MINOLTAFAX5600
PARTS MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Minolta FAX5600

Summary of Contents for Minolta FAX5600

  • Page 1 MINOLTAFAX5600 PARTS MANUAL...
  • Page 2 PREFACE The part numbers listed in Parts Manual are those which were assigned to the parts making up the machine at the time machine was originally introduced onto the market. Parts whose INDEX numbers are shown white against a black background in the illustration are those to be used in only certain market areas. These part numbers are given in the lower half part of the list section.

  • Page 3: Table Of Contents

    CONTENTS HOUSING • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • 1 DRIVE/PAPER TAKE-UP SECTION (A) •...

  • Page 4: Housing

    HOUSING PARTS MANUAL 3704 3704 3704...
  • Page 5 INDEX PART NO. PART NAME 4283-1027-01 HOLDER 4283-1028-01 HOLDER 0997-6102-01 FAN MOTOR 0992-2304-13 COVER 0992-1006-01 ACTUATOR INDEX PART NO. PART NAME INDEX PART NO. SFIX PART NAME...

  • Page 6: Drive/Paper Take-Up Section (A)

    DRIVE/PAPER TAKE-UP SECTION (A) 4307 3504 2514 3907 3504 8302 3501 4307 99 10 3504 9107 3704 3501 1308 3504 9107 3504 3907 3907 PARTS MANUAL 3704 3504 PWB-A 3907 16 18 3907...
  • Page 7 INDEX PART NO. PART NAME 0992-0134-02 PW BOARD 4283-1031-01 LABEL 0992-2001-17 HOLDER 0956-2027-01 RUBBER STRIP 0992-3001-24 ROLLER 4275-1022-01 PWB-PU 0992-2414-02 GROUND PLATE 0992-2308-25 COVER 0992-3008-02 0992-3015-02 HOLDER 0992-3019-01 CLUTCH SPRING 0992-3010-12 GEAR 40T 9335-1410-31 PHOTO INTERRUPTER 0992-3011-02 GEAR 16T 0992-6212-13 SOLENOID 0992-3014-01 BUSHING...

  • Page 8: Drive/Paper Take-Up Section (B)

    DRIVE/PAPER TAKE-UP SECTION (B) 3704 PWB-F 3704 3504 3501 PARTS MANUAL 3519 3907 3704 3501...
  • Page 9 INDEX PART NO. PART NAME 0992-0543-01 PRINT HEAD UNIT 0992-2007-01 TERMINAL 0992-2006-03 TERMINAL 0992-6225-01 PWB-HV 0997-6301-01 SWITCH 0956-2015-01 RUBBER FOOT 0957-0101-01 PW BOARD-G 0992-3025-01 0992-2016-01 GUIDE 0992-2015-01 TORSION SPRING 0992-3007-01 SUPPORT 0992-2024-01 GROUND PLATE 0992-3105-01 SPACER 0992-0761-03 REGULATING PLATE ASSY 9384-1311-11 CABLE TIE 104L INDEX...

  • Page 10: Transfer Unit

    TRANSFER UNIT PARTS MANUAL 3704 3704 3705 3705 3907 3704...
  • Page 11 INDEX PART NO. PART NAME 0992-3709-01 HOLDER 0957-3215-01 BUSHING 0992-3707-01 ROLL 0957-3208-01 GEAR 15T 0992-3720-01 ROLLER 0992-0391-08 TRANSFER UNIT 0992-4206-01 GEAR 21T 0992-4210-01 RING 0992-4205-12 BUSHING 0992-4203-01 GUIDE PLATE 0992-4201-01 ROLLER 0992-4213-01 PLATE 0992-4204-12 BUSHING 0992-0102-24 PW BOARD-R(NO IC) INDEX PART NO.
  • Page 12 FUSING UNIT PARTS MANUAL 3704 12 11 3704 10 09 3704 1305 3704 3704 3704 1305 3405 1305 3704 3704 3704...

  • Page 13: Fusing Unit

    INDEX PART NO. PART NAME 0992-2550-01 0992-2552-02 HOLDER 0992-2551-01 TORSION SPRING 0992-2508-13 GEAR 25/50T 0992-0484-01 FUSING UNIT 0972-5531-01 C-RING 0992-5512-01 GEAR 30T 0992-5521-01 BUSHING 0957-5511-01 BUSHING 0992-5517-13 PRESSURE SPRING 0992-5533-03 SEPARATOR 9335-1410-31 PHOTO INTERRUPTER 0992-7841-01 STOPPER 0992-5553-01 ACTUATOR 0957-5527-02 SEPARATOR ROLL 0992-3706-01 GEAR 40T 0992-0156-13...

  • Page 14: Housing/Panel

    HOUSING/PANEL PARTS MANUAL...
  • Page 15 INDEX PART NO. PART NAME 4283-1013-01 4283-1014-01 4283-1056-01 REAR COVER 4283-1006-01 PANEL ASSY 4283-1036-01 LABEL 4283-1053-01 LABEL 4283-1054-01 ONE-TOUCH SHEET 4283-1005-01 COVER ASSY 4275-1001-01 LCD DISPLAY 4278-1184-01 SPACER 4275-1144-01 HARNESS 4283-1012-01 BUTTON 4283-1007-01 BUTTON 4279-1001-01 KEY TOP 4278-1189-01 SUPPORT 4275-1149-01 HARNESS 4278-1058-01 KEY TOP...

  • Page 16: Transmit Section (A)

    TRANSMIT SECTION (A) PARTS MANUAL...
  • Page 17 INDEX PART NO. PART NAME 4275-1050-01 GEAR 20/46T 4275-1049-01 GEAR 19T 4275-1071-01 GEAR 25T 4275-1068-01 SPACER 4275-1066-01 BUSHING 4283-1059-01 COVER 4275-1175-01 BUSHING 4275-1046-01 GEAR 32T 4275-1183-01 TORQUE LIMITER 4275-1043-01 ROLLER 4275-1075-01 GEAR 4275-1078-01 SHOULDER SCREW 4275-1045-01 PRESSURE SPRING 4275-1165-01 ROLLER ASSY 4283-1018-01 ROLLER ASSY 4275-1164-01...

  • Page 18: Transmit Section (C)

    TRANSMIT SECTION (B) PARTS MANUAL...
  • Page 19 INDEX PART NO. PART NAME 4275-1060-01 LEVER 4283-1062-01 KNOB 4275-1032-01 TENSION SPRING 4278-1125-01 GEAR 4275-1033-01 BUSHING 4278-1124-01 CLUTCH SPRING 4283-1033-01 ROLLER ASSY 4275-1033-01 BUSHING 4283-1061-01 COVER 4275-1058-01 GEAR 4283-1060-01 GUIDE 4275-1004-01 PWB-SWITCH 4275-1005-01 PWB-SWITCH 4279-1033-01 ROLLER INDEX PART NO. PART NAME INDEX PART NO.

  • Page 20: Transmit Section (C)

    TRANSMIT SECTION (C) PARTS MANUAL...
  • Page 21 INDEX PART NO. PART NAME 4253-1027-01 STAMP 4275-1061-01 BRACKET 4275-1034-01 ROLLER 4275-1074-01 GUIDE 4275-1070-01 SET PLATE 4275-1007-01 MICROSWITCH 4275-1072-01 GEAR 21/59T 4275-1073-01 GEAR 19/53T 4220-1085-01 CORD CLAMP 4275-1185-01 MOTOR 4275-1182-01 DAMPER ROLL 4275-1055-01 GLASS 4279-1033-01 ROLLER 4275-1166-01 GUIDE ASSY INDEX PART NO.

  • Page 22: Scanner Section

    SCANNER SECTION PARTS MANUAL...
  • Page 23 INDEX PART NO. PART NAME 4283-1003-01 UNIT PARTS 4283-1021-01 4283-1020-01 LAMP 4275-1027-01 MIRROR 4275-1036-01 MIRROR 4275-1035-01 MIRROR 4275-1010-01 PWB-INVERTER INDEX PART NO. PART NAME INDEX PART NO. SFIX PART NAME...

  • Page 24: Frames

    FRAMES PARTS MANUAL...
  • Page 25 INDEX PART NO. PART NAME 4283-1067-01 COVER 4256-1081-01 WASHER 4275-1157-01 SPEAKER 4283-1066-01 COVER 4283-1064-01 GUIDE 4283-1065-01 GUIDE 4275-1143-01 PWB-CONNECT 4283-1032-01 SHEET 4275-1042-01 GROUND PLATE 4275-1179-01 CORD CLAMP 4275-1178-01 SPACER 4283-1004-01 4275-1011-01 PWB-NCU 4242-1046-01 COVER 4278-1479-01 COVER 4275-1012-01 PWB-MODULAR 4275-1041-01 COVER 4275-1024-01 PWB-PRINTER I/F INDEX...

  • Page 26: Cassette

    CASSETTE PARTS MANUAL...
  • Page 27 INDEX PART NO. PART NAME 4283-1071-01 RIGHT COVER 4275-1026-01 FOOT 4275-1175-01 BUSHING 4275-1017-01 TAKE-UP ROLLER 4275-1116-01 SHEET 4283-1042-01 SPONGE 4275-1122-01 GEAR 13/45T 4275-1123-01 GEAR 23T 4275-1126-01 GEAR 4275-1124-01 GEAR 41T 4275-1118-01 ROLLER 4275-1125-01 GEAR 4283-1041-01 4275-1135-01 SPACER 4254-1099-01 CABLE TIE 4275-1019-01 PWB-SWITCH 4275-1018-01...

  • Page 28: Handset/Accessories

    HANDSET/ACCESSORIES PARTS MANUAL...
  • Page 29 INDEX PART NO. PART NAME 4283-1046-02 COUNTER 4253-1138-01 HOLDER 4283-1079-01 HANDSET 4271-1014-01 SPIRAL CORD 4256-1127-01 MODULAR CORD 4275-1186-01 POWER CORD 4283-1049-01 LABEL 4283-1048-01 SHEET 4283-1076-01 TRAY 4282-1080-01 STAMP 4283-1080-01 MEMORY 2MB 4283-1081-01 MEMORY 4MB 4283-1082-01 MEMORY 8MB 4278-1496-01 4278-1497-01 HARNESS 4278-1498-01 HARNESS 4283-1045-01...

  • Page 30: Screws And Washers

    SCREWS AND WASHERS INDEX PART NO. PART NAME ILLUST 1305 9646-0306-13 SCREW 1308 9646-0308-13 2514 9642-0406-21 SCREW 3405 9733-0310-13 TAPPING SCREW 3501 9735-0306-13 3504 9735-0308-13 TAPPING SCREW 3519 9735-0312-13 3704 9739-0308-13 TAPPING SCREW 3705 9739-0306-13 3907 9742-0308-13 TAPPING SCREW 4307 9770-0308-13 TAPPING SCREW 8302...

  • Page 31: Numerical Index

    NUMERICAL INDEX PART NO. FIG. INDEX PART NO. 0956-2015-01 0992-6505-01 0956-2027-01 0992-6713-01 0957-0101-01 0992-6715-01 0957-3208-01 0992-7841-01 0957-3215-01 0997-6102-01 0957-5511-01 0997-6301-01 0957-5527-02 1200-1236-02 0972-5531-01 4220-1085-01 0992-0102-24 4242-1046-01 0992-0134-02 4253-1027-01 0992-0156-13 4253-1138-01 0992-0391-08 4254-1099-01 0992-0484-01 4256-1081-01 0992-0543-01 4256-1081-01 0992-0751-01 4256-1127-01 0992-0761-03 4271-1014-01 0992-1006-01 4275-1001-01 0992-2001-17...
  • Page 32 Copyright 1999 MINOLTA Co., Ltd. 4283-7995-21 99110000 Printed in Japan...
