FLIPPER 230V 50Hz 4M
Piusi S.p.A.
Via Pacinotti, 16/A - 46029 Suzzara (MN) - ITALY
Telefono +39 0376 534 561 | Fax +39 0376 536 393
piusi@piusi.com | www.piusi.com
1
2
A
B
C
D
E
F
1
2
(translation of original instructions)
3
4
5
Tolleranze generali
UNI EN 22768-mK SW-Massa
Disegnato
Ing.A.Zanzanelli
Data
12/10/2020
- Componente Adam Pumps -
Proprietà della ADAM PUMPS Spa - Senza autorizzazione scritta della stessa il presente disegno non potrà essere com
costruzione dell' oggetto rappresentato, nè venire comunicato a terzi o riprodotto. La società proprietaria tutela i propri
3
4
5
ENGLISH
M0628B EN
05/2023 - rev. 01
6
7
Peso indicativo
Rev.
1
2
3
4
5
RM n°
kg
Approvato
Data
Ing.A.Zanzanelli
Data
Firma
12/10/2020
Materiale
-
Denominazione
FLIPPER AC 230V 50Hz
F00100C00
Codice
6
7
EN
6
7
Fo
3
Advertisement
Table of Contents
Related Manuals for Piusi FLIPPER 230V 50Hz 4M
Summary of Contents for Piusi FLIPPER 230V 50Hz 4M
- Page 1 F00100C00 Codice FLIPPER 230V 50Hz 4M Proprietà della ADAM PUMPS Spa - Senza autorizzazione scritta della stessa il presente disegno non potrà essere com costruzione dell' oggetto rappresentato, nè venire comunicato a terzi o riprodotto. La società proprietaria tutela i propri...
- Page 2 - Machinery Regulations - Electromagnetic compatibility The documentation is at the disposal of the competent authority following motivated request at Piusi S.p.A. or following request sent to the email address: doc_tec@piusi.com. THE ORIGINAL DECLARATION OF CONFORMITY IS PROVIDED SEPARATELY WITH THE PRODUCT...
-
Page 3: Cgeneral Warnings
ANY REPRODUCTION, EVEN PARTIAL, IS FORBIDDEN. This manual belongs to Piusi S.p.A., which is the sole proprietor of all rights indicated by applicable laws, including, by way of example, laws on copyrights. All the rights deriving from such laws are reserved to Piusi S.p.A.: the reproduction, including partial, of this manual, its publication, change, transcription... -
Page 4: Dsafety Instructions
SAFETY INSTRUCTIONS D.1 SAFETY WARNINGS Mains - Before installation, make sure that the electric power supply network is fitted with a suitable preliminary earth-line and complies with the regulations in force. WARNING: You must avoid any contact between the electrical power supply and the fluid checks before that needs to be pumped. - Page 5 NOTE In the event that one or more of the components described below are missing from inside the package, please contact Piusi S.p.A. technical support. WARNING Check that the data on the plate correspond to the desired specifications. In the event of any anomaly, contact the supplier immediately, indicating the nature of the defects.
- Page 6 E. 2 COMPOSITION OF FLIPPER N° Part number TR003 VT074 TR007 AB051 TR005 TR004 TR006 TR008 10 AU0450W 11 VT049 12 71000112 13 VT075 14 VT076 15 FT020 16 RA039 17 TUB037 18 TUB192.5FFU 19 TUB190.5FFU Tolleranze generali Peso indicativo Rev.
- Page 7 MACHINE AND MANUFACTURER IDENTIFICATION The dispensing system comes with an identification plate; this is attached to the pump and contains the following information: type: lot number / Production year; technical data; use and maintenance handbook code WARNING Before installing, always make sure the type of dispensing system is correct and sui- table for the available power supply (Voltage/Frequency) F.1 PLATES POSITIONS The dispensing system is equipped with decals and/or plates to provide operators...
-
Page 8: Gtechnical Specifications
All products not listed in the "Intended Use" and "Treated Product Characteristics" para- graphs are to be considered not permitted, improper and therefore prohibited. Piusi S.p.A. accepts no responsibility for damage to persons or property caused by failure to comply with this requirement. - Page 9 WARNING The use of accessories that are unsuitable and were not provided with the system is strictly prohibited. Piusi S.p.A. accepts no responsibility for damage to persons, property or the environment caused by failure to comply with this requirement. The “FLIPPER” dispensing system is for professional use only.
- Page 10 3) load the drum onto the trolley and mount the drum locking belt to the appropriate hooks, as shown in the figure; 4) after loading the drum on the trolley, proceed with assembling the suction kit: screw both the 0,5M hose ends by turning the ring nuts of the fittings: on one side to the drum inlet, on the other to the pump;...
- Page 11 OPERATION AND USE WARNING To remove any substance residue or foreign matters from the pipes, wash the system before putting it into operation. To wash the system, follow the same dispensing procedures using demineralized or deionized water and eventually rinse with DdBlue® / AUS32 / D.E.F. Foreword Directions on how to start and stop operation of the system are given below: WARNING...
- Page 12 WASHING THE DISPENSING SYSTEM Foreword The dispensing system requires washing in order to remove product crystallisation which may damage the plant. ATTENTION Wear personal protective equipment (PPE) when performing the wash cycle. Use only demineralised water to wash the system. Disposal Liquids resulting from washing must be disposed of in accordance with the laws prevailing in the country of use.
-
Page 13: Rtroubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Lack of electric power Check the electrical connections and the safety systems. THE MOTOR IS Rotor jammed Check for possible damage or obstruction of the rotating NOT TURNING components. Motor problems Contact the Service Department THE MOTOR Low voltage in the electric Bring the voltage back within the anticipated limits... - Page 14 We are proud to provide you with a quality product and dedicated support. Together with your careful use, we are sure that you will have years of safe and dependable use. The President PIUSI S.p.A.
