rS” is fixed and “°C” blinks on display for ~10 seconds. The new service interval is now set.
-
Page 26: Starting
Instruction book Silent alarm function To snooze the alarm, press button 7. Starting Attention To ensure optimum operational efficiency, do not use dryer on/off switch repeatedly within a short time period. Wait at least 5 minutes to start the dryer again after stopping to allow pressure equalization. -
Page 27: During Operation
Instruction book During operation Procedure Regularly check: • The pressure dewpoint on the digital controller (1). The pressure dewpoint will deviate from nominal value if air inlet conditions or volume flow differ from nominal value. • That condensate is discharged via condensate outlet. The amount depends on the operating conditions. - Page 28 Instruction book Step Action Close the dryer inlet and outlet valve (customer’s installation). Press dryer on/off switch (2) and the dryer will stop. If provided, open the dryer by-pass valve.
-
Page 29: Maintenance Instructions
Instruction book Maintenance instructions Safety precautions Before starting any maintenance or repair work, close the air inlet and outlet valves and switch off the voltage. When removing the side panels of the dryer, be aware that internal elements such as the pipes can be hot. -
Page 30: Device Settings
Instruction book Device settings Regulating and safety devices The regulating and safety devices are factory-adjusted to obtain optimum performance of the dryer. Do not alter the setting of any of the devices. -
Page 31: Problem Solving
Instruction book Problem solving Condensate drain and air inlet and outlet valves Reference Name Inlet and outlet valves Condensate drain Dryer on/off switch Isolating switch Attention Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by Warranty or Product Liability. Apply all relevant safety precautions. - Page 32 Instruction book Condition Fault Remedy Check and correct; if necessary, Ambient temperature too draw cooling air via a duct from a high cooler place or relocate the dryer. Increase inlet pressure. Air inlet pressure too low Adjust the pressure switch. Dryer capacity exceeded Reduce air flow.
- Page 33 Instruction book Condition Fault Remedy Check the flow rate of treated air. Check the room temperature. The dryer is working Check the air temperature at the outside its rating dryer inlet. Clean the condenser. The dryer is working under Check the good operation of the bad conditions of fan.
- Page 34 Instruction book Condition Fault Remedy Troubles with the internal The compressor is very mechanical parts or with noisy the valves...
-
Page 35: Technical Data
Instruction book Technical data Reference conditions and limitations Reference conditions Unit Working pressure bar(e) Inlet air temperature ˚C Ambient temperature °C Dewpoint °C Limits Unit Maximum working pressure bar(e) Maximum inlet air temperature °C Minimum ambient temperature °C Maximum ambient temperature °C Air dryer data Performance data... - Page 36 Instruction book 230V 230V 115V Unit 50Hz 60Hz 60Hz Ambient air temperature (25 °C/ 77 Heat dissipated by °F) cooling medium flow 2.82 2.83 2.90 Compressed air inlet (approx.) temperature (35 °C/ 95 °F) Ambient air temperature (43 °C/ Heat dissipated by 109.4 °F) cooling medium flow 6.04...
-
Page 37: Pressure Equipment Directives
Instruction book Pressure equipment directives Components subject to Pressure Equipment Directive All pressure bearing components are designed category I or less according to European Directive 97/23/EC (until 19/07/2016) or Directive 2014/68/EU (from 20/07/2016 onwards). -
Page 38: Declaration Of Conformity
Instruction book Declaration of conformity Figure 7: Typical example of a Declaration of Conformity document (1): Contact address: Atlas Copco Airpower n.v. P.O. Box 100 B-2610 Wilrijk (Antwerp) Belgium (2): Applicable directives (3): Standards used On the Declaration of Conformity / Declaration by the Manufacturer, the harmonized and/or other standards that have been used for the design are shown and/or referred to. - Page 40 atlascopco.com...
