- Page 1 USER MANUAL Hydraulic self-centering mobile puller BETEX® HXPC 50 Ton © BEGA International BV - 21.02.R01...
- Page 2 © BETEX Tools...
- Page 3 Lees voor ingebruikname eerst de gebruiksaanwijzing en de veiligheidsvoorschriften Controleer alle onderdelen op mogelijke transportschade. Waarschuw bij schade onmiddellijk het transportbedrijf. Omdat onze producten voortdurend worden verbeterd, behouden wij ons het recht voor om wijzigingen aan te brengen. © BETEX Tools...
-
Page 4: Table Of Contents
5.1 Operation and use ............................ 9 6. Cleaning and maintenance ������������������������������������������������������������������������������������������������������������ 11 7. Decommissioning ���������������������������������������������������������������������������������������������������������������������������� 11 8. Disclaimer ����������������������������������������������������������������������������������������������������������������������������������������� 11 9. Technical data ���������������������������������������������������������������������������������������������������������������������������������� 12 9.1 Technical specifications ......................... 12 9.2 Explanation of machine parts ...................... 13 10. EC Declaration of conformity ������������������������������������������������������������������������������������������������������ 14 © BETEX Tools... -
Page 5: Introduction
• The BETEX HXPC is exclusively intended for removing pulleys, bearings, couplings and other symmetric rotation objects mounted on shafts. • The BETEX HXPC is solely for use up to a maximum spread of 840 mm and min./max. height of 210/1550 mm (centreline plunger to surface). -
Page 6: Safety
• Never use the hose to move attached equipment. The tension can cause damage to the hose. This can result in personal injury. • Do not adjust the settings of the internal high pressure relief valve. Creating hydraulic pressure beyond rated capacities can result in personal injury and damage to the machine. © BETEX Tools... -
Page 7: Explanation Of Machine Symbols
2�4 Explanation of machine symbols Consult manual Safety gloves compulsory Ear defenders compulsory Unplug Safety glasses compulsory Safety shoes compulsory Voltage 2�5 Position of symbols on machine © BETEX Tools... -
Page 8: Transport And Storage
• Check whether safety blanket has been supplied. • Remove the parts BETEX HXPC from the pallet e.g. using ramps. • The entire frame must be supported if hoisting devices are used. • Ensure that the hydraulic hoses do not become jammed. -
Page 9: Operation
5. Align the puller jaws and pushing adapter set-ups on the same centerline as the object to be removed. Failure to align parts properly can result in a dangerous operating situation because of the high hydraulic pressure used. WARNING! • Do not apply wheel brakes during removal, as the puller moves backwards. © BETEX Tools... - Page 10 • Falling objects can cause personal injury. The pulling job was not successful� The pulling job was not successful, the pressure is 700 bar (10.000 psi), the object remains in original position. The puller is not suitable for this pulling job. © BETEX Tools...
-
Page 11: Cleaning And Maintenance
8. Disclaimer The manufacturer and/or supplier cannot be held liable for any damage or consequential damage resulting from incorrect use of the device or damage to workpieces and any consequential damage resulting from a defect in the device. © BETEX Tools... -
Page 12: Technical Data
Operating self-centering jaws By threaded rod Adapters 4 items in mm 1 x Ø 40, 1x Ø 50 length 155 Min. height (from the centre) in mm Max. height (from the centre) in mm 1550 Manometer bar Weight kg © BETEX Tools... -
Page 13: Explanation Of Machine Parts
9.2 Explanation of machine parts © BETEX Tools... -
Page 14: Ec Declaration Of Conformity
Manufacturer’s address: Schorsweg 15, 8171 ME Vaassen, NL www.begaspecialtools.com Hereby declares that the products: • BETEX HXPC 50 Ton to which this declaration refers complies with the provisions of the following regulations Machinery Directive • 2006 / 42 / EC In which (parts of) the following standards are applied: •... - Page 15 © BETEX Tools...
