IMPORTANT INSTRUCTIONS
AND OPERATING MANUAL
M2305 ELECTRIC FIREPLACE
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 213-4467172 or 661-4358826
Monday - Sunday 8:30 am -5:30 pm P.S.T
ROWAN ELECTRIC APPLIANCE LLC 28407 Ascent Way,
Santa Clarita, CA 91350
60MIN
- Unit can tip over causing severe injury.
- Anchor unit to study on wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
Advertisement
Related Manuals for ROWAN ELECTRIC APPLIANCE M2305
Summary of Contents for ROWAN ELECTRIC APPLIANCE M2305
- Page 1 Contact our customer service team for help first. Call: 213-4467172 or 661-4358826 Monday - Sunday 8:30 am -5:30 pm P.S.T ROWAN ELECTRIC APPLIANCE LLC 28407 Ascent Way, Santa Clarita, CA 91350 60MIN - Unit can tip over causing severe injury.
- Page 3 -Do NOT use harsh chemicals or abrasive cleaners on this item.
-
Page 4: Parts List
PARTS LIST - 4 -... -
Page 5: Hardware List
HARDWARE LIST X 29 X 29 X 24 Ø6.5 x35mm Ø15 x 12mm Ø8 x 30mm Ø3 x 14mm X 26 Ø3 x 12mm Ø4 x 25mm - 5 -... - Page 6 DIMENSIONS 1472mm / 57.95" 400mm / 15.75" 454mm / 17.87" 707mm / 27.83" 707mm / 27.83" 560mm / 22.05" 1436mm / 56.54" 385mm / 15.16" 1472mm / 57.95" 400mm / 15.75" ASSEMBLY Before installing this fireplace, please read the following steps carefully. - 6 -...
- Page 7 STEP 1: Screw bolts (A) to panels (1)+(2)+(3)+(4)+(5)+(11). Attach door stoppers (E1) to panels (4)+(5) by securing screws (D). Attach door stoppers (E2) to doors (6)+(7) by securing screws (D). Attach knobs (H) to doors (6)+(7) by securing screws (I). X 29 - 7-...
- Page 8 STEP 2: Join panels (4)+(5) to panel (1) by inserting bolts (A) and dowels (C). Lock them by inserting and securing excenter fittings (B). - 8 -...
- Page 9 STEP 3: Join panels (8) by inserting bolts (A) and dowels (C). Lock them by inserting and securing excenter fittings (B). - 9 -...
- Page 10 STEP 4: Join panels (2)+(3) by inserting bolts (A) and dowels (C). Lock them by inserting and securing excenter fittings (B). Join foot (12) by securing screws (K). - 10 -...
- Page 11 STEP 5: Join the panel (9) to panel (11) by inserting bolts (A). Lock it by inserting and securing excenter fittings (B). - 11 -...
- Page 12 STEP 6: Join panels (11)+(9) by inserting bolts (A) and dowels (C). Lock them by inserting and securing excenter fittings (B). - 12 -...
- Page 13 STEP 7: Join panels (10) by securing screws (F). X 22 - 13 -...
- Page 14 STEP 8: Join doors (6)+(7) by inserting the hinges. - 14 -...
- Page 15 STEP 9: Adjust the door's position by loosing, moving, and tightening the hinges. - 15 -...
- Page 16 STEP 10: Install the firebox by securing screws (K). - 16 -...
