Trionic Veloped 14er M User Manual

Hide thumbs Also See for Veloped 14er M:
Table of Contents

Advertisement

Quick Links

Download this manual
Veloped User Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Veloped 14er M and is the answer not in the manual?

Questions and answers

Related Manuals for Trionic Veloped 14er M

Summary of Contents for Trionic Veloped 14er M

  • Page 1 Veloped User Guide...
  • Page 2 Veloped both off-road and in the city. accessed by the user. By choosing a Trionic Veloped Sport you This user manual is included in the scope of will discover a whole range of benefits, and delivery.

  • Page 3: Technical Data

    Veloped User Guide Trionic Veloped 14er M The Veloped has a unique 3-wheel design, obstacles up to 15 cm high (14" wheels). The but as you can see it has in fact four force required to overcome a smaller wheels. It’s aimed to be used as a walking...
  • Page 4 Correct Grip Height How to set the correct height of your Veloped Many rollator users set the grips too high, thinking that it will promote a more upright posture. But this actually worsens the posture, and it affects the stability negatively. You can determine the correct Veloped grip height by doing as follows, as recommended by all physiotherapists and all rollator manufacturers:...

  • Page 5: First Time Use

    First Time Use 1. Attach the rear wheels to the frame’s rear axle holes by pressing the black button in the centre of the wheel and then pushing the axle all the way into the axle hole. Release the push button. 2.

  • Page 6: Walking Mode

    Walking Mode 1. Unfold the Veloped by pulling the gripbar handles sideways, away from each other. 2. Check that the Veloped locks in walking mode; when unfolding it make sure you hear a click from the telescopic stay locking into position. 3.
  • Page 7 Folding the Veloped 1. Pull the seat to the rear. 2. Press the button on the right of the telescopic stay. 3. Bring one side and the other side of the frame closer to each other, reaching the left button on the telescopic stay.

  • Page 8: Parking Brake

    Parking Brake You can engage the parking brake in 3 different ways. Push the lower red parking trigger downwards with your index finger, while you pull the brake lever at the same time. Make sure that the parking brake is engaged, and that the Veloped does not move.
  • Page 9 Grip Height Adjustment 1. Release both quick-release levers by folding them outwards. 2. Adjust the gripbar to required height, the most adequate being the distance from the wrist to the ground when standing with the arms hanging freely. Use help to measure! The easiest way to adjust the gripbar is when sitting on the seat;...
  • Page 10 Grip Angle Adjustment The angle of the grips can be adjusted so that you get a comfortable hand position and an optimal support. 1. Loosen the screw on the rear end of the grip with a 4 mm Allen key. 2.

  • Page 11: Installing The Rear Wheels

    1. If the brakes work poorly, loosen the adjustment screw on each brake lever (counter-clockwise) and lock it in position by screwing the lock-nut towards the handle (clockwise). Contact your retailer, or the person responsible for servicing your Trionic Veloped, if the brakes still work poorly.

  • Page 12: Removing/Installing The Front Wheel

    Air Pressure Check the tyre air pressure regularly. Trionic recommends a tyre pressure of 1.5 bar/22 psi. Maximum tire air pressure is 2.5 bar/35 psi.
  • Page 13 Change Front Wheel Setting The wheel has two different settings: one for easy steering and one for direction-steady mode. There is an adjustment handle on the front wheel, placed between the wheels, that can be shifted between these two settings. Easy-steering mode/Lower position: Offers easy turning with retained climbing capacity.
  • Page 14 Removing/Attaching the basket The basket of the Trionic Veloped has a 22-litre loading capacity. It has a small zippered pocket at the rear end for valuables and smaller objects. The Veloped basket is removable, and is attached to the frame basket rails with three velcro sections.

  • Page 15: Removing/Installing The Seat

    The Veloped’s sliding seat is comprised of a seat base and a removable cover fixed with nine push buttons. 1. Hold the seat cover with the text Trionic to the right. Wrap the long flap between the telescopic stay and the seat base.

  • Page 16: Safety Instructions

    If your Veloped is not in perfect condition: please immediately contact your retailer/dealer or service representative authorized to service your Trionic Veloped. Make sure to check the tyre pressure every 4–5 weeks. Trionic recommends a tyre pressure of 1.5 bar/22 psi.

  • Page 17: Environmentally Friendly

    REF: 25-00-000 Environmentally Friendly The Trionic Veloped is manufactured in the way to have as little negative impact on the environment as possible during its lifecycle. When the product has served its purpose, it can be scrapped and the parts can be recycled.
  • Page 18 Veloped Video Product Demonstrations Watch the instructions on your smartphone. Open your camera app, point it at the QR code, and hold your phone steady until a notification or link appears on your screen. Tap the notification to open the link and start watching the video. Additionally, a manual link is provided for direct access to the video on your computer.

  • Page 19: Certificate Of Guarantee

    The Trionic Veloped includes a 10-year guarantee, excluding parts that are subject to normal wear (tyres, tubes, brake pads, brake cables, brake cable housings, grips and textile parts). The guarantee is valid from the date of purchase, and covers Trionic original parts only. Purchase Date:...
  • Page 20 Trionic Sverige AB Märstagatan 8 75323 Uppsala, Schweden support@trionic.com +46 8 522 100 50...
