Assembly Instructions

BBQ Side Table

Code: 00314

(W x D x H) 0.91m x 0.52m x 0.85m

ONLINE ASSEMBLY VIDEO AVAILABLE

Please scan the QR code or visit zestoutdoorlivingsupport.co.uk

PLEASE KEEP THESE INSTRUCTIONS

www.zestoutdoorliving.co.uk | 01352 752555 option 1 | sales@zestoutdoorliving.co.uk

Need help?

Do you have a question about the 00314 and is the answer not in the manual?

Page 1 Assembly Instructions BBQ Side Table Code: 00314 (W x D x H) 0.91m x 0.52m x 0.85m ONLINE ASSEMBLY VIDEO AVAILABLE Please scan the QR code or visit zestoutdoorlivingsupport.co.uk PLEASE KEEP THESE INSTRUCTIONS www.zestoutdoorliving.co.uk | 01352 752555 option 1 | sales@zestoutdoorliving.co.uk...
Page 2 Every Zest product is unique because each piece of timber has its own distinctive, natural features. Zest sources all of its timber from This is vital not only for the health responsibly-managed forests of the planet, but also shows Zest’s...
Page 3 BBQ Side Table Assembly Instructions Requires 2 person assembly. Tools required: Corded / Cordless Drill, Pozi-drive Bit / Screwdriver, 3mm Drill Bit required in order for you to drill all screw holes before construction. Please take a few moments to check all pack contents listed BBQ Side Table Pack List Code Item...
Page 4 Attach Lower Shelf A to Legs B using 2no Screws per leg, ensuring correct orientation of Legs B - Section ‘x’ lowermost (Fig.1a). Position Upper Shelf C as shown in Fig.1b and attach using 2no screws per leg. Invert Table Top D and place on flat surface. Position Diagonal Bracing E as shown in Fig. 2a and attach using 2no Screws (Fig.2b).
Page 5 Attach Table Top D to Legs B using 1no Screw per leg as shown in Fig. 4. Your BBQ Side Table is now complete. www.zestoutdoorliving.co.uk | 01352 752555 option 1 | sales@zestoutdoorliving.co.uk...
