Woson TANCO 8L Instruction Manual

Steam sterilizer autoclaw

Quick Links

Download this manual

Before using the device for the first time, the u s e r is required to read the instruction manual carefully. The manual is

provided to inform you about the correct use of the autoclave. Use the device in accordance with the recommendations

contained in this manual.

MODEL: TANCO 8L | TANCO 12L

IMPORTER

Release date of the

manual: Rev. G 08.2023

(EN) Rev. G 08.2023

(EN)

STEAM STERILIZER

AUTOCLAW

Importer and Authorized Service Point in Poland

Activeshop Ltd.

8B Graniczna St.,

Bud.DC2A 54-610 Wroclaw,

Poland

www.activeshop.com.pl

Table of Contents

Need help?

Do you have a question about the TANCO 8L and is the answer not in the manual?

Questions and answers

Summary of Contents for Woson TANCO 8L

Page 1 Use the device in accordance with the recommendations contained in this manual. STEAM STERILIZER AUTOCLAW MODEL: TANCO 8L | TANCO 12L Importer and Authorized Service Point in Poland Activeshop Ltd. IMPORTER 8B Graniczna St.,...
Page 2: Basic Information
User Manual Autoclave Model: TANCO 8L | TANCO BASIC INFORMATION Contact details Manufacturer Ningbo Jiangbei Woson Medical Instrument Co., Ltd. Building 95, No.25, Lane 300, Jinshan Road, Jiangbei District, Ningbo 315032, China tel: +86 574 83022668 | fax: +86 574 87639376 e-mail: overseas@woson.com.cn | www.woson.com.cn...
Page 3: Table Of Contents
User Manual Autoclave Model: TANCO 8L | TANCO TABLE OF CONTENTS BASIC INFORMATION........................................2 Contact information ..........................................2 Information about the manual......................................2 Legal requirements ..........................................2 CHAPTER 1 INTRODUCTION......................................5 1.1. Note/Important Information ....................................5 1.2. Application ..........................................5 1.3. Contraindications ........................................5 CHAPTER 2 SECURITY........................................5 2.1.
Page 4 User Manual Autoclave Model: TANCO 8L | TANCO CHAPTER 9 SERVICING THE DEVICE BY AN AUTHORIZED SERVICE CENTER..................21 CHAPTER 10 STORAGE AND TRANSPORTATION..............................22 10.1. Preparation for transport and storage................................22 10.2. Tank emptying ........................................22 10.3. Storage and transport conditions..................................22 10.4. Packaging..........................................22 Appendix No.
Page 5: Chapter 1 Introduction
User Manual Autoclave Model: TANCO 8L | TANCO CHAPTER 1 INTRODUCTION 1.1. Note/Important Information This manual contains necessary and sufficient information for safe operation of the device, such as optimal use, safe, reliable operation, and regular and correct service requirements.
Page 6: Warnings And Important Safety Information
User Manual Autoclave Model: TANCO 8L | TANCO Dispose of the device in accordance with the requirements of Directive 2012/19/EC. Used device Type B application part. Return to waste electrical equipment treatment facilities and electronic, according to with the local regulations in force, in this regard.
Page 7: Security Elements
User Manual Autoclave Model: TANCO 8L | TANCO - Only qualified technical personnel may perform any repairs and/or service, using original spare parts. - Before transportation, completely empty the tanks for clean and dirty (used) water and cool the autoclave chamber.
Page 8: Operational Risk
User Manual Autoclave Model: TANCO 8L | TANCO or an unqualified technician. Any repairs to the device can only be performed by an employee of a warranty and post-warranty service company authorized by the Manufacturer. 2.4. Operational risk Be careful when using the device to avoid a dangerous situation.
Page 9: Additional Equipment
User Manual Autoclave Model: TANCO 8L | TANCO 3.3. Additional equipment Name Model Quantity Appearance Built-in printer* USB memory card* Optional. 3.4. Requirements of the installation environment Place the autoclave on a level stable surface, so as to provide at least 10 cm of free space on each side, and at least 20 cm above the device, as shown in the following figures: Place the device in a room with adequate ventilation.
Page 10: Chapter 4 Description And Specification
(nominal diameter x depth): Φ192 mm × 320 mm (applies to model: TANCO 12L) 132 mm × 137 mm × 251 mm (applies to model: TANCO 8L) Cargo dimensions: 155 mm × 155 mm × 251 mm (applies to model: TANCO 12L) 2.56 kg/cm...
Page 11: The Course Of The Sterilization Cycle
User Manual Autoclave Model: TANCO 8L | TANCO 4.2.3. Safety valve Valve release pressure: 245 kPa (2.45 bar) Maximum operating temperature: 160°C 4.2.4. Tank capacity Distilled water tank capacity: 4,5L Used water tank capacity: 4,5L WARNING Pour only distilled water into the tank. The water temperature must not exceed 40°C.
Page 12: Chapter 5 Control Panel
User Manual Autoclave Model: TANCO 8L | TANCO CHAPTER 5 CONTROL PANEL 5.1. Control panel Chamber temperature display window Chamber pressure display window Cycle status/error code display window Program selection button Program selection window Program selection button Program selection window...
Page 13: Water Level And Quality Indicators
User Manual Autoclave Model: TANCO 8L | TANCO 5.2.1.4. Porous/Porous The program is designed for sterilization of cotton materials and similar articles. Program parameters: 121°C; 110 kPa; 3-fold vacuum; sterilization time: 20 minutes; drying time: 18 minutes. 5.2.2. Test program/Test program In standby mode, briefly press , to start switching to the corresponding test program.
Page 14: Sterilization Programs
User Manual Autoclave Model: TANCO 8L | TANCO 5.4. Sterilization programs If the device is on, the following programs can be selected with the appropriate parameters: Crossover Time Time Program Temperature Pressure vacuum sterilization drying UNPACKED/UNWRAPPED 134°C 210 kPa 4 min...
Page 15: Time Setting
User Manual Autoclave Model: TANCO 8L | TANCO 134.8 21.3 21.3 218.3 -80.4 St: Sterilization rE: Reducing pressure dr: Drying 90.2 0.11 PASS End of 5.6. Time setting In standby mode, press and hold the button for 8 seconds to enter the time setting mode.
Page 16: Alarming In Case Of High Level In Waste Water Tank
User Manual Autoclave Model: TANCO 8L | TANCO Filling the clean water tank is done manually. The tank is located in the upper part of the device. Open the lid of the tank and then pour distilled water up to the designated level, about 2 cm from the lid of the tank.
Page 17: Closing The Door
User Manual Autoclave Model: TANCO 8L | TANCO The arrangement is shown in the figures below: GOOD WRONG Thoroughly clean all items before placing them in the chamber. If the room temperature is lower than 10°C, before starting the program, turn on the autoclave for NOTE about 5-10 minutes to start heating the chamber.
Page 18: Power Off
User Manual Autoclave Model: TANCO 8L | TANCO 6.9. Power off After the process is complete, if the unit is no longer in use, press the power button to turn off the autoclave. When the green light of the power button goes out, close the door, but in such a way that it is not completely locked. If the unit will not be used for a long time, remove the power cord from the electrical outlet.
Page 19: Chapter 8 Maintenance
User Manual Autoclave Model: TANCO 8L | TANCO CHAPTER 8 MAINTENANCE 8.1. Maintenance schedule Period Action Person in charge Cleaning the door seal User Daily Cleaning the chamber User Cleaning the chamber, trays and rack User Weekly Cleaning the water drain filters...
Page 20: Monthly Maintenance
User Manual Autoclave Model: TANCO 8L | TANCO Use distilled water for the device in a strict manner to prevent The accumulation of mineral impurities and the occurrence of corrosion of the chamber. Always WARNING clean the chamber if salt solutions have been sterilized.
Page 21: Chapter 9 Servicing The Device By Authorized Service
User Manual Autoclave Model: TANCO 8L | TANCO With one hand, gently hold the edge of the gasket, then with the other hand, insert a screwdriver into the gap between the gasket and the door. Slowly remove the gasket. First remove a small part of the gasket, and then you can slowly pull out the entire gasket. After removing the gasket, clean it thoroughly, especially its groove.
Page 22: Chapter 10 Storage And Transportation
User Manual Autoclave Model: TANCO 8L | TANCO CHAPTER 10 STORAGE AND TRANSPORTATION 10.1. Preparation for transport and storage Turn off the device with the power button, unplug the power cord and wait for the device to cool down completely.
Page 23: Appendix No. 3 Hydraulic And Electrical System Diagram
User Manual Autoclave Model: TANCO 8L | TANCO Explanation of error message designations: Error code L.p. Meaning number Er01 The temperature of the steam generator is too high. Er02 The temperature of the heating ring is too high. Er03 Too high a temperature inside the chamber.
Page 24: Annex No. 4 Checklist For Evaluating The Requirements For The Device
User Manual Autoclave Model: TANCO 8L | TANCO Diagram of the electrical system Annex No. 4 Checklist for evaluating the requirements for the device The part that L.p. Requirements needs to be checked Appearance/Constr The device should be clean, without any distortion or damage, such as bends, dents, pits, uction of the scratches/beats, sharp edges, etc.
Page 25 User Manual Autoclave Model: TANCO 8L | TANCO The device must be equipped with a safety valve. The opening of the valve is then, Safety valve When the pressure value is about 0.27 MPa ± 0.01 MPa. If the pressure reaches the set value, the safety valve will automatically open and reduce the pressure.
Page 26 User Manual Autoclave Model: TANCO 8L | TANCO For all batches except for indented type A batches, the presence of saturated vapor in the load and in the usable space is considered achieved if all temperatures measured in the usable space and in the load throughout storage: - Are not lower than the sterilization temperature;...
Page 27 User Manual Autoclave Model: TANCO 8L | TANCO Check saturation vapor of water during sterilization indented batches Inset type A and type B, are distinguished by changing the color of the chemical indicators and checking that this corresponds to the requirements of the indicator manufacturer.
