  • Page 1 GA-945G-DS3 (rev. 2.0) Intel Core 2 Extreme dual-core / Core 2 Duo / ® Intel Pentium D / Pentium 4 LGA775 Processor Motherboard ® ® ® User's Manual Rev. 2002 12ME-945GDS3-2002R * The WEEE marking on the product indicates this product must not be disposed of with user's other household waste and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment!! * The WEEE marking applies only in European Union's member states.
  • Page 3 Gigabyte's prior written permission. Specifications and features are subject to change without prior notice. Product Manual Classification In order to assist in the use of this product, Gigabyte has categorized the user manual in the following: For quick installation, please refer to the "Hardware Installation Guide" included with the product.

  • Page 4: Table Of Contents

    Table of Contents Item Checklist ......................... 6 Optional Accessories ...................... 6 GA-945G-DS3 (rev. 2.0) Motherboard Layout .............. 7 Block Diagram ........................ 8 Chapter 1 Hardware Installation ..................9 Considerations Prior to Installation ..............9 Feature Summary ..................10 Installation of the CPU and CPU Cooler ............12 1-3-1 Installation of the CPU ..................
  • Page 5 Chapter 3 Install Drivers ..................... 49 Install Chipset Drivers ..................49 Software Applications ..................50 Driver CD Information ..................50 Hardware Information ..................51 Contact Us ..................... 51 Chapter 4 Appendix ....................53 Unique Software Utilities ................53 4-1-1 EasyTune 5 Introduction ..................53 4-1-2 Xpress Recovery2 Introduction .................

  • Page 6: Item Checklist

    Item Checklist IDE Cable x 1 and FDD Cable x 1 SATA 3Gb/s Cable x 2 I/O Shield * The items listed above are for reference only, and are subject to change without notice. Optional Accessories 2 Ports USB 2.0 Cable (Part Number: 12CR1-1UB030-51/R) 4 Ports USB 2.0 Cable (Part Number: 12CR1-1UB030-21/R) SPDIF In and Out Cable (Part Number: 12CR1-1SPINO-11/R) e-SATA Cable (Part Number: 12CF1-3SATPW-11R)

  • Page 7: Ga-945G-Ds3 (Rev. 2.0) Motherboard Layout

    GA-945G-DS3 (rev. 2.0) Motherboard Layout CPU_FAN ATX_12V KB_MS LGA775 Intel 945G AUDIO ® NB_FAN PCIE_3 RTL8111B PCIE_16 PWR_FAN PCIE_1 CLR_CMOS Intel ® ICH7 PCIE_2 CODEC BATTERY PCI1 SATAII0 SATAII2 BIOS PCI2 SATAII1 SATAII3 IDE1 PCI3 F_PANEL CD_IN SPDIF_IO SYS_FAN F_USB1...

  • Page 8: Block Diagram

    Block Diagram PCIe CLK CPU CLK+/-(266/200/133 MHz) LGA775 (100 MHz) Processor Host Interface DDRII 667/533/400 MHz DIMM (Note) PCI Express x16 Dual Channel Memory Intel ® 945G GMCH CLK (266/200/133 MHz) RJ45 RTL8111B BIOS PCI Express Bus ATA33/66/100 3 PCI Express x1 IDE Channel 4 SATA 3Gb/s Intel...

  • Page 9: Chapter 1 Hardware Installation

    2. Damage as a result of violating the conditions recommended in the user manual. 3. Damage due to improper installation. 4. Damage due to use of uncertified components. 5. Damage due to use exceeding the permitted parameters. 6. Product determined to be an unofficial Gigabyte product. - 9 - Hardware Installation...

  • Page 10: Feature Summary

    1 front panel connector 1 front audio connector 1 CD In connector 1 S/PDIF In/Out connector 2 USB 2.0/1.1 connectors for additional 4 ports by cables 1 Chassis Intrusion connector 1 power LED connector GA-945G-DS3 (rev. 2.0) Motherboard - 10 -...
  • Page 11 Rear Panel I/O 1 PS/2 keyboard port 1 PS/2 mouse port 1 parallel port 1 serial port (COMA) 1 VGA port 4 USB 2.0/1.1 ports 1 RJ-45 port 6 audio jacks (Line In / Line Out / MIC In / Surround Speaker Out (Rear Speaker Out) / Center/Subwoofer Speaker Out / Side Speaker Out) I/O Control IT8718 chip...

  • Page 12: Installation Of The Cpu And Cpu Cooler

    (Grasping the CPU firmly between your thumb and forefinger, carefully place it into the socket in a straight and downwards motion. Avoid twisting or bending motions that might cause damage to the CPU during installation.) GA-945G-DS3 (rev. 2.0) Motherboard - 12 -...

  • Page 13: Installation Of The Cpu Cooler

    1-3-2 Installation of the CPU Cooler Male Push Pin The top of Female Push Pin Female Push Pin Fig.1 Fig. 2 Please apply an even layer of CPU cooler paste (Turning the push pin along the direction of arrow is to on the surface of the installed CPU.

  • Page 14: Installation Of Memory

    DIMM socket. Then push it down. Fig.2 Close the plastic clip at both edges of the DIMM sockets to lock the DIMM module. Reverse the installation steps when you wish to remove the DIMM module. GA-945G-DS3 (rev. 2.0) Motherboard - 14 -...
  • Page 15 The GA-945G-DS3 supports the Dual Channel Technology. After operating the Dual Channel Technology, the bandwidth of memory bus will double. The GA-945G-DS3 includes 4 DIMM sockets, and each Channel has two DIMM sockets as following: Channel 0 : DDRII1, DDRII2...

  • Page 16: Installation Of Expansion Cards

    PCI Express x16 slot. To remove the VGA card from the PCI Expressx16 slot, you can press the latch as the picture to the left shows to release the card. GA-945G-DS3 (rev. 2.0) Motherboard - 16 -...

  • Page 17: I/O Back Panel Introduction

    I/O Back Panel Introduction PS/2 Keyboard and PS/2 Mouse Connector To install a PS/2 port keyboard and mouse, plug the mouse to the upper port (green) and the keyboard to the lower port (purple). Parallel Port The parallel port allows connection of a printer, scanner and other peripheral devices. Serial Port Connects to serial-based mouse or data processing devices.

  • Page 18: Connectors Introduction

    ). Please refer to the 2-/4-/6-/8- channel audio setup steps for detailed software configuration information. Connectors Introduction 14 4 ATX_12V PWR_LED ATX (Power Connector) F_PANEL CPU_FAN F_AUDIO SYS_FAN CD_IN PWR_FAN SPDIF_IO NB_FAN F_USB1 / F_USB2 IDE1 CLR_CMOS SATAII0/1/2/3 BATTERY GA-945G-DS3 (rev. 2.0) Motherboard - 18 -...
  • Page 19 1/2) ATX_12V / ATX (Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, please make sure that all components and devices are properly installed. Align the power connector with its proper location on the motherboard and connect tightly.
  • Page 20 PWR_FAN 6) NB_FAN (Chip Fan Power Connector) The chip fan will not work if you install it in the wrong direction and sometimes the chip fan will be damaged. Pin No. Definition +12V GA-945G-DS3 (rev. 2.0) Motherboard - 20 -...
  • Page 21 7) FDD (Floppy Connector) The FDD connector is used to connect the FDD cable while the other end of the cable connects to the FDD drive. The types of FDD drives supported are: 360 KB, 720 KB, 1.2 MB, 1.44 MB and 2.88 MB.
  • Page 22 10) PWR_LED The PWR_LED connector is connected with the system power indicator to indicate whether the system is on/off. It will blink when the system enters suspend mode. Pin No. Definition MPD+ MPD- MPD- GA-945G-DS3 (rev. 2.0) Motherboard - 22 -...
  • Page 23 11) F_PANEL (Front Panel Jumper) Please connect the power LED, PC speaker, reset switch and power switch etc. of your chassis front panel to the F_PANEL connector according to the pin assignment below. Message LED/ Speaker Connector Power Power/ Switch Sleep LED Reset Switch IDE Hard Disk Active LED...

  • Page 24: Front Audio Connector

    70 about the software settings. 13) CD_IN (CD In Connector) Connect CD-ROM or DVD-ROM audio out to the connector. Pin No. Definition CD-L CD-R GA-945G-DS3 (rev. 2.0) Motherboard - 24 -...
  • Page 25 14) SPDIF_IO (S/PDIF In/Out Connector) The S/PDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby Digital Decoder. Use this feature only when your stereo system has digital input function. Use S/PDIF IN feature only when your device has digital output function. Be careful with the polarity of the SPDIF_IO connector.
  • Page 26 You may clear the CMOS data to its default values by this header. To clear CMOS, temporarily short the two pins. Default doesn't include the jumper to avoid improper use of this header. Open: Normal Short: Clear CMOS GA-945G-DS3 (rev. 2.0) Motherboard - 26 -...
  • Page 27 18) BATTERY Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. If you want to erase CMOS... 1. Turn off the computer and unplug the power cord. 2.
  • Page 28 GA-945G-DS3 (rev. 2.0) Motherboard - 28 -...

  • Page 29: Chapter 2 Bios Setup

    CMOS SETUP screen. You can enter the BIOS setup screen by pressing "Ctrl + F1". If you wish to upgrade to a new BIOS, either GIGABYTE's Q-Flash or @BIOS utility can be used. Q-Flash allows the user to quickly and easily update or backup BIOS without entering the operating system.

  • Page 30: The Main Menu (For Example: Bios Ver. : F1A)

    This action makes the system reset to the default settings for stability. 3. The BIOS Setup menus described in this chapter are for reference only and may differ from the exact settings for your motherboard. GA-945G-DS3 (rev. 2.0) Motherboard - 30 -...
  • Page 31 Standard CMOS Features This setup page includes all the items in standard compatible BIOS. Advanced BIOS Features This setup page includes all the items of Award special enhanced features. Integrated Peripherals This setup page includes all onboard peripherals. Power Management Setup This setup page includes all the items of Green function features.

  • Page 32: Standard Cmos Features

    Select this if no IDE/SATA devices are used and the system will skip the automatic detection step and allow for faster system start up. Access Mode Use this to set the access mode for the hard drive. The two options are: Large/Auto(default:Auto) GA-945G-DS3 (rev. 2.0) Motherboard - 32 -...
  • Page 33 Capacity Capacity of currently installed hard drive. Hard drive information should be labeled on the outside drive casing. Enter the appropriate option based on this information. Cylinder Number of cylinders Head Number of heads Precomp Write precomp Landing Zone Landing zone Sector Number of sectors Drive A...

  • Page 34: Advanced Bios Features

    (Default value) If you want to cancel the setting of password, please just press ENTER to make [SETUP] empty. (Note) This item will show up when you install a processor which supports this function. GA-945G-DS3 (rev. 2.0) Motherboard - 34 -...
  • Page 35 HDD S.M.A.R.T. Capability This feature allows your hard disk to report read/write errors and to issue warnings when third- party hardware monitor utility is installed. Enabled Enable HDD S.M.A.R.T. capability. Disabled Disable HDD S.M.A.R.T. capability. (Default value) CPU Hyper-Threading (Note) Enabled Enable CPU Hyper Threading Feature.

  • Page 36: Integrated Peripherals

    This value will auto make by the setting "On-Chip SATA Mode" and "PATA IDE Set to". If PATA IDE were set to Ch. 0 Master/Slave, this function will auto set to Ch. 1 Master/Slave. USB Controller Enabled Enable USB controller. (Default value) Disabled Disable USB controller. GA-945G-DS3 (rev. 2.0) Motherboard - 36 -...
  • Page 37 USB 2.0 Controller You can disable this function if you are not using onboard USB 2.0 feature. Enabled Enable USB 2.0 controller. (Default value) Disabled Disable USB 2.0 controller. USB Keyboard Support Enabled Enable USB keyboard support. Disabled Disable USB keyboard support. (Default value) USB Mouse Support Enabled Enable USB mouse support.
  • Page 38 Using Parallel port as Extended Capabilities Port. ECP+EPP Using Parallel port as ECP & EPP mode. ECP Mode Use DMA Set ECP Mode Use DMA to 3. (Default value) Set ECP Mode Use DMA to 1. GA-945G-DS3 (rev. 2.0) Motherboard - 38 -...

  • Page 39: Power Management Setup

    Power Management Setup CMOS Setup Utility-Copyright (C) 1984-2006 Award Software Power Management Setup ACPI Suspend Type [S1(POS)] Item Help Soft-Off by PWR-BTTN [Instant-Off] Menu Level PME Event Wake Up [Enabled] Power On by Ring [Enabled] Resume by Alarm [Disabled] x Date (of Month) Alarm Everyday x Time (hh:mm:ss) Alarm 0 : 0 : 0...
  • Page 40 (Default value) Full-On When AC-power back to the system, the system always in "On" state. Memory When AC-power back to the system, the system will return to the Last state before AC-power off. GA-945G-DS3 (rev. 2.0) Motherboard - 40 -...

  • Page 41: Pnp/Pci Configurations

    PnP/PCI Configurations CMOS Setup Utility-Copyright (C) 1984-2006 Award Software PnP/PCI Configurations PCI 1 IRQ Assignment [Auto] Item Help PCI 2 IRQ Assignment [Auto] Menu Level PCI 3 IRQ Assignment [Auto] : Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help F5: Previous Values F6: Fail-Safe Defaults...

  • Page 42: Pc Health Status

    Monitor CPU temperature at 90 C / 194 Disabled Disable this function. (Default value) CPU/POWER/SYSTEM FAN Fail Warning Disabled Disable the fan fail warning function. (Default value) Enabled Enable the fan fail warning function. GA-945G-DS3 (rev. 2.0) Motherboard - 42 -...
  • Page 43 CPU Smart FAN Control Disabled Disable this function. Enabled When this function is enabled, CPU fan will run at different speed depending on CPU temperature. Users can adjust the fan speed with Easy Tune based on their requirements. (Default value) CPU Smart FAN Mode This option is available only when CPU Smart FAN Control is enabled.

  • Page 44: Mb Intelligent Tweaker(M.i.t.)

    Set C.I.A.2 to Racing. (Automatically increase CPU frequency(9%,11%) by CPU loading. Turbo Set C.I.A.2 to Turbo. (Automatically increase CPU frequency(15%,17%) by CPU loading. (Note) This item will show up when you install a processor which supports this function. GA-945G-DS3 (rev. 2.0) Motherboard - 44 -...
  • Page 45 Full Thrust Set C.I.A.2 to Full Thrust. (Automatically increase CPU frequency(17%, 19%) by CPU loading. Warning: Stability is highly dependent on system components. CPU Host Clock Control Please note that if your system is overclocked and cannot restart, please wait 20secs. for automatic system restart or clear the CMOS setup data and perform a safe restart.

  • Page 46: Load Fail-Safe Defaults

    ESC: Quit : Select Item F8: Q-Flash F10: Save & Exit Setup Load Optimized Defaults Selecting this field loads the factory defaults for BIOS and Chipset Features which the system automati- cally detects. GA-945G-DS3 (rev. 2.0) Motherboard - 46 -...

  • Page 47: Set Supervisor/User Password

    2-10 Set Supervisor/User Password CMOS Setup Utility-Copyright (C) 1984-2006 Award Software Standard CMOS Features Load Fail-Safe Defaults Advanced BIOS Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations Save & Exit Setup Enter Password: PC Health Status Exit Without Saving...

  • Page 48: Save & Exit Setup

    ESC: Quit : Select Item F8: Q-Flash F10: Save & Exit Setup Abandon all Data Type "Y" will quit the Setup Utility without saving to RTC CMOS. Type "N" will return to Setup Utility. GA-945G-DS3 (rev. 2.0) Motherboard - 48 -...

  • Page 49: Chapter 3 Install Drivers

    Chapter 3 Install Drivers Pictures below are shown in Windows XP. Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the Run.exe.

  • Page 50: Software Applications

    Software Applications This page displays all the tools that Gigabyte developed and some free software, you can choose anyone you want and press "install" to install them. Driver CD Information This page lists the contents of software and drivers in this CD-title.

  • Page 51: Hardware Information

    Hardware Information This page lists all device you have for this motherboard. Contact Us Please see the last page for details. - 51 - Install Drivers...
  • Page 52 GA-945G-DS3 (rev. 2.0) Motherboard - 52 -...

  • Page 53: Chapter 4 Appendix

    Toggles between Easy and Advance Mode Display screen Display panel of CPU frequency Function display LEDs Shows the current functions status GIGABYTE Logo Log on to GIGABYTE website Help button Display EasyTune 5 Help file Exit or Minimize button Quit or Minimize EasyTune...

  • Page 54: Xpress Recovery2 Introduction

    2. System storage capacity and the reading/writing speed of the hard disk will affect the data backup speed. 3. It is recommended that Xpress Recovery2 be immediately installed once you com- plete installations of OS and all required drivers as well as software. GA-945G-DS3 (rev. 2.0) Motherboard - 54 -...
  • Page 55 The Main Screen of Xpress Recovery2 1. RESTORE: Restore the backed-up data to your hard disk. (This button will not appear if there is no backup file.) 2. BACKUP: Back up data from hard disk. 3. REMOVE: Remove previously-created backup files to release disk space.

  • Page 56: Flash Bios Method Introduction

    Updating BIOS with Q-Flash Utility on Dual BIOS Motherboards. Some of Gigabyte motherboards are equipped with dual BIOS. In the BIOS menu of the motherboards supporting Q-Flash and Dual BIOS, the Q-Flash utility and Dual BIOS utility are combined in the same screen.
  • Page 57 Entering the Q-Flash utility: Step1: To use Q-Flash utility, you must press Del in the boot screen to enter BIOS menu. CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Select Language Advanced BIOS Features Load Fail-Safe Defaults Integrated Peripherals Load Optimized Defaults Power Management Setup Set Supervisor Password...
  • Page 58 Save Main BIOS to Floppy Save Backup BIOS to Floppy Enter : Run :Move ESC:Reset F10:Power Off After BIOS file is read, you'll see a confirmation dialog box asking you "Are you sure to update BIOS?" GA-945G-DS3 (rev. 2.0) Motherboard - 58 -...
  • Page 59 3. Press Y button on your keyboard after you are sure to update BIOS. Then it will begin to update BIOS. The progress of updating BIOS will be displayed. Please do not take out the floppy disk when it begins flashing BIOS. 4.
  • Page 60 Set User Password PC Health Status Save & Exit Setup MB Intelligent Tweaker(M.I.T.) Exit Without Saving Esc: Quit : Select Item F8: Q-Flash F10: Save & Exit Setup Time, Date, Hard Disk Type... GA-945G-DS3 (rev. 2.0) Motherboard - 60 -...
  • Page 61 Exploring the Q-Flash utility screen The Q-FlashBIOS utility screen consists of the following key components. Q-Flash utility bar Q-Flash Utility V1.30 Flash Type/Size.........SST 49LF003A 256K Keep DMI Data Enable Task menu for Update BIOS from Floppy Q-Flash utility Save BIOS to Floppy Action bar Enter : Run :Move...
  • Page 62 Press Del to enter BIOS menu after system reboots and "Load BIOS Fail-Safe Defaults". See how to Load BIOS Fail-Safe Defaults, please kindly refer to Step 6 to 7 in Part One. Congratulation!! You have updated BIOS successfully!! GA-945G-DS3 (rev. 2.0) Motherboard - 62 -...
  • Page 63 BIOS. Fig 1. Installing the @BIOS utility Fig 2. Installation Complete and Run @BIOS Click Start/ Programs/ Gigabyte/ BIOS/ @BIOS Select @BIOS item than click Install Fig 3. The @BIOS Utility Fig 4. Select the desired @BIOS server Click "...
  • Page 64 III. In method I, if the BIOS file you need cannot be found in @BIOS server, please go onto Gigabyte's web site for downloading and updating it according to method II. IV. Please note that any interruption during updating will cause system unbooted.

  • Page 65: 4- / 6- / 8- Channel Audio Introduction

    4-1-4 2- / 4- / 6- / 8- Channel Audio Introduction The default speaker settings for the 6 audio jacks are as shown in the picture to the right. The jack retasking capability supported by HD Audio allows Center/Subwoofer users to change the function for each audio jack by Speaker Out Line In the audio software provided.
  • Page 66 Out jack, a small window will pop up and ask you what type of equipment is connected. Choose Headphone or Line Out depending on the device connected and click OK. The 2-channel audio setup is completed. GA-945G-DS3 (rev. 2.0) Motherboard - 66 -...
  • Page 67 Setting Up 4-Channel Audio STEP 1 : After installation of the audio driver, you should find an Audio Manager icon in your system tray (you can also find the icon in Control Panel). Double- click the icon to open the Audio Control Panel. STEP 2: In the Audio Control Panel, click the Audio I/O tab.
  • Page 68 Choose a device depend- ing on the type of speaker connected (6-channel audio consists of Front Speaker Out (Line Out), Rear Speaker Out, and Center/Subwoofer Speaker Out) then click OK. The 6-channel audio setup is completed. GA-945G-DS3 (rev. 2.0) Motherboard - 68 -...
  • Page 69 Setting Up 8-Channel Audio STEP 1 : After installation of the audio driver, you should find an Audio Manager icon in your system tray (you can also find the icon in Control Panel). Double- click the icon to open the Audio Control Panel. STEP 2: In the Audio Control Panel, click the Audio I/O tab.
  • Page 70 Panel and click the Audio I/O tab. In the ANA- LOG area, click the Tool icon and then select the Disable front panel jack detection check box. This action completes the AC'97 Audio configuration. GA-945G-DS3 (rev. 2.0) Motherboard - 70 -...

  • Page 71: Troubleshooting

    Below is a collection of general asked questions. To check general asked questions based on a specific motherboard model, please log on to http://www.gigabyte.com.tw Question 1: I cannot see some options that were included in previous BIOS after updating BIOS. Why? Answer: Some advanced options are hidden in new BIOS version.
  • Page 72 GA-945G-DS3 (rev. 2.0) Motherboard - 72 -...
  • Page 73 - 73 - Appendix...
  • Page 74 GA-945G-DS3 (rev. 2.0) Motherboard - 74 -...
  • Page 75 - 75 - Appendix...
  • Page 76 GA-945G-DS3 (rev. 2.0) Motherboard - 76 -...
  • Page 77 - 77 - Appendix...
  • Page 78 GIGABYTE TECHNOLOGY (INDIA) LIMITED NIPPON GIGA-BYTE CORPORATION WEB address : http://www.gigabyte.in WEB address : http://www.gigabyte.co.jp Australia Singapore GIGABYTE TECHNOLOGY PTY. LTD. GIGA-BYTE SINGAPORE PTE. LTD. WEB address : http://www.gigabyte.com.au WEB address : http://www.gigabyte.com.sg GA-945G-DS3 (rev. 2.0) Motherboard - 78 -...
  • Page 79 Germany Russia G.B.T. TECHNOLOGY TRADING GMBH Moscow Representative Office Of GIGA-BYTE Technology WEB address : http://www.gigabyte.de Co., Ltd. U.K. WEB address : http://www.gigabyte.ru G.B.T. TECH. CO., LTD. Latvia WEB address : http://www.giga-byte.co.uk GIGA-BYTE Latvia The Netherlands WEB address : http://www.gigabyte.com.lv GIGA-BYTE TECHNOLOGY B.V.
  • Page 80 - 80 -...
