- Page 1 SMART SQUAT 20819 OWNER’S MANUAL WEBSITE...
- Page 2 Introduction Installation Indication As shown in the diagram: 1. Stand base 2. Base communication terminal 3. Stand communication terminal 4. M8*10 internal hexagon socket button head screw 5. Display stand Step 1: First, insert the base communication terminal (2) into the stand communication terminal (3) as shown in the diagram.
-
Page 3: Safety Precautions
As shown in the diagram: As shown in the diagram: 1: Cable 1: Cross recessed pan head screw M4*8 2: Connecting pipe 2: Display back cover 3: M12 flat washer 3: Cross recessed pan head screw M3*6 4: M12 spring washer 4: Stand communication terminal Step 1: First, power on the device (do not operate the interface). -
Page 4: Preparation Before Use
9.Please make sure to read all instructions before use. The factory is not responsible for Operating Instructions any personal injury or property damage caused by improper use of this product. Preparation before use: 10.The power plug must be reliably grounded, and try to avoid using other electrical appliances on the same power supply line. -
Page 5: Mode Description
Mode Description: LED Light Description : We provide four resistance modes for the product, namely Standard Mode, Eccentric Mode, Isokinetic Mode, and Elastic Mode. Please refer to the following instructions for Color Remark State specific modes: Gradient effect Powered on, resistance not activated Blue (dark to light, light to dark) Mode... -
Page 6: Specification
Assembly Step 1 7. Pay attention to the order of locking nuts when installing. Do not lock the nuts being installed until the entire equipment is installed. Only lock the nuts one by one after the entire machine is installed. Step Description Specification... -
Page 7: Table Of Contents
Assembly Step 3 Assembly Step 2 Step Description Specification Step Description Specification Bearing frame Cross connection frame Swinging rack Stand frame Adjusting rack Hexagon socket screws with cylindrical head M10*25 Axis 2 M10*30 Hexagon socket screws with cylindrical head Gas spring cylinder Spring washer d0=25 Elastic retaining ring for shaft... -
Page 8: Swinging Rack
Assembly Step 4 Assembly Step 5 Step Description Specification Step Description Specification Swinging rack Foot rest Axis 1 Hexagon socket screws with countersunk heao M10*70 Elastic retaining ring for shaft Hexagon socket screws with cylindrical head M10*30 d0=25 Spring washer Flat washer 20*010.5*2... -
Page 9: Hexagon Socket Screws With Cylindrical Head M10*30
Assembly Step 6 Maintenance Attentions Step Description Specification Daily Maintenance: Shoulder pad 1.Clean the seat pad,back pad and cushion with warm water and soft cloth in order to avoid the sweat erosion to these component . Hexagon socket screws with cylindrical head M8*30 2.Clean the frame with warm water and soft cloth Spring washer...
