- Page 1 GVM-SD600D-II...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions and Precautions --------------------------- Page 1~2 Warning ------------------------------------------------------------------------ Page 2 Product introduction ---------------------------------------------------------- Page 3 Disclaimers -------------------------------------------------------------------- Page 3 Product parameter ------------------------------------------------------------ Page 4 Precautions -------------------------------------------------------------------- Page 4 Product structure analysis ---------------------------------------------------- Page 5 Installation method ------------------------------------------------------- Page 6~10 Description of product control keys ---------------------------------------- Page 11 Function introduction &... -
Page 3: Important Safety Instructions And Precautions
IMPORTANT SAFETY INSTRUCTIONS First and foremost: this product is professional lighting and staging equipment and should be used by a professional lighting technician or under the guidance of a professional. When using this product, you must always follow the cautions below: 1．Read the product manual carefully before use. -
Page 4: Warning
17.For some products with long power cords, please place the power cords properly and avoid contact with overheated surfaces that may damage or trip personnel. Please use the original power cords of our manufactory. The damage caused by using non-original power cords is not covered by our repair service. -
Page 5: Product Introduction
PRODUCT INTRODUCTION Welcome to use the "GVM-SD600D-II", this product is specially designed for senior photography enthusiasts. The product is suitable for live streaming / outdoor / studio photography, and also for YouTube video shooting. 1．The light can be adjusted steplessly, with 1 COB LED , and CRI of 97+, Bi-color temperature 2700K~6800K, which helps restore and enrich the color of the object, providing you with natural and vivid shooting effects. -
Page 6: Product Parameter
PRODUCT PARAMETER ◆ Brand : GVM ◆ Product Model : GVM-SD600D-II ◆ Product Name : Photography light ◆ Product Type : Photography fill light ◆ Features : Multiple light effect modes, high display index lamp beads ◆ Control Methods : DMX, Wireless remote control, Light body control, APP Bluetooth MESH network control ◆... -
Page 7: Control Box
PRODUCT STRUCTURE ICON Vents Bowens mount Control input Lamp beads Angle lock U-frame handle Light stand interface Fixture knob Lamp Head Cooldown key Return key Display screen Mode key Battery plate Menu key Knob 1: Brightness adjustment / selection confirmation Controller output interface Knob 2:... -
Page 8: Installation Method
INSTALLATION METHOD Loosen the light stand fixing knob, install the light to the light stand as shown below, then tighten the light stand fixing knob. Loosen the angle locking handle, adjust the angle of the spotlight, then tighten the angle locking handle. - Page 9 Insert the standard cover into the corresponding Bowens bayonet socket of the light, then turn it clockwise gently. To remove the standard cover on the light, push the Bowens disassembly buckle to the behind and rotate the standard cover counterclockwise to disassemble the standard cover. Install the controller fixing clip on the light stand as shown in the figure below.
- Page 10 Follow the steps shown in the figure below to install the controller on the controller fixing clip first.
- Page 11 As shown in the figure below, use the control wire to connect the light and the controller.
- Page 12 There are two power supply modes to choose from: 1． Use the AC power cord for power supply. 2． Use two V button batteries for power supply. (Batteries must be inserted into both battery slots to provide power, and the power is halved when using batteries.)
-
Page 13: Description Of Product Control Keys
DESCRIPTION OF PRODUCT CONTROL KEYS Display: Display current settings, modes and parameters. Mode key: light mode switch button. Menu key: press this key to enter the settings menu. Return key: press this key to return to the previous level menu. Cooling key: start a large air volume cooling until the temperature decreased to a touchable temperature. -
Page 14: Function Introduction & Instructions For Use
FUNCTION INSTRUCTION & INSTRUCTION FOR USE ① MENU ： Figure 1 MENU DMX SETTINGS DMX SETTINGS (Figure 1): PROFILES ADDRESS Set the DMX parameters, [address (001-512)] 8bit and configure the mode [(8bit/16bit)]. 16bit DMX SETTINGS Figure 2 MENU DIM CURVE DIM CURVE (Figure 2): Set the dimming curve, [linear / logarithmic / Linear... - Page 15 Figure 7 MENU LANGUAGE LANGUAGE (Figure 7): Set the system language. ENGLISH 简体中文 LANGUAGE SYSTEM SETTINGS (Figure 8): Figure 8 MENU SYSTEM SETTINGS View system information and restore Contrl Ver 1.27 Lamp Ver 1.02 Factory Settings. UID: GPR0650B-0F6888410 Factory Reset SYSTEM SETTINGS ②...
-
Page 16: App Control
APP CONTROL APP Download Method (Scan the QR code on the back of the manual to download the APP) Android Device：Official website QR code, Google Play, Huawei Store, etc. iOS Device：App Store Figure 1 Figure 2 Device-adding 1．Before adding a device, please make sure you have turned on your phone’s Bluetooth and network data, accessibility to Bluetooth and network data, then... -
Page 17: Account Login
Account Login Figure 5 Use e-mail to get the verification code to log in (the first login ◆ automatically registers the account). (Figure 5) There may be a delay in sending the verification code, and ◆ the speed of delivery depends on the e-mail server you are using. -
Page 18: Quick Troubleshooting
QUICK TROUBLESHOOTING Check the product Troubleshooting Issue Whether the connection Make sure the adapter is well between the light and the connected with the power plug. power supply is normal. The indicator does not light up. When using a lithium battery to supply power, make sure Use the product after recharging that the battery does not have... -
Page 19: Packing List
PACKING LIST Name Quantity Notes Photography Lights AC Power Cable Controller Cable Controller Controller Clip Standard Cover Spotlight Protective Cover Magic Cable Tie Carrying Case Manual... -
Page 20: Product Warranty
PRODUCT WARRANTY Dear user, this warranty card is important proof for applying for warranty service. Please cooperate with the salesperson to fill it out and keep it properly. Thank you! Model Number Product Barcode Product Information Name Contact Number User Information Mailing Address Name... -
Page 21: How To Obtain Warranty Service
8．Other malfunctions or damages not caused by quality issues of the product itself. In such cases, you should seek solutions from the relevant responsible parties, and GVM will not be held liable. Malfunctions or damages caused by components, accessories, or software not covered by the warranty or beyond the warranty scope that renders the product unable to function properly are not covered by the warranty. - Page 22 Huizhou City Latu Photographic Equipment Co., Ltd. Web: www.gvmled.com B&H Email: bh@gvmled.com GVM Email: support@gvmled.com Amazon Email: amazonsupport@gvmled.com Warehouse Address: 4301 N Delaware Ave, unit D. PHILADELPHIA, PA19137, USA...
