Mitsubishi Electric LGH-160RVXT3-E Operating Instructions Manual
Lossnay energy recovery ventilator
Hide thumbs
Also See for LGH-160RVXT3-E:
- Installation instructions manual (38 pages) ,
- Handbook (80 pages)
Table of Contents
Related Manuals for Mitsubishi Electric LGH-160RVXT3-E
Summary of Contents for Mitsubishi Electric LGH-160RVXT3-E
- Page 1 2404N23HHZA0034 Lossnay Energy Recovery Ventilator MODELS: LGH-160RVXT3-E LGH-200RVXT3-E LGH-250RVXT3-E Operating Instructions For the user Please read this manual carefully before use for proper and safe use. Do not attempt to install the product by yourself. Eng-1...
-
Page 2: Safety Precautions
2404N23HHZA0034 Safety precautions The following signs indicate that death or serious injury may be caused by failure to heed the precautions described below. WARNING Incorrect handling could cause serious injury or death. Do not turn the unit on or off when flammable gas has leaked. It could catch fire or cause explosion with sparks released from electrical components. -
Page 3: Names Of The Parts
2404N23HHZA0034 Names of the parts Outlet shutter Hinge Air filter Air exhaust fan (Fan 3) Air exhaust fan (Fan 4) Control cover Maintenance cover Name plate Air supply fan (Fan 1) Air filter Lossnay core Air supply fan (Fan 2) Motor maintenance cover Model name can be found on the Name plate. - Page 4 2404N23HHZA0034 n Display and Function button (PZ-62DR series) Backlit LCD Function buttons ON/OFF lamp MENU RETURN SELECT ON/OFF button button button button n AUTOMATIC VENTILATION setting n “Auto” fan speed control The automatic ventilation mode automatically provides the correct When CO sensor or pressure sensor is connected, “Auto”...
-
Page 5: Maintenance
2404N23HHZA0034 Maintenance Remove all dust and dirt on air filters and Lossnay cores at regular 3. Hold the handle and draw the Lossnay cores out from the main intervals in order to prevent a deterioration in the Lossnay functions. unit. Guideline: Clean the air filters once a year. -
Page 6: Specifications
Exhaust (dB(A)) L1-N L2-N L3-N Temperature (Pa) (Pa) Heating Cooling LGH-160RVXT3-E 1600 61.5 LGH-200RVXT3-E 2000 78.5 56.5 LGH-250RVXT3-E 2500 * The above values apply during Lossnay ventilation when the fan speed is set to Fan speed 4 at the rating pressure loss and 400 V / 50 Hz at factory setting of L/R swiching condtion.
