Summary of Contents for Trionic Walker 12er S
- Page 1 Walker User Guide...
- Page 2 Trionic Walker 12er, and that you the specified handling instructions. Make will experience many pleasant moments sure that the user manual can always be with it.
-
Page 3: Technical Data
The Walkers are tested and approved comfortable ride, and it’s perfect for every according to the international standard urban and outdoor area. All the new Trionic ISO-11199-2:2005, for a maximum user Walker rollators are equipped with a weight of 150 kg. - Page 4 Correct Grip Height How to set the correct height of your rollator Many rollator users set the grips too high, thinking that it will promote a more upright posture. But this actually worsens the posture, and it affects the stability negatively. You can determine the correct grip height by doing as follows, as recommended by all physiotherapists and all rollator manufacturers:...
-
Page 5: First Time Use
First Time Use 1. To unfold the Walker, pull the two hand grips away from each other. 2. Grab the right grip with your right hand and lift the right front- and right rear wheel off the ground. With the right wheels lifted, lock the Walker in Walking mode by pressing the left rear corner of the seat distinctly downwards. -
Page 6: Parking Brake
Parking Brake You can engage the parking brake in 3 different ways. Push the lower red parking trigger downwards with your index finger, while you pull the brake lever at the same time. Make sure that the parking brake is engaged, and that the Walker does not move. - Page 7 Grip Height Adjustment 1. Release the quick-release lever positioned just above the seat by folding it outwards horizontally. 2. Slide the hand grip up-/downwards to your preferred grip height. 3. Lock the hand grip at the chosen height by folding the quick-release lever to its closed position.
- Page 8 Grip Angle Adjustment The angle of the grips can be adjusted so that you get a comfortable hand position and an optimal support. 1. Loosen the screw on the rear end of the grip with a 4 mm Allen key. 2.
-
Page 9: Folding The Rollator
Folding the Rollator 1. Grab the seat handle and pull it upwards and the Walker will start folding. 2. Push the two grips handles fully together. - Page 10 Unfolding the Walker 1. To unfold the Walker, pull the two hand grips away from each other. 2.Grab the right grip with your right hand and lift the right front- and right rear wheel off the ground. With the right wheels lifted, lock the Walker in Walking mode by pressing the left rear corner of the seat distinctly downwards.
- Page 11 Detaching the Front Wheels 1. Open the quick-release on the front wheel by folding it outwards. 2. Unscrew the nut on the inside of the fork a bit, so that the wheel can be detached from the fork. 3. Remove the front wheel from the fork. Do not operate the quick-release levers like wing nuts or screws.
-
Page 12: Attaching The Front Wheels
Attaching the Front Wheels 1. Enter the front wheel into the fork, with the quick- release lever positioned on the outside of the Walker. 2. Tighten the nut on the inside of the fork, so that the quick-release gets correctly tensioned when closed. 3. -
Page 13: Installing The Rear Wheels
Installing the Rear Wheels The rear wheels are removable to simplify transportation of the Walker. 1. To detach the wheel, press the black button at the centre of the wheel and pull the wheel off. 2. To attach the wheel, press the black button at the centre of the wheel and push the wheel axle into the axle hole. -
Page 14: Brake Adjustment
(counter-clockwise) and lock it in position by screwing the lock-nut towards the handle (clockwise). Contact your retailer, or the person responsible for servicing your Trionic Walker, if the brakes still work poorly. Air Pressure Check the tire air pressure regularly. Trionic recommends a 1.5 –... -
Page 15: Safety Instructions
If your Walker is not in perfect condition: please immediately contact your retailer/dealer or service representative authorized to service your Trionic Walker. Make sure to check the tyre pressure every 4–5 weeks. Trionic recommends a tyre pressure of 1.5 bar/22 psi. - Page 16 (tires, tubes, brake pads, brake cables, brake cable housings, grips and textile parts). The guarantee is valid from the date of purchase, and covers Trionic original parts only. CE - Trionic Sverige AB ensures that the above...
-
Page 17: Environmentally Friendly
REF: 25-00-000 Environmentally Friendly The Trionic Walker is manufactured in the way to have as little negative impact on the environment as possible during its lifecycle. When the product has served its purpose it can be scrapped and the parts can be recycled. - Page 18 Walker Video Product Demonstrations Watch the instructions on your smartphone. Open your camera app, point it at the QR code, and hold your phone steady until a notification or link appears on your screen. Tap the notification to open the link and start watching the video. Additionally, a manual link is provided for direct access to the video on your computer.
-
Page 19: Certificate Of Guarantee
The Trionic Walker includes a 10-year guarantee, excluding parts that are subject to normal wear (tires, tubes, brake pads, brake cables, brake cable housings, grips and textile parts). The guarantee is valid from the date of purchase, and covers Trionic original parts only. Purchase Date:... - Page 20 Trionic Sverige AB • Märstagatan 8 • 75323 Uppsala • Sweden support@trionic.com 818-480-1907...
