- Page 1 TS-4542 AND TS-4736 TANK SUMPS INSTALLATION GUIDE...
- Page 2 Copyright © 2018 Franklin Fueling Systems, LLC, Madison, WI 53718. All world rights reserved. No part of this publication may be stored in a retrieval system, transmitted, or reproduced in any way, including, but not limited to, photocopy, photograph, magnetic, or other record, without the prior written permission of Franklin Fueling Systems.
-
Page 3: Table Of Contents
Contents Introduction ............................1 Conventions used in this manual ....................1 Questions and concerns ........................1 Operating precautions ........................2 Regulatory compliance ........................3 Installation............................5 Installing the sump ........................5... -
Page 4: Intentionally Blank
Intentionally Blank... -
Page 5: Introduction
Introduction Conventions used in this manual This manual includes safety precautions and other important information presented in the following format: NOTE: This provides helpful supplementary information. IMPORTANT: This provides instructions to avoid damaging hardware or a potential hazard to the environment, for example: fuel leakage from equipment that could harm the environment. -
Page 6: Operating Precautions
Operating precautions Franklin Fueling Systems (FFS) equipment is designed to be installed in areas where volatile liquids such as gasoline and diesel fuel are present. Working in such a hazardous environment presents a risk of severe injury or death if you do not follow standard industry practices and the instructions in this manual. -
Page 7: Regulatory Compliance
Regulatory compliance IMPORTANT INFORMATION – FOLLOW ALL INSTRUCTIONS IMPORTANT: Sump products shall only be assembled and installed by a qualified person (as determined by the manufacturer). Tthe use of non-qualified personnel or any deviations from these recommended procedures could result in damage or leakage. IMPORTANT: Failure to use recommended combination of sump products in a completed assembly may cause damage or leakage. - Page 8 Intentionally Blank...
-
Page 9: Installation
Installation Installing the sump IMPORTANT: Keep matching sump lids and sump bases together, do not mix parts. Number lids and bases to avoid confusion. Do not store a lid separate from its sump base for long periods of time. Install lids on bases when sumps are not being worked on. IMPORTANT: If a lid does not fit on a riser, warm the lid with a heat gun to make it more flexible. - Page 10 5. Determine the location of the tank fitting adapter(s) (or manway adapter) and mount the tank sump to the adapter. See the Tank Fitting Adapter Installation Instructions and Manway Installation Instructions for further information. The tank fitting adapter must be at least 5"...
- Page 11 NOTE: See the Installation Guide Overview for a list of proper backfill materials. 6. Properly support the tank sump with approved backfill material below and around the tank sump. 7. Install the lid on the tank sump during backfill operations to prevent the sump from distorting.
- Page 12 A Franklin Fueling Systems Brand 771-119-00 r10...
