Icom IC-F4060 Series Service Manual Addendum page 2

November 2012
SECTION 6
6-1 PREPARATION
▄ REQUIRED TEST EQUIPMENT
EQUIPMENT
CS-F3060 ADJ (for F4060 series)
Adjustment software CS-F3160/5060 ADJ (for F4160 series)
CS-F3160/5060 ADJ (dPMR) (for [DPM-01])
Frequency range
FM deviation meter
Measuring range
Frequency range
Frequency counter Frequency accuracy
Sensitivity
Measuring range
Frequency range
RF power meter
Impedance
SWR
▄ SYSTEM REQUIREMENTS
® ®
• Microsoft Windows 98/98SE/Me/2000/XP
• RS-232C serial port (D-sub 9 pin)
▄ ADJUSTMENYT SOFTWARE INSTALLATION
q Quit all applications when Windows is running.
w Insert the CD into the appropriate CD drive.
e Double-click the "Setup.exe" contained in the 'CS-
F3160/5060 ADJ' folder in the CD drive.
r The "Welcome to the InstallShield Wizard for CS-
F3160/5060ADJ" will appear. Click [Next>].
t The "Choose Destination Location" will appear. Then click
[Next>] to install the software to the destination folder. (e.g.
C:\Program Files\Icom\CS-F3160/5060 ADJ)
y After the installation is completed, the "InstallShield Wiz-
ard Complete" will appear. Then click [Finish].
u Eject the CD.
i Program group 'CS-F3160/5060 ADJ' appears in the 'Pro-
grams' folder of the start menu, and 'CS-F3160/5060 ADJ'
icon appears on the desk top screen.
Microsoft and Windows are registered trademarks of Microsoft Corporation in the USA and other countries.
• ADJUSTMENT FREQUENCY LIST
FREQUENCY (MHz)
CH
Low band High band
1 400.000 450.000
2 435.000 485.000
3 470.000 520.000
4 434.950 484.950
5 435.000 485.000
6 435.000 485.000
7 435.000 485.000
8 400.000 450.000
9 470.000 520.000
10* 435.000 –
11* 400.000 –
12* 470.000 –
(Replacement page)
ADJUSTMENT PROCEDURE
GRADE AND RANGE
: DC–600 MHz
: 0 to ±10 kHz
: 0.1–600 MHz
: ±1 ppm or better
: 100 mV or better
: 1–10 W
: 100–300 MHz
: 50 Ω
: Better than 1.2 : 1
ADJUSTMENT ITEM
350 MHz
band
TX power : Low1
350.000
Mode : Wide
TX power : Low1
375.000
Mode : Wdie
TX power : Low1
400.000
Mode : Wide
TX power : Low1
374.950
Mode : Wide
TX power : High
375.000
Mode : Wide
TX power : Low2
375.000
Mode : Wide
TX power : Low1
375.000
Mode : Narrow
TX power : Low1
350.000
Mode : Narrow
TX power : Low1
400.000
Mode : Narrow
TX power : Low1
–
Mode : Middle
TX power : Low1
–
Mode : Middle
TX power : Low1
–
Mode : Middle
EQUIPMENT
Modifi ed OPC-966 CLONING CABLE
JIG cable
(See the illustration on page 5-2)
Power attenuation
Attenuator
Capacity
Standard signal Frequency range
generator (SSG) Output level
Frequency rang
Oscilloscope
Measuring range
Input impedance
External speaker
Capacity
▄ BEFORE STARTING SOFTWARE ADJUSTMENT
Clone the adjustment frequencies into the transceiver, and
set the confi guration using with the CS-F3160/5060
SOFTWARE before starting the software adjustment. Other-
wise, the software adjustment can not be started.
CAUTION!: BACK UP the originally programmed memory data
in the transceiver before programming the adjustment frequencies.
When program the adjustment frequencies into the transceiver,
the transceiver's memory data will be overwritten and lose original
memory data at the same time.
▄ STARTING SOFTWARE ADJUSTMENT
q Connect the transceiver and PC with OPC-966
w Turn the transceiver power ON.
e Boot up Windows, and click the program group 'CS-
F3160/5060 ADJ' in the 'Programs' folder of the [Start]
menu, then CS-F3160/5060 series ADJ's window appears.
r Click 'Connect' on the CS-F3160/5060 ADJ's window, then
appears transceiver's up-to-date condition.
t Set or modify adjustment data as specifi ed.
FREQUENCY (MHz)
CH
Low band High band
†
13 435.000 485.000
†
14 400.000 450.000
†
15 470.000 520.000
16 435.000 485.000
17 435.000 485.000
†
; Necessary only when the optional UT-126 is installed. *; Only [EUR]
CONVENIENT: The same cloning file is available.
Right-click below, and select "Save Embeded File to Disk."
[Low band] :
[High band] :
[350 MHz band] :
6 - 1
GRADE AND RANGE
: 20 or 30 dB
: 10 W
: 0.1–600 MHz
: 0.1 µV to 32 mV
(–127 to –17 dBm)
: DC–20 MHz
: 0.01–20 V
: 8 Ω
: 1 W or more
CLONING
JIG CABLE
ADJUSTMENT ITEM
350 MHz
band
TX power : Low1
375.000
Mode : Digital
TX power : Low1
350.000
Mode : Digital
TX power : Low1
400.000
Mode : Digital
TX power : Low1
375.000 Mode : Wide
CTCSS : 151.4 Hz:
TX power : Low1
375.000
Mode : Narrow
.
