Minolta FAX 1600e Instructions Manual

NOTE
• Do not throw away the box in which the fax was shipped. It is to be
used when transporting the fax.
• Keep all packing materials out of the reach of children.
1. Unpacking Procedures
1. Take the fax machine, the Manual pouch and Accessories Box A and B,
out of the box carefully. Make sure you have all the items listed below.
If any are missing, contact your dealer.
Document Exit Tray
(2)
(3)
4503UE09
4503-7746-01
UNPACKING / SETTING-UP INSTRUCTIONS
(1) Fax Machine
(2) Accessories Box A
• Printer Tray
• Document Feeding
Tray
(1)
• Stopper
• Stopper Mounting
Instructions
(3) Accessories Box B
• Power Cord
• Connecting Cord
• Toner Cartridge
• Drum Cartridge
• Operator's Manual
• Simplified Operator's
Manual
• Quick Reference Sheet
• Function Label
• Warranty Card
(2)
(1)
(3)
©2001
MINOLTAFAX 1600e
2. Take the fax machine out
of the plastic bag and
remove the tape (6 places).
4503UP02
3. Take off the Paper Feeding
Tray Cover and remove the
tape (1) from the Paper
Guide.
Remove the tape from the
recesses of the Paper Feed-
4503UP03
ing Cassette and take out
(3)
the urethane foam (2).
Open the Control Panel and
take out the protective mat
(3) from the Platen Roller.
4503UP04
