Do you have a question about the Z8 and is the answer not in the manual?

Questions and answers

aaron hoy
May 27, 2025

what voltage setting should i use and whats the difference between using each of them. for riding times z8 single motor ebike

1 comments:
Mr. Anderson
May 27, 2025

The Riding'Times Z8 single motor e-bike should use the 48V voltage setting. The difference between the settings is:

- 36V: Lower voltage, typically results in less power and range.
- 48V: Higher voltage, provides more power and a longer range, which matches the Z8's 48V battery specification.

This answer is automatically generated

Len
January 27, 2025

What does fault code E008 motor failure code mean

User image 6798173c73fe0
1 comments:
Mr. Anderson
May 14, 2025

Fault code E08 means there is a Motor Phase-Wire Short Circuit or Controller Fault. It may be caused by shorted or damaged motor phase wires or internal controller damage. The solution is to check the motor phase wires (yellow, green, blue) for damage and replace the motor if needed. Also, unplug and replug the controller phase-wire connectors. If the error disappears temporarily but returns, the controller may need replacement.

This answer is automatically generated

STEVE SIMMONS
June 28, 2025

Why is my controller ticking ? Can you send a link for a replacement for my Z8PRO?

Joseph Silva
June 20, 2025

Can I charge the battery without taking it off of the bike?

User image 6854a6b9a7cd6

Summary of Contents for Riding'Times Z8

  • Page 2 Original Instructions User's Manual Electric Bike Z8 The picture is for reference only. Before using the product, please read this manual. IMPORTANT! Read carefully and keep for future reference.
  • Page 3 Welcome 1. Join the Riding'times community of riders wherever you are! This is just the beginning of your adventure with us! We look forward to hearing about your experience and seeing you online on our social networks: Tag us! @Ridingtimes #Ridingtimes 2.
  • Page 4 3. Customer Service: EN:Our product technology is already very mature, with 20 years of trade, we have distributors all over the world who can provide you with the most localized and professional technical support within 24 hours. DE:Unsere Produkttechnologie ist sehr ausgereift, mit 20 Jahren Handel haben wir weltweit Vertreter, die Ihnen innerhalb von 24 Stunden die bestmögliche lokalisierte und professionelle technische Unterstützung bieten.
  • Page 5 European Union Compliance Statement Battery recycling information for the European Union Batteries or packaging for batteries are labeled in accordance with European Directive 2006/66/EC concerning batteries and accumulators and waste batteries and accumulators. The Directive determines the framework for there turn and recycling of used batter es and accumulators as applicable throughout the European Union.
  • Page 6 Bike frames and parts have limitations, and extreme riding should not be performed. Z8 assumes no liability for any accident, injuries,or property damage incurred as a result of rider’s use or misuse of Z8 bicycles, including any damages resulting from or arising out of off-road usage.
  • Page 7 • If you have an impairment or disability such as visual impairment, hearing impairment, physical impairment, cognitive/language impairment, and/or a seizure disorder, consult your physician before riding our bikes. • Be careful to keep your body parts and other objects away from the sharp teeth of chain rings, moving chain, turning pedals and crank, and the spinning wheels of your bicycle.
  • Page 8: Table Of Contents

    Contents 1. Components Diagram --------------------------------------------------------------6 2. Assemble Electric Bike ------------------------------------------------------------- 7 3. Technical Parameters -------------------------------------------------------------- 11 4. Battery Instructions ---------------------------------------------------------------- 11 5. Instructions of The Dashboard -------------------------------------------------- 13 6. Considerations ----------------------------------------------------------------------- 22 7. Maintenance and Cleaning ------------------------------------------------------- 22 8. Troubleshooting Instructions ---------------------------------------------------- 23 9.
  • Page 9: Components Diagram

    1. Components Diagram...
  • Page 10: Assemble Electric Bike

    2. Assemble Electric Bike Take out of the electric bike from the box (Figure 1). Figure 1 (2) Assemble the handlebar: Put the handlebar into the center of the vertical bar (Figure 1), fasten the screws by using NO.4 Allen Wrench (Figure 2) . Figure 2 Figure 1...
  • Page 11 (3) Assemble the front wheel: Put the front wheel on the suspension fork, disc brake is the left of the ebike. Take out of the quick release bag from the accessory box, insert to the front wheel axle hole, twist the quick release nut to the right tightness, move down to remove the handle.
  • Page 12 (5) Insert the connection cable: Insert and connect the cable of the left/right brakes, speed swivel, dashboard, three-in-one switch based on the color, pay attention to the cable connector directions (Figure 1) , manage the cable harness (Figure 2). Figure 2 Figure 1 (6) Assemble the front mudguard: Put the mudguard on the wheel, and use the NO.4 Allen wrench and the open spanner fixed the mudguard on the front fork.
  • Page 13 (7) Assemble the pedal plate: Take out of the left and right pedal plate, “L “is for left side and “R” is for the right side (Figure 1) , put the pedal plate on the crank, fasten it by using the open spanner (Figure 2) . Figure 2 Figure 1 (8) Manage the cable harness: Take out of the winding tube from the accessory box, put the left brake cable, brake...
  • Page 14: Technical Parameters

    3. Technical Parameters Product Model Battery 48V 15Ah Load 1 20 KG Mileage (Depends on load, terrain and riding 40- 90KM habits) Charging time 7-9 hours Wheel diameter 20 inches Charger 54.6V 2A 4. Battery Instructions (1) Battery charging This bicycle is an external lithium battery, which can be removed for charging. When the battery is low, open the key and take out the battery.
  • Page 15 · Do not immerse the pack in water and seawater Guard against Damp. · Do not use and leave the pack near a heat source such as fire or heater. · When recharging, use the battery charger specifically for that purpose. ·...
  • Page 16: Instructions Of The Dashboard

    5. Instructions of Dashboard (1). Product name and model Intelligent LCD display for ebike; model: YL81C (2). Specifications 36V/48V power supply Rated working current 15mA Maximum working current 30mA Leakage current at power-off<1uA Working current at the supply controller end 50mA Working temperature- 2 0 ~ 6 0 ℃...
  • Page 17 (4). Function overview and functional area layout 1). Function overview Display YL81C provides a variety of functions to meet the riding needs of users, including: · Battery level indicator · Assist level adjustment and indication · Headlight indicator · Speed indicator: including real-time speed, maximum speed (MAXS) and average speed (AVG) ·...
  • Page 18 Display Interface Switching 3). Push assistance By pressing and holding the button the electric push assistance mode will be enabled. Your ebike will run at a constant speed of 6km/h. The display will show level “P”. By releasing the button, your e-bike will immediately stop power output and return to the state before push assistance.
  • Page 19 4). Assist level selection By pressing the button , the ebike assist level will be switched to change the motor output power. The assist levels available for the display levels 0-5. Assist Level Switching Interface 5). Battery level indicator The battery level indicator consists of five segments. When the battery is fully charged, the five segments will be all on. In case of under voltage, the outline of the battery indicator will flash, which means the battery has to be charged immediately.
  • Page 20 Error Code Indicator Interface When an error code appears on the display interface, please conduct troubleshooting in time. Otherwise, your ebike will not work normally. (6). General setting All parameters can only be set when your ebike stops. The steps for the general setting are as follows: In the power-on state, when the display shows the speed of 0.
  • Page 21 (7). Custom setting All parameters can only be set when your ebike stops. The steps focus on setting are as follows: In the power-on state, when the display shows the speed of 0. Press and hold the buttons the same time for more than 2 seconds to enter the selection interface of custom setting options. Press the button to switch the selection interface of general setting options, and press the ▶...
  • Page 22 3). Speed limit setting P3 represents the speed limit setting option. The adjustable range is 10~40km/h. Press the button enter the parameter modification interface. Press the button for parameter selection. Press the button to save the parameter and return to the selection interface of general setting options. Speed Limit Setting Interface 4).
  • Page 23 5). Speed sensor setting P5 refers to the speed sensor setting option, which can be set according to the number of magnetic heads installed on the wheels of your e-bike. The setting range is 1-63. Press the button to enter the parameter modification interface.
  • Page 24 7). Assistance sensor setting P7 refers to assistance sensor setting. The adjustable range is 1-25A . Set the number of booster disk magnets, adjustable range: 5, 6, 7, 8, 9, 10, 12. Press the button to enter the parameter modification interface. Press the button for parameter selection.
  • Page 25: Considerations

    Considerations Please use it safely, and do not plug or unplug the display when it is powered on. · Please avoid bumping as far as possible. · Please do not alter the background parameter settings of the display at will otherwise normal riding cannot be guaranteed ·...
  • Page 26: Troubleshooting Instructions

    Troubleshooting Instructions Instrument error code Fault name Fault name Fault code Fault code Controller failure E001 E004 Handle failure E002 Communication failure E005 Brake handle failure E003 E006 Hall fault Motor failure Warranty (1). Warranty information For the faults caused by the quality of the product under normal use, the company will be responsible for ·...
