Icom IC-F4060 Series Service Manual Addendum page 320

Jun. 2009
SECTION 4
P
BEFORE INSTALLING OPTIONAL UNITS
Before installing optional units, the supplied sponge
must be attached. Remove the bottom protective
paper, and attach the sponge to the specifi ed position
on the optional units as shown below.
NOTE: Attach the sponge by pressing it gently
but ensure that it is attached to the unit securely.
• UT-96R
• UT-126H
(Replacement page)
OPTIONAL UNIT INSTALLATION
Sponge
Sponge
Sponge
(Supplied with the unit)
• UT-109R/UT-110R
• UT-124R
4 - 1
Sponge
Sponge
