Assembly Instructions

Tatton Gazebo

Code: 00629

V2 05 24

(W x D x H) 2.64m x 2.64m x 2.49m

ONLINE ASSEMBLY VIDEO AVAILABLE

Please scan the QR code or visit zestoutdoorlivingsupport.co.uk

PLEASE KEEP THESE INSTRUCTIONS

www.zestoutdoorliving.co.uk | 01352 873555 | sales@zestoutdoorliving.co.uk

of 9

Need help?

Do you have a question about the Tatton and is the answer not in the manual?

Questions and answers

Summary of Contents for Zest Tatton

Page 1 Assembly Instructions Tatton Gazebo Code: 00629 V2 05 24 (W x D x H) 2.64m x 2.64m x 2.49m ONLINE ASSEMBLY VIDEO AVAILABLE Please scan the QR code or visit zestoutdoorlivingsupport.co.uk PLEASE KEEP THESE INSTRUCTIONS www.zestoutdoorliving.co.uk | 01352 873555 | sales@zestoutdoorliving.co.uk...
Page 2 European redwood. Unlike man-made materials, timber is an entirely natural material, and each piece has its own distinctive qualities. So, owning a Zest timber product is like enjoying a unique slice of nature. The benefits of slow grown timber: Trees grow slowly in the cold climate of Eastern...
Page 3 10897 Finial 10966 Rafter 10898 Fascia 10896 Roof Panel 10972 Roof Panel End Board 10967 Roof Capping Tatton Seat Parts - Optional Extra 11278 Leg Brace 11279 Seat Leg 11280 Seat Brace 11281 Front Fascia 11282 Back Fascia 11283 Seat Board Small...
Page 4 11725 - Tatton Gazebo Fixings List Item Description Quantity 45mm Screws 70mm Screws 120mm Screws Expansion Tape (N.B. This product must be assembled on a level surface.) This product is made from pressure-treated timber. It should not be painted or coated with any other treatment until at least 6 months after purchase www.zestoutdoorliving.co.uk | 01352 873555 | sales@zestoutdoorliving.co.uk...
Page 5 Lay out 6 Floor Panels A as shown in Fig.1a and fix together using 12no 70mm Screws as shown in Fig.1b. Place the Infill B in centre and fix in position using 6no 45mm Screws (Fig.1c). PANEL MAY VARY Attach 2no Posts C to Full Panel D using 6no 70mm Screws (3no per post) as shown in Fig.2a.
Page 6 Insert 6no Rafters H into predrilled holes of Finial G (Fig.3a) and fix in position using 6no 120mm Screws (1no per Rafter H). Lift Rafter Assembly into slots on top of Posts C (Fig.3b) and fix in position using 12no 70mm Screws (2no per post) –...
Page 7 (N.B. Prior to fixing Roof Panels, apply two even beads of silicone to each Rafter D and into grooves in Finial G.) Position Roof Panel K onto Rafters D and into groove in Finial G (Fig.5a). Fix in position using 6no 45mm Screws (3no per side) - Fig.5b. Repeat procedure for remaining 5no Roof Panels K.
Page 8: Left Leg Assembly
Seat Assembly – Optional Extra LEFT LEG ASSEMBLY RIGHT LEG ASSEMBLY LEFT LEG ASSEMBLY Using 8no 45mm Screws (4no per Leg Brace N), fix 2no Leg Braces N to 2no Seat Legs O ensuring lower brace is 20mm up from bottom of Seat Legs O and top brace is flush with top of Seat Legs O (Fig.7a).
Page 9 Your Tatton Gazebo is now complete. www.zestoutdoorliving.co.uk | 01352 873555 | sales@zestoutdoorliving.co.uk of 9...
