Part Description
CL52 Robot Coupe Commercial Food Processor with
Series "D" Whole Head Feed Assembly, and Two Plates
(Std. Pack contains
Two Plate Racks
* 28110 5x5mm Dicing Kit (Series "D")
* 28111 8x8mm Dicing Kit (Series "D")
10x10mm Dicing Kit (Series "D")
* 28112
* 28113 14x14mm Dicing Kit (Series "D")
* 28114 20x20mm Dicing Kit (Series "D")
25x25mm Dicing Kit (Series "D")
* 28115
* 28117 5mm Dicing Grid Only (Series "D")
* 28118 8mm Dicing Grid Only (Series "D")
10mm Dicing Grid Only (Series "D")
* 28119
* 28120 14mm Dicing Grid Only (Series "D")
* 28121 20mm Dicing Grid Only (Series "D")
25mm Dicing Grid Only (Series "D")
* 28122
* 28128 5mm Slicing Plate (Series "D")
* 28129 8mm Slicing Plate (Series "D")
10mm Slicing Plate (Series "D")
* 28130
* 28131 14mm Slicing Plate (Series "D")
* 28132 20mm Slicing Plate (Series "D")
25mm Slicing Plate (Series "D")
* 28133
* 28134 8x8mm French Fry Set (Series "D")
* 28135 10x10mm French Fry Set (Series "D")
Magnetic Switch Assembly
29451
29501 Lock For Feed Cover
29530 Motor Pulley
Mount Spacer for Control Board
29533
29564 Blade Only for FF Set (Series "D")
29599 Control Wire Connector
Motor Support/Chute
29628
29630 Bearing Assembly, Lower
29691 Pusher Bushing
Cabbage Plate Locking Nut
29692
29693 Drive Shaft Assembly
29694 Feed Lead Assembly
Magnet Safety Arm
29705
29741 Support Plate Brace
29781 Knife with Screws for Slicing Plate
Control Board
102480
102690 Discharge Plate
117682 Shaft Pulley, 75 teeth
117687 Bottom Cover
117689 Motor Support Plate
Base Brace
117691
117692 Support Plate Brace
117703 Control Board Retainer Pin
Discharge Vane
117802
118008 Removable Divider
118324 Small Pusher
Shaft Only
118380
118427 Feed Lead
118428 Pusher Assembly
Base Cover
118430
118436 Lock Nut Wrench
203107 Seal Protector
Bushing, Circlip-Shaft
203108
203109 Thrust Bushing
203132 Washer
Motor Assembly
303081
406516 Front Data Plate
501599 Capacitor
Off Switch (Red)
502169
* Denotes Accessories
CL52 Series "D"
C446SA & C450GPA), and
(R475).
Part Description
On Switch (Green)
502170
Bearing/Upper
507063
507122 Strain Relief
1.5mm Grating Grid Only For
C404GN
Belt
C411N
C418GN 7mm Grating Grid Only For
Horizontal Blade (4x4)
C429JBA
Horizontal Blade (6x6)
C431JBA
* C433GPA Extra Coarse (9mm) Grating Plate
6mm Julienne Plate
* C438JA
6mm Julienne Vertical Blade Only
C439JBA
C440JBA 2mm Julienne Horizontal Blade Only
1mm Slicing Plate
* C444SA
2mm Slicing Plate
* C445SA
* C445W 2mm Waved Slicing Plate
Waved Blade Only
C445WD
3mm Slicing Plate
C446SA
C446W 3mm Waved Slicing Plate
1.5mm Blade Only
C449SBA
Medium (3mm) Grating Plate
* C450GPA
* C451GPA Fine (2mm) Grating Plate
Hard Cheese Grating Plate
* C452GPA
Coarse 5mm Grating Plate
* C453GPA
C454GN Medium Grating Grid Only for
Fine Grating Grid Only for
C455GN
Hard Cheese Grating Grid Only For
C456GN
C457GN Coarse Grating Grid Only For
Extra Coarse Grating Grid Only For
C458GN
Grating Plate Base
C459BA
* C460JA 2mm Julienne Plate
Vertical Blade Only
C461JBA
* C462JA 4x4 Julienne Plate
C463JBA 4mm Julienne Vertical Blade Only
5mm Waved Slicing Plate
* C464W
* C466JA 8x8 Julienne Plate
C467JBA 8mm Julienne Vertical Blade Only
4mm Medium Grating Plate
* C475GPA
* C477SA 4mm Slicing Plate
7mm Grating Plate
* C478GPA
2x4 Julienne Vertical Blade Only
C4831JBA
C4832JBA 2mm Julienne Horizontal Blade Only
2x4 Julienne Plate
* C483JA
2x6 Julienne Vertical Blade Only
C4841JBA
* C484JA 2x6 Julienne Plate
2x8 Julienne Vertical Blade Only
C4861JBA
2x8 Julienne Plate
* C486JA
* C494GPA 1.5mm Grating Plate
1mm Pulping Plate
* C495GPA
Hinge Pin
CL520
CL523 Hinge Pin Bushing
Stainless Steel Wall Mount Plate Rack
* CL575
5mm Screw
CL590A
CL590B 6mm Screw
8mm Screw
CL590C
10mm Screw
CL590D
CL590E 12mm Screw
Shaft Pin
CL592
Cord with Plug
R240
R3009U Relay
Foot
R402F
Plate Rack
* R475
* R476 Plate Rack (3 Plate Capacity)
Plastic Washer
R609A
Breaker
RB497
(01 / 2001)
NOMENCLATURE / PARTS LIST
C494GPA
C478GPA
C450GPA
C451GPA
C452GPA
C453GPA
C433GPA
MAJ : 01/2001
